2 x Front Support Posts
2 x Rear Support Posts
2 x Roof Framing
4 x Roof Rafters
13 x Featheredge Roof
2 x Side Fascia Boards
1 x Front Fascia Board
1 x Decorative Front Piece
3 x Decorative Crosshatch Panel
4 x 32mm Square Spindles
3 x Hand / Baserail (Rear)
6 x Hand / Baserail (Sides)
95 x 50mm Green Screws
16 x 75mm Green Screws
20 x 100mm Screws
All images are for illustration only. Please see individual item listings for actual item specifications.
3" x 3"
2100mmm
3" x 3"
1950mm
2" x 2"
1660mm
2" x 2"
1260mm (Angle Cut)
1800mm
4" x 1"
1350mm (Angle Cut)
4" x 1"
1840mm
1660mm
1200mm
Recommended Tools
(A1)
Drill Driver
(A2)
PZ2 Driver Bit
(B1)
Tape Measure
(B2)
Spirit Level
(B3)
(B4)
(B5)
(B6)
(C1)
(C2)
(C3)
(C4)
(FIX 1)
(FIX 2)
(FIX 3)
We recommend two
people to assemble this
BBQ shelter.
Page 1 of 10
Advertisement
Summary of Contents for eDecks Cross Hatch Garden BBQ Shelter
- Page 1 Recommended Tools 2 x Front Support Posts 3” x 3” 2100mmm (A1) Drill Driver 2 x Rear Support Posts 3” x 3” 1950mm (A2) PZ2 Driver Bit 2 x Roof Framing 2” x 2” 1660mm (B1) Tape Measure 4 x Roof Rafters 2”...
- Page 2 *To prevent splits, drill a pilot hole before driving screws* To create the rear panel, assemble parts (C1), (C2) and (C3) as per below, use 50mm green screws (FIX 1) as indicated to join the pieces together. The panel should be approximately 270mm in from either end to be centred. FIX1 FIX1 FIX1...
- Page 3 *To prevent splits, drill a pilot hole before driving screws* To create the side panels, assemble parts (C1) and (C4) as per below, use 50mm green screws (FIX 1) as indicated to join the pieces together. The panel should be approximately 35mm in from either end to be centred. Repeat the process for both sides.
- Page 4 *To prevent splits, drill a pilot hole before driving screws* With the three side/rear panels now built, they can be attached to the corner support posts. Starting with the rear support posts (A2) place the rear panel between the two posts and screw into place using 2 x 100mm screws (FIX 3) per side, driving through the post from the out- side, one at the top and one at the bottom.
- Page 5 *To prevent splits, drill a pilot hole before driving screws* Using the roof framing parts (B1) and (B2) assemble your roof frame as below. Screw through the face of (B1) into the rafters / frame timbers (B2) using 2 x 75mm green screws (FIX 2) at each end. Please Note: Due to the slight angle cuts on pieces (B2) the frame should not lay flat;...
- Page 6 *To prevent splits, drill a pilot hole before driving screws* Attach the featheredge roof boards (B3) to the roof frame you have just built in step 5 using 1 x 50mm green screw (FIX1) per board, per joist as indicated to the right.
- Page 7 *To prevent splits, drill a pilot hole before driving screws* Lift the roof above the corner posts and rest it in place, the outer edges of the roof frame should sit inside the posts. Fix the roof in place using 2 x 100mm wood screws (FIX 3) per corner driving through the posts from the outside. FIX3 Page 7 of 10 All images are for illustration only.
- Page 8 *To prevent splits, drill a pilot hole before driving screws* With the roof fixed in place the fascia boards (B4), (B5) and the decorative piece (B6) can now be installed to finish off the roof section. The fascia's are fastened into place using 4 x 50mm green screws (FIX 1) as below. The decorative piece is to be centred on the fascia and fixed in place by screwing through the back of the frame into the piece using 1 x 50mm green screw (FIX 1) .
- Page 9 *To prevent splits, drill a pilot hole before driving screws* To complete the build, you lastly have to install the side and rear handrails (C3) and (C4) which double up to create a more solid feel and cover any screw holes made in earlier steps. These should sit flush in-between your corner posts and are secured using 1 x 50 green screw (FIX 1) at each end, the screws should be driven up through the bottom handrail into the other (C3 / C4) sitting on top.
- Page 10 Page 10 of 10 All images are for illustration only. Please see individual item listings for actual item specifications.
