Colours may vary
Electric Golf Buggy – E4000 & E4000S
User Manual
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by
this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
THE BATTERY MAY HAVE SOME CHARGE ON ARRIVAL, IT IS IMPORTANT
HOWEVER THAT THE BATTERY IS CHARGED PRIOR TO USE.
E&OE
© 2020 Thomson
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for THOMSON E4000
Summary of Contents for THOMSON E4000
- Page 1 Colours may vary Electric Golf Buggy – E4000 & E4000S User Manual READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
-
Page 2: Safety
Electric Golf Buggy – E4000 & E4000S Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols:... - Page 3 Electric Golf Buggy – E4000 & E4000S General Electrical Safety General Electrical Safety General Service Information • Inspect electrical equipment, extension • Electrically grounded equipment must • The equipment must be serviced or cords, power bars, and electrical fittings have an approved cord and plug and repaired at authorised service centres for damage or wear before each use.
-
Page 4: Safety Symbols
Electric Golf Buggy – E4000 & E4000S Safety Symbols The product may have safety warning labels attached to it, explained below. Understand the symbols on your product and their meanings. If any stickers become unreadable, unattached etc, replace them. Flammable Material Hazard... - Page 5 Electric Golf Buggy – E4000 & E4000S Carbon-Monoxide Hazard Pull Hazard Slope / Fall Injury Hazard "Slam Dunk" Warning Do not use the product in Be aware that the product Be aware that using the Do NOT attempt "slam dunk"...
-
Page 6: Table Of Contents
Electric Golf Buggy – E4000 & E4000S Table of Contents Safety ............................. 2 Safety Symbols ............................4 Parts Identification ........................7 Assembly and Setup ........................8 Operation ............................. 10 Handle Control Functions ........................... 10 Timer and Distance Functions ......................10 Cruising and Braking Functions ...................... -
Page 7: Parts Identification
Electric Golf Buggy – E4000 & E4000S Parts Identification Name Name Speed knob Lower bag strap Upper holder Front wheel Upper bag strap Upper holding fixed knob Battery Handle IC Controller Rear wheel Battery plug Wheel hub cap Front wheel Adjust bolt... -
Page 8: Assembly And Setup
Electric Golf Buggy – E4000 & E4000S Assembly and Setup 1. Identify the Left and Right wheels by locating the L and R sticker on the inside of the wheels. To identify which side to place the wheels, stand behind the buggy, the right wheel is needs to be installed on your right and the left on your left. - Page 9 Electric Golf Buggy – E4000 & E4000S 4. Place the battery pack (F) on the battery tray (G) and fasten the hook and eye strap (H) around the battery and fasten it tightly. Ensure that the power switch on the caddy handle is off. Insert the battery plug (I) into the golf buggy’s outlet (J).
-
Page 10: Operation
Electric Golf Buggy – E4000 & E4000S Operation Handle Control Functions Timer and Distance Functions Press once. • The golf buggy will automatically move forward by 10m and will stop by itself afterwards. Press twice. • The golf buggy will automatically move forward by 20m and will stop by itself afterwards. -
Page 11: Operating Your Golf Buggy
Electric Golf Buggy – E4000 & E4000S Operating your Golf Buggy 1. To turn the golf buggy ON, hold down the ON/OFF button for about 2 seconds. The battery charge LED should light up. A battery indicator with green or red colour LEDs on the handle shows the battery charge at any time. -
Page 12: Lead-Acid Battery Care And Maintenance
Electric Golf Buggy – E4000 & E4000S Lead-Acid Battery Care and Maintenance Top 2 Battery Care Requirements 1. Charge battery before first use. The battery may arrive with some charge, regardless of this the battery must be charged for 12 hours on the initial charge and 5 – 12 for each subsequent charge. -
Page 13: Maintenance
Electric Golf Buggy – E4000 & E4000S Maintenance The steps below will ensure that you get a prolonged and reliable life out of your golf buggy. • The golf buggy has been designed so that the user can concentrate on playing golf, while the golf buggy does the work of carrying your bag. -
Page 14: Troubleshooting
Electric Golf Buggy – E4000 & E4000S Troubleshooting Symptoms Resolutions ◼ Check the fuse in the battery case. ◼ Check all wiring connections and plugs. Golf buggy does not have any power. ◼ Check if the battery has any charge left. -
Page 15: Specifications
Electric Golf Buggy – E4000 & E4000S Specifications E4000 Model E4000 Material Aluminum alloy Motor power 250W Max speed 8km/h Max load capacity 30kg Distance per charge 20 km Battery 12V, 33Ah Charger 240V AC (input), DC 12V Power Plug... - Page 16 ©2019 Thomson. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,...
