Summary of Contents for Orlaco 0710240
- Page 1 Cable reel spring driven 12mtr Cable reel spring driven 12mtr with heater Installation Manual Manual IM0973410 A 02 3/2009 English Article no. 0710240/0710280 Art. no. 0710240 Cable reel spring driven 12mtr Art. no. 0710280 Cable reel spring driven 12mtr with heater...
-
Page 2: Table Of Contents
• The equipment must be assembled as shown in this manual. • If there have been alterations or changes to this equipment that have not been specifically approved by Orlaco, use of this equipment is not permitted. Before you start using this equipment, please read this manual carefully 1310850 and follow all instructions. -
Page 3: General
Installation Manual 1. General Before you put the equipment to use, you should familiarise yourself with it first. Technical specifications Cable reel spring driven Use: Video signal transmission on forklifts Reel length: 15 metres (incl. reserve) Initial tension: 7 rotations Winding cable: 9.0 mm Speed:... -
Page 4: Assembly
Installation Manual 3. Assembly ∅9 (4x) ∅9 (4x) To ensure that the cable drum provides optimal service after assembly, the following assembly instructions must be observed: The spring cable drum is mounted using one round flange (Fig. 1) and four screws. The mounting areas must not be uneven and must be clean. The winding drum must be attached horizontally and the cable must be mounted vertically at the centre of the winding area. -
Page 5: Commissioning
Installation Manual When fastening the cable to the fork carriage (to the camera), the following must be observed: A swivelling bracket (included in delivery) must be assembled to the fork carriage (fixed part); this bracket must be able to maintain its position without the aid of the side shift, if present. -
Page 6: Faults And Causes
Installation Manual Caution Under no circumstances should cleaning sprays or contact sprays be used! Check the contact brushes for wear and replace if necessary. Clean off any settled dust or abrasion from the slip-ring element. Check the ring surface and polish if necessary. Check all wires are firmly connected and look for insulation damage. -
Page 7: Electrical Connections
Orlaco. This also applies to the associated drawings and figures. Orlaco reserves the right to make changes to components at any time without informing customers beforehand or directly. All dimensions given are for commercial purposes. - Page 8 ORLACO Orlaco is a Manufacturing company that specializes in making cameras and monitor systems for commercial vehicles, fork-lift trucks, cranes, off shore and maritime. Our objective is to design and produce camera systems for the profes- sional market that improve the drivers view and increase operating efficiency.
