产品使用手册1
Product Instruction Manual
爱玛
温馨提示:
Tips:
使用前请仔细阅读使用说明书,
Please read the user manual carefully before use.
未了解电动摩托车的特性前请不要使用,应妥善保存说明书。
Do not use the electric motorcycle without knowing its
characteristics, and keep the instructions properly.
AIMA
使用者禁止对车辆进行非法改装!
Users are prohibited from illegally modifying the vehicle!
注:未得爱玛科技集团股份有限公司的书面同意,不得翻印本《使用说明书》的任何部分。
A05 电动车
Note: No part of this User Manual may be reproduced without the written consent of AIMA Technology
A05 Electric vehicle
Group Co., Ltd.
使用手册 V1.0
Instruction Manual V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A05 and is the answer not in the manual?

Questions and answers

Summary of Contents for AIMA A05

  • Page 1 使用者禁止对车辆进行非法改装! Users are prohibited from illegally modifying the vehicle! 注:未得爱玛科技集团股份有限公司的书面同意,不得翻印本《使用说明书》的任何部分。 A05 电动车 Note: No part of this User Manual may be reproduced without the written consent of AIMA Technology A05 Electric vehicle Group Co., Ltd. 使用手册 V1.0 Instruction Manual V1.0...
  • Page 2 产品使用手册2 Product Instruction Manual 爱就马上行动 爱玛科技股份有限公司监制 Supervised by AIMA TECHNOLOGY GROUP CO.,LTD 格瓴新能源科技(山东)有限公司 Act at once if you love Geling New Energy Technology (Shandong) Co., Ltd. 地址: 山东沂南县开元路 88 号 Address: No. 88, Kaiyuan Road, Yinan County, Shandong Province 售后服务电话: 4008828890...
  • Page 3: Table Of Contents

    产品使用手册1 Product Instruction Manual 安全驾驶注意事项 目录 Notes for Driving Safety 1.在仔细阅读使用手册、了解电动三轮车的性能之前,不要使用电动三轮车;不要借给不会 Directory 操作电动三轮车的人骑行。 1.Do not use the electric tricycle until carefully read instruction manual and understand the performance of the electric tricycle; do not lend to anyone who is unable not operate the electric 安全驾驶注意事项...
  • Page 4 7.Power grid indication 黄色显示时为需要充电提示并降低车速功率。 parts from AIMA Sales Store. In addition, when purchase our products, please fill in the "User Warranty Card" completely and clearly, keep the "User Stub Copy" properly, and deliver the When it is yellow, the charging is required and it indicates that the vehicle speed power is other two copies to our local service station so that we can contact and serve you in time.
  • Page 5 产品使用手册3 Product Instruction Manual 启动方法 Boot Method 车辆带有 P 档功能,以下情况会进入 P 档: 启动方式一:使用机械钥匙打开车门,进入车辆,按下一键启动按键启动车辆电源 The vehicle is equipped with P gear function, and it will enter P gear under the following Start mode I: use the mechanical key to open the door and enter the vehicle, and press the next conditions: 1.当手刹拉起时,显示...
  • Page 6 产品使用手册4 Product Instruction Manual 左、右组合开关 Left and right combination switch 危险报警开关 近光灯打开、 1.灯光开关、右组合开关向左打开大灯,向右打开位灯;在大灯状态下按 Danger alarm switch 按 远光灯打开;左组合开关向左, 左转向灯亮起,向右右转向灯亮起, 中间为转向灯关闭 当启动状态时按下按钮,车辆警示灯闪烁,再次按下时关闭 1.Turn the light switch and the right combination switch to the left to turn on the headlight and to When the button is pressed in the start-up state, the vehicle warning light flashes, and it turns off the right to turn on the positionlight;...
  • Page 7 产品使用手册5 Product Instruction Manual 顶灯功能: 铅酸蓄电池接线参考 Dome light function: Lead-acid battery wiring reference 当顶灯开关位于 ON 档时, 顶灯开启。 当顶灯开关 本车型为 60-72V 通用版车型,请在接线时确认车辆适配的电池电压,可参考如下方式进行 位于"DOOR"档位时,打开车门,顶灯点亮。 电池连接: When the dome light switch is ON, the dome light is This model is a 60-72V universal model. Please confirm the battery voltage suitable for the turned on.
  • Page 8: 车辆智能化控制

    产品使用手册6 Product Instruction Manual 车辆智能化控制 Intelligent vehicle control 智能版车型配置有智能化控车系统,您可扫码下载“GREEN 智行”后,扫描车辆(座桶)上方的 二维码,按照 APP 指引,连接蓝牙绑定车辆后,实现手机 APP 控车。 The intelligent model is equipped with intelligent vehicle control system, you can scan the code to download “GREEN Smart Drive” and scan the QR code above the vehicle (seat bucket). According to guidelines in the APP, connect the Bluetooth binding vehicle to realize mobile APP vehicle control.
  • Page 9: 充电的方法

    4.Pay attention to the battery type and applicable voltage matched by the charger. Mixed-using and charging 当充电器的输入和输出端接通后,充电器的红色指示灯亮,表示电源已接通正在充电。 with any non-standard AIMA special quick charging equipment is strictly prohibited. When the input and output terminals of the charger are connected, the red light of the charger will 5.充电器内部有高压电路,严禁自行拆解或维修充电器,如有以上行为,充电器将不享受质保服务,...
  • Page 10: 检查与维修

    时与爱玛服务站联系并进行维修。 any abnormality, please go to the distributor for inspection and maintenance, and shall be The motor shall be inspected at AIMA Service Station every three months. No special inspected regularly. maintenance is required for daily use of the motor. If any abnormality is found, please contact AIMA Service Station in time for maintenance.
  • Page 11 产品使用手册9 Product Instruction Manual 相关润滑剂周期 蓄电池的保养 The Relevant Lubricant Cycle Maintenance of Battery 1.新车首次使用,蓄电池应充足电。 润滑部位 润滑周期 推荐润滑用油 1.When the new vehicle is used for the first time, the battery shall be fully charged. Lubricated part Lubrication cycle Recommended lubricating oil 2.每次使用完车辆,应尽快充足电。这样有利于延长蓄电池使用寿命。...
  • Page 12 Brake light switch lock nut absorper-steering knuckle 请使用爱玛专用电机控制器,严禁私自更换,或更改电路。 拖曳臂后桥(U 型螺栓) 制动总泵制动踏板 Please use the special motor controller of AIMA, and it is forbidden to replace or change the 45± 5 23± 2 Towing Arm-Rear Axle (U-bolt) Braking master cylinder-brake pedal circuit without permission.
  • Page 13: 车辆参数

    产品使用手册11 Product Instruction Manual 车辆参数 故障现象与排除 Failure and Troubleshooting 故障现象 Troubles 故障原因 Causes 排除方法 Elimination solution Inspection and maintenance 打开电源仪表无显 1 保险丝断路 1 查明原因并更换保险丝 序号 内容 参数 示调速失灵 1.Fuse open circuit 1.Find out the cause and replace the Serial Content Parameter 2 电源插头与电池插座接触不良...
  • Page 14: 整车结构图

    产品使用手册12 Product Instruction Manual 整车结构图 Vehicle Structure Diagram 顶盖 Top cover 左前门玻璃 前挡风玻璃 前挡风玻璃 Left front door glass Front windscreen Front windscreen 外后视镜总成 左侧围后窗玻璃 Exterior mirror assembly Left Rear Quarter 前机盖本体 Window Glass 左前侧翼子板本体 Front Cover Body Left Front Fender Body 充电口...
  • Page 15: 电器原理图

    产品使用手册13 Product Instruction Manual 电器原理图 控制器 蓝 电源指示 脚刹开关 远光灯 controller SOURCE INDI. foot brake switch high-beam headlight Electrical Principle Diagram 相线 绿白 红 手刹开关 远光指示 phase line green & white hand brake switch high-beam indicator 霍尔 灰白 空开 黑 大灯开关...
  • Page 16: 售后服务及质保范围

    产品使用手册14 Product Instruction Manual 售后服务及质保范围 After-sales Service and Warranty Scope 尊敬的用户: Dear Users: 感谢您购买本公司的电动车,为切实保护您的合法权益,同时便于我们履行质保义务和承担责任,请 您妥善保存维修卡。凭卡及购车发票可以到售车单位享受质保服务。 Thank you for purchasing our electric vehicle. In order to protect your legal rights and facilitate our warranty obligations and responsibilities, please keep the maintenance card in a safe place. With this card and the purchase invoice, you can enjoy warranty services at the dealership where you bought the vehicle.
