Summary of Contents for FoundationLogic Innovation ElphaPex DG 1
- Page 1 DG 1 Server Manual DG 1 Server Manual Version 1.0.1 March 2024...
- Page 2 COPYRIGHT © Copyright FoundationLogic Innovation Corp 2024. All rights reserved. ElphaPex brand by FoundationLogic Innovation Corp (hereinafter referred to as 'ElphaPex') reserves the right to make revisions, enhancements, modifications, improvements, and other adjustments to their products and services at any given time, as well as to discontinue any product or service without prior notice.
- Page 3 Kindly note that the entire content aims to elucidate product specifications and parameters. The description content within the text or illustrations may vary depending on the accessory manufacturer, batch, or origin. The content serves solely for illustrative and parameter testing purposes and cannot be considered the sole standard for product evaluation. Customers should fully comprehend that parameters or indicators that do not impact the expected benefits of the product may exhibit slight deviations due to production conditions and tolerances.
- Page 4 Index 1.Overview 1.1 Server Components 1.2 Specifications 2.ElphaPexTool Guide 3.Server Configuration 3.1 Pool Configuration 4.Server Monitoring 5.Server Management 5.1 Firmware Version Check 5.2 System Upgrade 5.3 Password Change 5.4 Restoring Initial Settings Regulations...
-
Page 5: Server Components
Overview The DG 1 Server is the latest machine launched by ElphaPex with Scrypt algorithm, which consists of a central hash boards box, four fans, a power supply and a main control box. All DG 1 Servers are tested and configured prior to shipping to ensure easy set up. Front View Back View Notes:... - Page 6 Controller Board Interface: FP-101 Power Supply:...
-
Page 7: Specifications
Notes: ￮ Power supply FP-101 is part of DG 1 server. For detailed info, please refer to the specifications below. Specifications Version: 1.0 Model No.: DG 1 Product Glance Value Version Model DG 1 Crypto Algorithm/Coins Scrypt Hashrate, MH/s 11000 ± 3% 3420 ±... - Page 8 Power supply AC Input current, Amp Hardware Configuration Network connection mode RJ45 Ethernet 10/100M Server Size (Length*Width*Height, w/o 369.3*196*287 package), mm Server Size (Length*Width*Height, with 480*289*387 package), mm Net weight, kg 16.1 Gross weight, kg 17.4 Environment Requirements Operation temperature, °C 0~40 Storage temperature, °C -20~70...
- Page 9 Get software pack ElphaPexTool from www.elphapex.com Notes: ￮ ElphaPexTool is now only available on Windows platforms. Extract the file. Open the software ElphaPexTool.exe and click on 【+】, Add the corresponding network segment range Press the Scan button. The information about servers in the current network segment is displayed in a list.
- Page 10 Double-click the selected line, this will open the browser to the server's web page. Proceed to login using root for both the username and password. In the IP section, you can assign a Static IP address (optional). Enter the IP address, Subnet mask, gateway and DNS Server. Click SAVE button.
-
Page 11: Server Monitoring
Notes: ￮ Note that please DO NOT adjust the fan speed by yourself although it can be configured. The server itself will tune the fan speed automatically going along with the environment temperature changes. Set the options according to the following table: Option Description Mining Address... - Page 12 Notes: ￮ ℃ When the temperature of the outlet reaches 85 , the temperature control policy of the DG 1 server will activate the high temperature protection and the mining process will stop Monitor your server according to the descriptions in the following table: Option Description chipNum...
-
Page 13: Server Management
Server Management Firmware Version Check Enter the backstage web site of your server, find the firmware version on the bottom. firmwareVersion displays the current release version your server uses. In the examples below, the server is using firmware version: DG1_SW_V1.0.0 System Update Notes: ￮... -
Page 14: Password Change
When the update process is completed, the server will restart, and it will turn to the Dashboard page. Password Change In Web site page, click Password. Enter the current password and the new password, then click SAVE. Restoring Initial Settings Notes: ￮... - Page 15 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1). This device may not cause harmful interference. (2). This device must accept any interference received, including interference that may cause undesired operation. CAN ICES-003(A) / NMB-003(A) Note: This equipment has been tested and found to comply with the limits for a Class A digital...
