- Page 1 U33I U S E R M A N U A L WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier.
- Page 2 Safety Precautions Retain this manual for future reference. WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other appliance.
- Page 3 Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “URBANA” APPLIANCE, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • Installation and service must be performed by a qualified installer, • All Urbana gas-fired appliances must be installed in accordance with service agency or gas supplier. their instructions.
-
Page 4: Safety Precautions
Safety Precautions Power Vent ONLY: This type is identified by the suffix PV. This appliance draws all of its air for combustion from outside the dwelling, through a specially designed vent pipe system. This appliance has been tested and approved for installations from 0 feet to 4500 feet (1372 m) above sea level. In the USA: The appliance may be installed at higher altitudes. -
Page 5: Table Of Contents
CONTENTS Contents Safety Precautions ........4 Operating Instructions . -
Page 6: Operating Instructions
Operating Instructions Remote Control The Proflame 2 uses a streamline design, remote control to allow the user to interact with the system. The simple button layout and LCD display offers a user friendly CAUTION! experience. The MODE key is used to cycle through different features. -
Page 7: Syncing Your Remote To The Fireplace
Operating Instructions Temperature Unit Setting Remote Syncing Your remote can be set to either read °C or °F. To Sync the Remote to the unit. To set your preferred unit: Remove the screen Press the Thermostat key and the Mode key simultaneously while the On the right hand side, locate the reset switch system is OFF. -
Page 8: Pilot Light Modes
Operating Instructions Turning On Your Fireplace Pilot Light Modes Press the ON/OFF Key on the remote; the LCD display will Your fireplace has a pilot light which ignites the main show the room temperature. burner. The way in which your pilot light functions can be A single “beep”... -
Page 9: Flame Height Control
Operating Instructions Top Light Flame Height Control Your fireplace comes with top lights that illuminate the inside of the firebox. (All Urbana Series models come with Your fireplace has 6 flame height settings. To control the top lights as a standard. ) height of the flame: To turn on your top light: Turn on your fireplace;... -
Page 10: Parts Diagram
Parts List 50-4400 U33/U33T Burner only 50-4399 U33T Baffle 50-4401 U33/U33T PEM bracket 50-4319 U33T Safety Screen 50-4164 U33 Glass 50-4402 U33/U33T Glass Bumper Set (L & r) # 50-3887 IFC Urbana #50-3888 - PF2 WiFi Ready #50-2682 - SIT 885 VALVE W/ Transmitter STEPPER MOTOR (NG) #50-3892 - Urbana Rocker... -
Page 11: Parts List
Parts List 50-4408- Power vent Rheostat 50-4464- Horizontal Liner - Rear 50-4463 Horizontal liner - side Assembly #50-4279 - Glass hand knob #50-3837 - SUCTION cup (metal) HANDLE (1 PC) Gaskets Part numbers U33T Firebox Braided Gasket single side #50-4409 U33/U33T Control panel Gasket #50-4410 U33/U33T Bulkhead Gasket... - Page 12 Move closer to fireplace & try again. (listen for acknowledgement beeps) Check batteries in remote. “Nothing happenes when I turn on the fireplace Re-sync the remote to the fireplace. with the remote.” Check burner switch is in the on position. Call Your dealer to arrange a service call.
-
Page 13: Troubleshooting
Troubleshooting | 13... -
Page 14: Installation Reference Guide
Installation Reference Guide Please fill in and retain this information card for your future reference. Go to www. enviro.com/warranty to fill in your warranty registration card. NAME OF DEALER: NAME OF INSTALLER: _________________________________________ _________________________________________ ADDRESS: ADDRESS: _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________... -
Page 15: Warranty Information
In the event of a defect of material or workmanship during the specified warranty period, Damage as a result of improper usage or abuse. Sherwood reserves the right to make repairs or to assess the replacement of a defective product at Sherwood’s factory. The shipping costs are to be paid by the consumer.
