Installation Instructions
Thank you for purchasing the WeatherTech
thoroughly familiarize yourself with the steps to install the MudFlap on your vehicle. When properly installed,
the WeatherTech
No-Drill MudFlap will provide you with years of protection.
®
Allen Wrench
Hardware Included
Your MudFlap kit includes an Allen Wrench
and the plastic push rivets pictured here.
1
1
Start by thoroughly washing your vehicle. Take
care to remove all dirt, debris, and stains from
each fender in the areas corresponding to where
the MudFlaps will be installed.
3
3
Unlocked Position
Identify the driver's side MudFlap by locating the
"LH" mark located centrally in the recessed
cavity on the tire side of the MudFlap. Ensure that the
QuickTurn
fasteners are in the fully unlocked posi-
tion using the Allen wrench provided.
MudFlap
No-Drill MudFlap. Please read this installation guide to
®
Plastic
Rivets
WARNING!
The MudFlap is designed to
fit vehicles with standard size
wheels and tires. Installation
of mud flaps on vehicles with
aftermarket wheels or oversize
tires may interfere with the
MudFlap and will void the
warranty and may damage the
MudFlap or the vehicle.
2
2
Begin driver's side MudFlap installation by
parking the vehicle on level ground. Begin with
the left side.
4
4
Unlocked Position
Position the smooth surfaced portion of the MudFlap so
that it contours firmly against the fender as shown.
IMPORTANT - Ensure that the QuickTurn
remains in the fully unlocked position during this step.
fasteners

Advertisement

loading
Need help?

Need help?

Do you have a question about the No-Drill MudFlap and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WeatherTech No-Drill MudFlap

  • Page 1 No-Drill MudFlap. Please read this installation guide to ® thoroughly familiarize yourself with the steps to install the MudFlap on your vehicle. When properly installed, the WeatherTech No-Drill MudFlap will provide you with years of protection. ® WARNING! Allen Wrench The MudFlap is designed to fit vehicles with standard size...
  • Page 2 Insert the pin into the base and press firmly to secure the rivet. Congratulations! Begin passenger side installation by parking the vehicle on a level surface. Your new WeatherTech No-Drill MudFlaps ® Repeat steps 3-7. have been installed!
