- Page 1 Handles Storage High (KB08RI-091 / KB08MI-014)
- Page 2 Manufacturer: Kingsbox d.o.o. Partizanska 129, 6210 Sežana Slovenia Customer service: Write us on info@kingsbox.com or send us a message through our website at www.kingsbox.com/help Usage class: Studio (S) Designed in compliance with: ISO 20957 Warnings: - Freestanding equipment shall be installed on a stable and levelled base - All equipment designed with anchoring/attachement holes (e.g.
- Page 3 ATTENZIONE! Se la struttura non viene fissata a terra e/o al muro, puo’ rib-altarsi e/o provocare danni a persone o oggetti in immediata vicinnanza. I bulloni per il fissaggio del rig a muro e/o al pavimento non sono inclusi nel pacco, in quanto per diversi tipi di muro 7 pavi- men-tazione bisogna utilizzare diversi tipi di bulloni d’ancoraggio.
- Page 4 Assembly elements: Position 1 Position 2 Position 3 1x Handles Storage 2x Hook 1 2x Hook 2 High Position 4 Position 5 Position 6 4x Screw M12x110 6x Hook 3 4x Hook Protection or M12x90 Position 7 Position 8 Position 9 8x Washer M6 4x Screw M6x20 4x Nut M6...
- Page 5 Assembly elements: Position 10 Position 11 8x Washer M12 4x Nut M12...
-
Page 6: Tools Needed
Tools needed: Wrench 19 Wrench 10... -
Page 7: Assembly Instruction
Assembly instruction: STEP: 1 STEP: 2... - Page 8 Assembly instruction: STEP: 3 MAX. LOAD: MAX. SUM LOAD: 40kg Max. 15 kg/hook Max. 15 kg/hook Max. 10 kg/hook Max. 15 kg/hook...
