- Page 1 5G IP Camera User Manual Document Version Pages 5G IP Camera User Manual V1.1.0 5G IP Camera XTEE50216 User Manual Provided by Xingtera Inc. Santa Clara USA Qualcomm Smart City Accelerator Program Member...
- Page 2 5G IP Camera User Manual FCC statements: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
5G IP Camera User Manual CONTENT Chapter 1 Brief Introduction of Product ..............1 General ........................1 Word Definition ......................2 Chapter 2 IP Camera System ..................3 Features ........................... 3 2.1.1 Network ............................. 3 2.1.2 System ............................3 2.1.3 External Interface ........................ - Page 4 5G IP Camera User Manual 4.1.11 4G/5G Configuration ......................22 4.1.12 Cloud Platform Configuration ....................22 4.1.13 SMTP ............................ 23 4.1.14 RTMP Configuration ......................24 4.1.15 Device Upgrade ........................24 Video Stream RTSP Connection ..................25...
-
Page 5: Chapter 1 Brief Introduction Of Product
5G IP Camera User Manual Chapter 1 Brief Introduction of Product 1.1 General IP Camera series provides a comprehensive range of security and surveillance solution to meet users’ requirement. The cameras can be set up in a network and controlled or managed locally and remotely. -
Page 6: Word Definition
5G IP Camera User Manual 1.2 Word Definition Word Explanation IP Camera Advanced Video Coding (MPEG-4 AVC) is a block-oriented H.264 motion-compensation-based video compression standard. High Efficiency Video Coding(HEVC), also known as H.265 and MPEG-H Part 2, is a video compression H.265 standard, designed as a successor to the widely used AVC (H.264 or MPEG-4 Part 10). -
Page 7: Chapter 2 Ip Camera System
5G IP Camera User Manual Chapter 2 IP Camera System 2.1 Features 2.1.1 Network ❖ Ethernet: 1*RJ45 10M/100M Ethernet Port ❖ Network Storage: NFS、CIFS/SMB ❖ Protocol: IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP Audio 2.1.2 System Service Management... -
Page 8: Other Web Functions
5G IP Camera User Manual ❖ Remote web server device management cloud platform for user to do remote status monitoring, configuration and update, etc. 2.1.5 Other Web Functions ❖ Local web server for device configuration, system maintenance, storage management, video monitoring, etc. ❖... -
Page 9: Chapter 3 Operating Environment
5G IP Camera User Manual Chapter 3 Operating Environment 3.1 Computer requirement ❖ Recommended Windows 8 and above. ❖ IE 11 or above. 3.2 Connection 3.2.1 Equipment power supply IP camera supports PoE power supply and DC 9-60V wide voltage power supply. Users can choose one of the power supply modes to power the equipment. - Page 10 5G IP Camera User Manual ⚫ Terminal Interface: When the device is normally powered on, the infrared light at the front of the camera will flash quickly, and there will be a slight clicking sound inside the lens. At the same time, when the back cover is opened, it can be seen that there are lights inside.
-
Page 11: Network Connection
5G IP Camera User Manual 3.2.2 Network connection The camera can be connected to the computer for debugging and configuration in the following ways: 1. Direct computer connection 2. Connect through a switch or router 3.2.3 Access to devices Factory default configuration page address of IPC is http://192.168.1.100. Default user name is admin, the password is admin. - Page 12 5G IP Camera User Manual 2. Modify IPv4. 5G IP Camera Page 8 of 25...
-
Page 13: Device Login
5G IP Camera User Manual 3. Set the COMPUTER IP to any address in 192.168.1.x network segment. 4. Try to access the IP camera configuration web page http://192.168.1.100 from Internet Explorer. 3.2.4 Device login 1. Open IE browser (IE 8.0 or above) and enter the IP address of IPC. 2. - Page 14 5G IP Camera User Manual 2. The user needs to install the video plug-in when the user login to IE for the first time. Click and download the video player plug-in. 3. After finish downloading, install the video plug-in. 4. After finish installing the video plug-in, refresh the IE. Users can check real-time video monitoring on IE and user can operate different functions of IPC on this web interface.
-
Page 15: Chapter 4 Main Function
5G IP Camera User Manual Chapter 4 Main Function 4.1 Local Web Management Portal We recommend using Windows Internet Explorer to get the best user experience. You may require installing some plug-ins before you use the web portal. 4.1.1 Login The default login credential is printed on a tag on your camera. -
Page 16: Configuration
5G IP Camera User Manual 4.1.2 Configuration Click the ‘Configuration’ tab on the top menu, user can manage the IPC from the following page. The side menu has list out all the items that user can configure. User can do detail configuration on the right side of the side menu after clicking the related item. -
Page 17: Video Setting
5G IP Camera User Manual 4.1.4 Video Setting Support video configuration, including Stream Type, Video Format, Resolution, Quality, Time, Bit Rate, CBR/VBR Type, etc. 4.1.5 Real-time Video Real-time video is supported in IPC web interface and user can control the IPC remotely at the same time. - Page 18 5G IP Camera User Manual 2. Click preview option on the top of the menu. At the lower right corner, user can remote control IPC such as play/stop live video, snapshots, video recording. Some cameras can support lens zoom, focus and other features. 3.
- Page 19 5G IP Camera User Manual 4. User can setting the record video storage path on the IPC web interface. 5G IP Camera Page 15 of 25...
- Page 20 5G IP Camera User Manual Buttons of image setting: Button Description Primary stream Secondary stream Window size Real size Full scream size Protocol setting Play Stop Snapshot Brightness Contrast Sharpness Noise reduction level Default Video recording Saturation 5G IP Camera Page 16 of 25...
- Page 21 5G IP Camera User Manual Buttons of IPC remote control: Button Description configuration Zoom in Zoom out Focus increase Focus reduce Iris increase Iris reduce Focus speed Lens initialization Auxiliary focus Auto iris 5G IP Camera Page 17 of 25...
-
Page 22: Video Playback
5G IP Camera User Manual 4.1.6 Video Playback The IPC web interface supports video playback function. User can use the IPC web interface to play the recorded video from the IPC storage directly. You may require to install plug-ins before you use this function. Processes: 1. -
Page 23: Video Record Schedule
5G IP Camera User Manual 4.1.7 Video Record Schedule User can set the recording schedule so that the IP camera can record automatically at regular intervals. Processes: 1. Click the configuration on the top of menu. 2. Select the storage option on the left side. 3. -
Page 24: Alarm
5G IP Camera User Manual 4.1.8 Alarm The product supports various event alarm functions, by setting up some trigger conditions and the related actions to inform user to check and take action. 4.1.9 Storage Configuration The product support storage management, storage configuration, file search, scheduled recording, scheduled image capture, etc. -
Page 25: Network Configuration
5G IP Camera User Manual 4.1.10 Network Configuration The communication port used by the device to transmit data can be configured on the port setting page. The default port numbers used by http/https/rtsp are 80/443/554. If you want to use RTSP to connect, please try to fill in the target address in the following format, rtsp://user:pass@192.168.1.100:554/main (user:pass needs to be replaced with the username and password of the system. -
Page 26: 5G Configuration
ID. (The cloud server address and server port may change by the customer’s local server and local port) Notice: This Cloud Platform Configuration is just for Xingtera private cloud platform. 5G IP Camera Page 22 of 25... -
Page 27: Smtp
5G IP Camera User Manual 4.1.13 SMTP 5G IP Camera Page 23 of 25... -
Page 28: Rtmp Configuration
5G IP Camera User Manual 4.1.14 RTMP Configuration 1. Setup RTMP client related parameters, include IP Address / Port / Stream Name / Stream Path. Click Enable and then save configuration. 2. The current connection status of RTMP can be displayed on the current page. 4.1.15 Device Upgrade 3. -
Page 29: Video Stream Rtsp Connection
5G IP Camera User Manual 4.2 Video Stream RTSP Connection IPC system provides RTSP protocol to streaming video through network. By typing the RTSP address and port, verify the username and password, user will be able to watch the real-time video streaming on web page, VLC or network video players. If you want to use RTSP to connect, please try to fill in the target address in the following format, rtsp://user:pass@192.168.1.100:554/main...
