Summary of Contents for Blair BFD-KX+ Series
- Page 1 OPERATOR’S MANUAL BFD-KX+ SERIES PORTABLE MAGNETIC DRILL Covers Drill Covers Drill Part Numbers: Part Numbers: 0140001 FOR USE WITH KARBON X+ CUTTERS OMBFD-KX+ Printed in U.S.A. 06/2024...
- Page 2 Welcome to Blair Congratulations on your purchase of the Blair Portable Magnetic Drill. Your model is designed to produce superior holes quickly and ef- ficiently. Through constant innovation and development, Blair is committed to provide you with hole producing tools and products to help you be more productive.
-
Page 3: Electrical Safety
WARNING Cutters are sharp. Wear To prevent electric Do not stare at Always wear eye The slug is ejected at gloves when installing shock, do not use operating light. protection while using the end of the cut. Do or removing cutter from power tools near wet cutting tools, or in the not aim cutter or arbor... -
Page 4: Important Safety Instructions
fire and/or serious personal injury. h) Keep handles and grasping surfaces, clean and Do not use Blair Cutters where ejected slug might cause Important Safety Instructions - Continued injury (slug ejected at end of cut). Also, adhere to all free from oil and grease. - Page 5 OPERATING INSTRUCTIONS 6. Feed Cutter slowly into workpiece. Only after cutting 1. Place drill on material (at least 3/8" thick) and path is established to a depth of about 1/16" can locate for drilling hole. additional force be applied to feed handles. Ease up on feed pressure as cutter starts 2.
-
Page 6: Safety Switch
SAFETY SWITCH NOTE: The Safety Switch located in the base of the unit shuts off the motor when the unit lifts. The magnet will stay engaged until you turn off the magnet. It is important to keep this area clean and free from chips. Periodically check this switch for proper function and if for some reason it is not working properly, send the unit to an authorized repair center for service. -
Page 7: Control Panel Assembly
CONTROL PANEL ASSEMBLY 08836 Control Panel Assembly Item Part # Description 08829 Faceplate 90571 Power Cord Assy 08831 Guard - Switch 08832 Switch - Motor On 08834 Cover - Switch Green 08833 Switch - Motor Off 08835 Cover - Switch Red 08830 Switch - Rocker, Illuminated 04879... - Page 10 BFD-KX+ PARTS LIST Item # Part # Description Item# Part # Description 20115 Drill Housing & Label Assy 17475 Ring - Retaining 12mm shaft 20120 Gear Box Cap 08453 Ring - Retaining, Int 1.259 Bore 08428 Gear Box Cover 04718 SCR PAN HD #4-40 x 3/8 LG 20125 Motor Housing Assy...
- Page 11 CUTTERS FOR THE BFD-KX+ KARBON X+ CUTTERS The Karbon X+ cutters are made specifically for the BFD-KX+. They are equipped with 5/8" tool-less Bayonet-style twist and lock shank, 1" D.O.C. stack cut cutter. They are made of premium M42 high speed steel and available in diameters from 7/16"...
-
Page 12: Commercial / Industrial Limited Warranty
COMMERCIAL / INDUSTRIAL LIMITED WARRANTY Blair Equipment Company warrants its Portable Magnetic Drills and Tornado II Paint Shakers for two (2) years and other products for ninety (90) days from date of purchase against defects due to faulty material or workmanship and will repair or replace (at its option) without charge any items returned.
