Summary of Contents for goliath BASIC LINE

Page 1 INSTRUCTION BASIC LINE...
Page 2 Quick Start Guide......................3 Indoor stations......................4 Compact front-door station..................6 Circuit diagrams......................10 Wiring........................13 Example configuration indoor and outdoor station..........20 Configuration front-door station..................42 Mobile phone app....................43 General DIP switch settings.................... 51...
Page 3 ● Wire all devices as described in the wiring diagrams (page 10 ff.) ● Wait until the door intercom system is fully raised...
Page 4 Alarm connections SD card slot (up to 64GB) 130.0 mm 189.0 mm...
Page 5 20.0 mm 119.3 mm...
Page 8 Mounting surface-mounted housing Installation recommendation The recommended installation height of the outdoor station is 1.50 - 1.60 metres. The height of the lens is important here.
Page 9 Installation recommendation Flush-mounted housing The recommended installation height of the outdoor station is 1.50 - 1.60 metres. installation The height of the lens is important here. 123.0 123.0 mm 35.0 35.0 mm 32.5 104.0 mm 32.5 mm 104.0...
Page 11 Goliath Basic Line suppressor Goliath Basic Line distributor Goliath Basic Line 2 wire module...
Page 12 Goliath Basic Line suppressor Goliath Basic Line distributor Goliath Basic Line distributor Goliath Basic Line 2 wire module 2Wire ALARM LOCK D O O R _ N...
Page 13: Wire Information
Cabling Important notes: • Do not put the system into operation until everything has been wired correctly as shown in the wiring diagram. • Do not apply any additional power to the indoor stations (monitors) or door station. This will lead to a defect. As soon as the system has been correctly wired, the indoor stations (monitors) should start up after one to two minutes, as should the door station.
Page 14 Note: The Goliath video door intercom has already been prepared for use before despatch. This means that your video door intercom should be ready for immediate use without any further adjustments. If you still encounter problems, you will find instructions here on how to make the necessary configurations.
Page 15 Configuration 1x indoor station and 1x door station DIP switch indoor station Indoor station settings DIP switch door station Click on Set the DIP- "Add" to assign a name Switch 1 to the Switch DIP switch 1 to the ON to the door station and ON position position (top).
Page 16 DIP switch indoor station 1 Indoor station settings DIP switch door station...
Page 17 Click on "Add" to assign a name to Set DIP switch 1 to Switch DIP switch 1 to the ON the door station and set the ON position (up). position (top). the ID to 1. DIP switch indoor station 2 Indoor station settings Switch DIP switch 1 and DIP Click on "Add"...
Page 18 DIP switch indoor station 2 Indoor station settings Switch DIP switch 1 and DIP Click on "Add" to give the door switch 16 to the ON position station a name. (top). and set the ID to 1. DIP switch indoor station 3 Indoor station settings Switch DIP switch 1 and DIP Click on "Add"...
Page 19 Click on Click on "Add" to assign a name "Add" to assign a Switch DIP switch 1 to the ON to the door station and name to the door position (top). set the ID to 1. station and set the ID to 2...
Page 20 DIP switch door station 1 DIP switch door station 2 Set DIP switch 1 to the ON Set DIP switch 2 to the ON position (up). position (up). Configuration 2x indoor station and 2x door station Indoor station Indoor station settings settings for DIP switch indoor station 1 for door station 1...
Page 21: Call Screen
Call screen Symbol Description of the Open the door that is directly connected to the door station. Open the door that is connected to the AV-VTZ16 access module. Take a snapshot Note: This is only possible if an SD card is inserted in the indoor station Start a video recording Note: This is only possible if an SD card is inserted in the...
Page 23: Start Screen
Start screen Designation Description of the Main If this symbol is not displayed, this means that the indoor indoor station station is an extension. • Display, delete individual or complete list • If an SD card is inserted, 3 additional tabs are Info displayed: Alarm, Guest message and Video image •...
Page 24 Symbol with exclamation mark: Cloud One of two cases has occurred: connection • The indoor station is not connected to the WLAN • The cloud function is deactivated Date & time • Display of unread alarm information • Arming and disarming - There are 4 modes Home, Arming / Away, Quiet and Customised disarmin...
Page 25 DMSS You can initiate a call from the indoor station to all smartphones connected to the indoor station. All smartphones ring simultaneously, but only one user can answer the call. To do this, open the DMSS app and tap the icon in the centre of the screen. During a call, you have the option of either ending the call using the red button or muting the sound using the loudspeaker symbol.
Page 26 Info Display and edit alarm information, guest messages and video images Alarm After an alarm is triggered, an alarm sounds at the indoor station for 15 seconds. Information about the alarm is saved in the list under Alarm. You can either display all alarms or only unread alarm information. You can delete individual alarm notifications via Edit.
Page 27 Guest Messages (Guest Msg) This tab only appears if you have inserted an SD card in the indoor station. If an SD card is inserted, visitors can leave a video message after the ringing time has elapsed. You can either display all messages ("All") or only new messages ("Unread"). You can delete individual guest messages via Edit.
Page 28 VTO (Door) You can use the monitoring function to view live images from connected door stations or HDCVI cameras. Add door station: Press "Add" and enter the ID of the door station and assign a name. Press OK to save the setting. Remove the door station: Press the "Edit"...
Page 29: Monitor Door Station
Monitor door station Select Monitor → VTO and press Play. The image of the selected door station is displayed. Symbol Description of the Open the door that is directly connected to the door station Open the door that is connected to the AV-VTZ16 access module Take a snapshot Note: This is only possible if an SD card is inserted in the indoor station...
Page 31 Camera Up to two Goliath HDCVI cameras can be connected. The maximum resolution is 2 megapixels. Additional components such as plugs may be required for the connection. In the "Camera" menu item, you have the option of opening the live image of the...
Page 32 Ring tone (ring) Set the ringing and alarm tones. You can make further settings, such as the ringing time, under Miscellaneous VTO ringing (VTO ring) • You can set different ringtones for individual door stations • There are 5 different ringtones to set the volume of the ringing.
Page 33 Alarm tone (Alarm ring) Under Alarm tone, you can choose between two alarm tones. Note: This function is only used if wired alarm indicators are connected to the indoor station to set the volume of the ringing. Go to the next or previous page with to go to the next or previous page.
Page 34: Other (Other)
Other (Other) Set the ring time, microphone and voice volume. You can also mute the ringtone. Note: The minimum setting for the ringing time is 5 seconds About to adjust the volume for the microphone and speech...
Page 35: Alarm Settings (Alarm)
Alarm settings (Alarm) Wired zone (Wired Zome) You can set the detector type, NO/NC, the alarm status and the input and output delay Designation Explanation Zone Cannot be changed Specify which type of detector is connected to this zone. For example: Kind Infrared motion detector, smoke detector, door contact, etc.
Page 36: Alarm Mode
Output After activating the alarm output, the indoor station emits a signal when the doorbell rings at the door station. If you connect an electronic chime to the NO and COM connections of the indoor station, it will ring in addition to the indoor station. Alarm mode Set the on/off status of the range for different modes.
Page 37 Time (Time) Set the time. Time zone and NTP (Network Time Protocol) time protocol). You can also configure the DND mode here. Notes: To use the NTP function, the indoor station must be connected to your router via WLAN. The indoor station then automatically sets the time If the NTP function is switched off, you can set the time yourself Set the time zone in Germany to GMT + 1 for winter time and GMT +2 for summer time Configure DND mode...
Page 38 Display Brightness: The brightness of the VTH screen. If the screen display is brighter or darker than expected, you can adjust the brightness by tapping + or -. Screen switch-off time (Screenclose Time): The screen will automatically switch off when it reaches the idle time limit. If this is longer or shorter than your expected time, you can adjust the time by tapping + or Clean (Clean): Tap the icon and the screen will lock for 30 seconds.
Page 39 Other (Other) Designation Explanation Maximum time to monitor the door station or connected cameras. Display After the time has elapsed, you must open the camera or door time (in station again. sec.) Maximum recording time of the door station or a camera. Example: If the Record time time is set to 300 seconds, a maximum of this time can be recorded in one go.
Page 40 Touch sound Switch the touch sound on or off...
Page 41: Wireless (Wlan)
Wireless (WLAN) Go to Settings → Wireless (WLAN) Step 1: Activate the WLAN function Step 2: Select your network and enter your WLAN password Wireless IP (Wireless IP) Once the WLAN has been switched on and connected, you can specify an IP address here.
Page 42 password User PWD (User PWD) The user password is for arming and disarming the alarm indicator. The default password here is 123456. To change the password, enter the old password, then the new password and confirm it. Network PWD (Network PWD) The network password is used when you connect the indoor station to the DMSS app.
Page 43 Step 2: Set a password and confirm it. If you wish, you can also enter an e-mail address in case you forget the password and want to reset it. Step 3: Save the password with OK. After the network password has been created, the indoor station automatically generates a code under Settings →...
Page 44 Local info (Product Info) Here you can restart the indoor station, reset it to the factory settings and format or remove the SD card. Explanation Restart the indoor station Reset the indoor station to factory settings Format the SD card Remove the SD card.
Page 45: Arming And Disarming
Arming and disarming This is only used if wired alarm indicators are connected to the indoor station. Arming If an alarm is triggered after arming, an alarm with a link is generated and the alarm information is uploaded. Make sure that the area has been added to the arming mode. •...
Page 46 Disarming Step 1 In arming mode, tap Step 2 Enter the disarming password in the "In Disarm mode" and then tap OK. The default password for arming and disarming is 123456. If you want to change the password, you can find more information under Password.
Page 47 Configuration Front-door station Set door opener time To set the opening time of your door opener to 2 seconds, switch DIP switches 5 and 6 to the OFF position (down). To set the opening time of your door opener to 4 seconds, switch DIP switch 5 to ON (up) and 6 to the OFF position (down).
Page 48 Step 1: Download the app and create an account Visit the Google Play Store or the Apple App Store and search for the "DMSS" app. Download the application and open it. After successfully starting the app, you will be asked for authorisations the first time you open it.
Page 49 A 6-digit verification code has been Please enter your e-mail address and set a sent to your e-mail address. Please password. Make sure that you agree to the enter this code and confirm terms of use and with "OK". Agree to the privacy policy. Registration has now been successfully Then click on completed.
Page 50 Step 2: Connect the indoor station to the Wi-Fi and generate the QR code 1. Go to Settings → Wireless (WLAN) 2. Activate the WLAN function 3. Select your network and enter your WLAN password Wireless IP (Wireless IP) Once the WLAN has been switched on and connected, you can enter a Set IP address.
Page 51 password Go to "Settings → Password → Network PWD (Network PWD) and activate the cloud function there Set a password and confirm it. If you wish, you can also enter an e-mail address in case you forget the password and want to reset it. Save the password with OK.
Page 52 If no network password has been created, no code is displayed under QR code. Go to Settings → QR code. Open the app and tap the plus symbol in Now scan the QR code on the the top right-hand corner. Then select indoor station.
Page 53 The serial number and other information about Now select the type of device you the indoor station are now transferred. Then go want to add: " VTH" to "Next".
Page 54 Now enter the device name and your network The setup of your door intercom password. The user name is always "user". system is now complete. Then click on "Save".
Page 55 Device release Click on the icon at the top right Select "Device release".
Page 56 Either enter the e-mail address of the account for which you want to share the Scan the QR code of the user for whom intercom or click on the highlighted icon. you want to share the system.
Page 57 To display the QR code, go to the app of Scan the QR code with the main user's the user you want to add and click on "Me". mobile phone to add the device. Then click on You can add up to 6 additional devices the QR code symbol.
Page 58 General settings for the DIP switches of the door station: General DIP switch Pos. Function Description of the DIP 1 Configure door station addresses. Maximum 14 addresses. DIP 2 Please refer to the next table for the exact address settings. DIP 3 DIP 4 Opening time:...
Page 59 Opening time: 8 seconds ON: NTSC Mainly used in the USA, Canada and Japan DIP 7 Video format OFF: PAL Mainly used in Europe, China and Great Britain Nameplate Nameplate illumination is DIP 8 lighting switched on...
Page 60 A maximum of 14 addresses for door stations can be assigned via the DIP switches. be set Door station addresses Door station DIP switch position Rule Address DIP 1 ON DIP 2 ON DIP 1 ON + DIP 2 ON DIP 3 ON DIP 1 ON + DIP 3 ON DIP 2 ON + DIP 3 ON...
Page 61 DIP 2 ON + DIP 3 ON + DIP 4...
Page 62 Switch DIP switch no. Function Value • DIP 1 to DIP 12 are used to set the indoor station addresses • A maximum of 4094 different addresses can be set • In the following table you will find the most important Indoor station addresses...
Page 63 • DIP 1 to DIP 12 are used to set the indoor station addresses • A maximum of 4094 different addresses can be set 1024 • In the following table you will find the most important 2048 Indoor station addresses DIP 13 to ON if an HDCVI camera is connected via a UTP cable.
Page 64 Indoor station addresses Indoor DIP switch to DIP switch combination station Address DIP 1 DIP 2 DIP 1 + DIP 2 DIP 3 DIP 1 + DIP 3 DIP 2 + DIP 3 DIP 1+ DIP 2 + DIP 3 DIP 4 DIP 1 + DIP 4 DIP 2 + DIP 4...
