Summary of Contents for Siera PRO 9792IP

  • Page 1 PRO 9792IP User Manual...
  • Page 3 Precautions Fully understand this document before using this device, and strictly observe rules in this document when using this device. If you install this device in public places, provide the tip "You have entered the area of electronic surveillance" in an eye-catching place. Failure to correctly use electrical products may cause fire and severe injuries.
  • Page 4 Caution If this device is installed in places where thunder and lightning Ÿ frequently occur, ground the device nearby to discharge high energy such as thunder strikes in order to prevent device damage. CAUTION Avoid heavy loads, intensive shakes, and soaking to prevent Ÿ...
  • Page 5: Special Announcement

    Special Announcement All complete products sold by the manufacturer are delivered along with Ÿ nameplates, quick setup guide and accessories after strict inspection. The manufacturer shall not be held responsible for counterfeit products. The manufacturer will update this manual according to product function Ÿ...
  • Page 6: Device Structure

    Open Package Examination Open the package, check the appearance of product for no obvious damage, and confirm the item list for table 1-1 is consistent. Table 1-1 Packing list Quantity Component Remark High Speed Dome Camera Quick Setup Guide Bracket connector No.5 Hex Wrench Slotted screwdriver Terminal block...
  • Page 7 Core Function Description Alarm input and alarm Brown Alarm output channel 1 output channels. Brown/ Alarm output channel 1 common terminal Black Alarm output channel 2 Alarm output channel 2 Red/ common terminal Black Orange Alarm input channel 1 Orange/ Alarm input channel 2 Black Yellow...
  • Page 8 2.2 Camera Dimensions NOTE Different device may have different dimensions, please refer to the actual product. Figure 2-2 Dimensions Unit:mm...
  • Page 9: Device Installation

    Device Installation Installation Steps: Step 1 Please make the mark based on bracket dimensions for drilling the hole. Drill four φ8 holes over 60 mm depth, and drive the swell plastic buttons into the holes. Figure 3-1 Bracket dimensions(unit:mm) 备注 63.6 φ...
  • Page 10 Figure 3-3 Fixing the bracket and dome 备注 Wall bracket Ceiling bracket Tightening the screws Tightening the screws Step 4 Mount the high speed dome to the wall or ceiling and tighten the four screws on the bracket completely. Quick Configurations (Eg IE) 4.1 Login Step 1 Open the Internet Explorer, enter the IP address of IP camera (default value: 192.168.1.251 in the address box, and press...
  • Page 11 Step3 Click Login, the main page is displayed. 4.2 Modify IP address Choose Configuration > Device > Local Network, the Local Network page is displayed. Enter the IP address in the IP Address box and click Apply as shown in figure 4-2.
  • Page 12 Figure 4-3 Adding a trusted site Figure 4-4 Configuring ActiveX control and plug-in Step 3 Download and install the player control as prompted. NOTE If the repair tips displayed when installing the control , please ignore the prompt, and continue the installation, the login page is displayed when the control is loaded.
  • Page 13 To browse a real-time video, click Live Video. The Live Video page is displayed, as shown in figure 4-5. Figure 4-5 Live Video Playback Configuration Live Video Stream Camera 4.4 Two-way audio NOTE Partial camera do not support two-way audio, this section do not apply.
  • Page 14 Alarm input and Alarm output connection: Step1 Connect alarm input device to Alarm IN0 and Alarm COM0 of multi-head cable. Step2 Connect alarm output device to Alarm OUT1 and Alarm COM1 of multi-head cable, alarm output interface can connect to normal open device only. Step3 Log in Web, Choose Configuration>Alarm>I/O Alarm, set the parameters as shown in figure 4-6.
  • Page 15: Simple Troubleshooting

    5.1 Simple Troubleshooting Failure Mode Parts For Checking Possible Cause Solution No actions and Power supply is abnormal Replace no images External electricity Main board exists after power on Replace problems Whether something get stuck Motor is abnormal Mechanical fault There is image, The swing of camera Very oblique...
  • Page 16 5.3 Lighting Protection, Surge Protection Outdoor speed dome camera must consider thunder-proof and surge immunity. On the premise of guaranteeing electrical safety,we can take following lightning protection measures: .At least keep 50m distance between signal transmission line and high voltage equipment or high voltage cable.
  • Page 17 5.4 Pressing Line Method And Line-sequential Of Network Cable There are two kinds of network cable: crossover cable and parallel cable. Crossover cable: one end uses the standard of 568A, the other end uses the standard of 568B. Parallel cable: Both the two ends use 568A or 568B (568B is mostly adopted). The standard of 568A: green-and-white, green, orange-and-white, blue, blue-and-white, orange, brown-and-white, brown.
