- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. TUSCANY cs892lp Owner's Manual Shop genuine replacement parts for TUSCANY cs892lp Find Your TUSCANY Grill Parts - Select From 11 Models -------- Manual continues below --------...
- Page 2 USE AND CARE MANUAL For Model CS892LP Stop! Missing a part? DO NOT RETURN PRODUCT TO STORE The store where you made the purchase does not stock parts for this item. If you need parts, whether they are 1-800-229-5647 missing or damaged, please call Customer Service at Call us between 8:00 AM and 5:00 PM Eastern time, Monday through Friday or email us at saleshelp@sureheat.com FOR YOUR SAFETY:...
-
Page 3: General Safety Instructions
General Safety Instructions IMPORTANT SAFETY INFORMATION - Read this manual carefully before using your grill to reduce the risk of fire, burn hazard or other injury. - Extreme care should be used because of the high temperatures produced by this appliance. - Page 4 General Safety Instructions ▲ ▲ WARNING WARNING NOTE: Do Not operate the main burners and Do not use the rotisserie in the rain. infrared back burner at the same time. This can cause warping of the roll top grill hood. ▲...
-
Page 5: Grill Features
Grill Features 1. Roll top grill hood 8. Side burner 2. Bread warming rack 9. Towel bar 3. Grilling/cooking surface 10. Control Knob: Side burner 4. Side shelf 11. Electronic igniter: main burners, side burner and bottom IR burner 5. Left cart 12. -
Page 6: Getting Started
Getting Started 10 - Self-tapping screws 8 - Phillis sunk screws M4 x 10 26 - Phillips head screws M5 x 12 Getting Started 1. Please follow the steps in the order that they are presented. 2. Assemble the grill where you plan to use it. 3. -
Page 7: Grill Assembly
Grill Assembly LEFT SHELF ASSEMBLY Fig. 1 1. Loosen the four M5 x 12 Phillips head screws on the middle of the grill cart left by approximately 1/4". Attach the grill cover shelf by inserting the four bolt heads into the holes on the grill cover shelf. Tighten the four screws to secure the shelf. - Page 8 Grill Assembly SIDE BURNER PARTS ASSEMBLY Fig. 6 6. Loosen the four M6 x 12 Phillips head screws on the bottom of the grill cart right by approximately 1/4". Attach the tank tray by inserting the four bolt heads into the holes on the tank tray. Tighten the four screws to secure the tank tray.
- Page 9 Grill Assembly Side burner bracket Fig. 11 SIDE BURNER PARTS ASSEMBLY Fig. 9 Orifi ce bracket 11. Remove the two M5 x 8 Phillips head screws from Bolts Holes the orifi ce bracket. Align the orifi ce into the center of the side burner bracket.
-
Page 10: Door Assembly
Grill Assembly DOOR ASSEMBLY Fig. 16 16. Attach the left cart door to the left cart assembly by securing the hinges with four M4 x 10 Phillips sunk screws . (See Fig. 16) Phillips sunk screws Fig. 17 17. Attach the right cart door to the right cart assembly by securing the hinges with four M4 x 10 Phillips sunk screws. - Page 11 Serving Cart Usage 1. Pull the serving cart out from the grill cart. Fig. 19 (See Fig. 19) 2. 2. Grasp the control bars on both sides. Then left Control bar Fig. 20 the control bars up and the serving cart will raise and lock into position.
-
Page 12: Gas Requirements
Gas Requirements GENERAL INFORMATION ▲ Never attach an unregulated gas line to the appliance. Connection to WARNING an unregulated gas line can cause excessive heat or fi re. Verify the type of gas supply to be used, either Natural Gas (N.G.) or Liquid Propane (L.P.), and make sure the serial plate agrees with that of the supply. -
Page 13: Gas Installation
Gas Requirements L.P. GAS INSTALLATION Tuscany™Gas Grills that are set to operate with L.P. gas come with a high capacity hose and regulator assembly. (Note: Only use the pressure regulator and hose assembly supplied with the grill or a replacement pressure regulator and hose assemblies specified by Tuscany™). This assembly is designed to connect directly to a standard 20 lb. -
Page 14: Pre Operation Leak Testing
Pre Operation Leak Testing GENERAL INFORMATION Although all gas connections on the grill are leak tested prior to shipment, a complete gas tightness check must be performed at the installation site due to possible shifting during shipment, installation or excessive pressure unknowingly being applied to the unit. Periodically check the whole system for leaks and immediately check the system if the smell of gas is detected. -
Page 15: Lighting The Grill
Lighting the Grill Do not attempt to "Light" the grill if the odor of gas present!! BEFORE LIGHTING Fig. 21 ▲ Important! Before Lighting: WARNING • Check the gas supply line for cuts, wear or abrasion. • Always keep your face and body as far away from the grill as possible when lighting. - Page 16 Using the Grill and Side Burner GRILL LOCATION Do not use the grill in garages, breezeways, sheds or any enclosed area. Never operate the grill ▲ WARNING in enclosed areas as this could lead to a carbon monoxide buildup, which could result in injury or death.
-
Page 17: Bottom Infrared Cooking Tips
Bottom Infrared Cooking Tips Even with an expert chef, infrared cooking can be quite a challenge. If you follow these simple suggestions, you will soon be making juicier, more savory foods than you have ever experienced before. In general, foods will cook in less time then they would take an ordinary grill. If you rotate food regularly (about every 2 minutes), extreme charring is avoided. -
Page 18: Care And Maintenance
Care and Maintenance PROTECTION OF INFRARED BURNERS The burners of your grill are designed to provide a long life of satisfactory performance. However, there are steps you must take to prevent cracking of the burner's ceramic surfaces, which will cause the burners to malfunction. -
Page 19: Cooking Grates
Care and Maintenance DRIP TRAY The drip tray should be cleaned periodically to prevent heavy buildup of debris. NOTE: Allow the drip tray to cool before attempting to clean. Important: Do not leave the grill outside during inclement weather unless it is covered. Rain water can collect inside of the grill, the grill cart or the drip tray if left uncovered. -
Page 20: Troubleshooting Your Grill
Troubleshooting Your Grill GENERAL TROUBLE SHOOTING You should inspect the burners at least once a year or immediately if any of the following conditions occur: • The smell of gas. • Flames appearing mostly yellow. (some yellow at the tips is OK) •... - Page 21 Troubleshooting Your Grill Problem SOLUTION Grill will not light with a match or low heat with dial • Is your gas supply fully turned on? set to "High" position. • Is there gas in your L.P. tank? Check your gas level. •...
-
Page 22: Replacement Parts List
Replacement Parts List Hood Assembly Flavor Grid B SASBA00173C SBNMC00139A 1 set 1 piece Hood Handle Assy. Main Burner Tube SASQG00005A RCOAZ00071A 1 set 1 piece Temperature Gauge Front Face Assy. RCOZZ00029A SWLBA00344A 1 piece 1 set Bread Warming Rack Manifold &... - Page 23 Replacement Parts List Side IR Burner Right Cart Door RCOZZ00207A SBNCB00550B 1 piece 1 set Orifi ce Bracket Tank Tray SBNAB00062A SBNCD00563A 1 piece 1 set Side Burner Orifi ce Side Shelf Assembly RCODZ00045A SASCB00547B 1 piece 1 set Side Burner Valve Assembly Towel Bar RCOPZ00001A SCTQG00013A...
- Page 24 Replacement Parts List Grill Cover Shelf Tank Barrier Shelf SBNCD00555A SBNCD00585A 1 set 1 set Drip Pan Swivel Caster with Lock SBNMC00398A RCOZZ00218A 1 set 1 piece Cart Back Swivel Caster SBNCB00595A RCOZZ00219A 1 set 1 piece Cart Door Right Serving Cart SBNCD00567A SWLCD00586A...
- Page 25 LIMITED WARRANTY Sure Heat Mfg warrants that for 2 years from the date of purchase, the stainless steel panels will not break due to defects in material or workmanship. All other components of this grill are warranted free from defects in material and workmanship for one year from the date of purchase. Sure Heat Mfg. at its option, will repair or replace this product or any component of the product found to be defective during the warranty period.
