Important safety Information
•
SAVE THESE INSTRUCTIONS – This manual contains important safety and
operating instructions.
•
Before using this product, read all instructions and cautionary markings.
•
Use of an accessory outside of amp rating could result in fire, electric shock
or failure. Professional installation is highly recommended.
•
Avoid direct exposure to rain, moisture or snow.
•
Do not operate the Ghost Box if it damaged in any way - replace it immediately.
•
To reduce risk of damage or electric shock, disconnect the Ghost Box from
the vehicle battery before attempting any maintenance or cleaning. Turning
off controls will not reduce this risk.
info@projectxoffroad.com
(866) 294-9244
Mon-Sat 8am-5pm PST
Model No. GB538825
Advertisement
Table of Contents
Related Manuals for PROJECT X GHOST BOX
Summary of Contents for PROJECT X GHOST BOX
- Page 1 Model No. GB538825 Important safety Information • SAVE THESE INSTRUCTIONS – This manual contains important safety and operating instructions. • Before using this product, read all instructions and cautionary markings. • Use of an accessory outside of amp rating could result in fire, electric shock or failure. Professional installation is highly recommended. • Avoid direct exposure to rain, moisture or snow. • Do not operate the Ghost Box if it damaged in any way - replace it immediately. • To reduce risk of damage or electric shock, disconnect the Ghost Box from the vehicle battery before attempting any maintenance or cleaning. Turning off controls will not reduce this risk. info@projectxoffroad.com (866) 294-9244 Mon-Sat 8am-5pm PST...
-
Page 2: Technical Specifications
11.6V - 14.7V DC Output Maximum Current: 20A @12V DC (Channel 1) 40A @12V DC (Channel 2) Output Maximum Power: 480W @12V DC Operating Temp: -22°F to 149°F Storage Temp: -40°F to 185°F Waterproof Rating: IP65 Wireless Frequency: 2.4GHz RF WiFi & Bluetooth 5.0 Wireless Range (RF WiFi): 98.4 Feet (without interference or obstruction) Wireless Range (Bluetooth®): 33 Feet (without interference or obstruction) Replacement Fuse: 40A Max - Standard ATC Type The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by ADC Solutions Offroad & Adventure, LLC is under license. Other trademarks and trade names are those of their respective owners. INCLUDES GHOST BOX 2x Button Head Screws (L25) 2x M5 Lock Nuts 4x M5 Washers 2x External Antennas 1x 3M VHB™ Double Sided Tape 2x Large Rubber Caps (Spare) 2x Small Rubber Caps (Spare) 5x PROJECT X Stickers... -
Page 3: Installation
INSTALLATION • Insert the External Antennas to the Ghost Box. Mounting • Choose a suitable mounting location for the Ghost Box. Make sure the location is strong enough Button Head to mount the Ghost Box. Screw (L25) Option 1 - Mounting with screws M5 Washer • Mark two holes for a precise installation and make sure nothing beneath will be damaged by drilling. • Drill 2 pilot holes using a 13/64 inch drill bit. Maximum Torque • Line up the Ghost Box with the M5 Washer for M5 Lock Nut: pilot holes and secure with Button 18 in/lbs M5 Lock Nut Head Screws (L25), M5 Washers 1.5 ft/lbs and M5 Lock Nuts. 2.03 Nm NOTE: Do not exceed the maximum torque in order to avoid overtorque. Option 2 - Mounting with 3M VHB™... - Page 4 WIRING Cut the pointed head of the Rubber OPEN THE GHOST BOX Caps according to the thickness of the hardwire cable. Unscrew and open the lid of the Ghost Box. Remove the O Ring and the transparent Cut at on the Small Rubber Cab plastic cover. for cable diameter range 1 - 3.5 mm Cut at on the Large Rubber Cab for cable diameter around 3.5 mm Cut at on the Large Rubber Cab for cable diameter range 4 - 5.5 mm O Ring Transparent plastic cover Rubber cap Small Rubber Cap Large Rubber Cap Remove the fuse before making any connections WIRE CONNECTION Refer to the illustration below and connect the hardwire cables to the Ghost Box. Re- assemble everything and close the lid.
- Page 5 WIRING - GHOST BOX Ghost Box hardwire cables are color coded, RED for POSITIVE (+) and BLACK for NEGATIVE (-). Connect the RED cable to the POSITIVE (+) battery clamp as illustrated. The POSITIVE battery post will be slightly larger than the NEGATIVE post, and will be marked with a PLUS (+) sign. There may also be a RED protective cover over the positive battery post. Connect the BLACK cable to the NEGATIVE (-) battery clamp as illustrated. The NEGATIVE will be marked with a MINUS (-) sign. There may also be a BLACK plastic protective cover over the negative battery post. Every installation is unique. This diagram is meant to be for illustrative purposes only. Professional installation is highly recommended. NOTE: After connecting the Ghost Box to the car battery, the LED power indicator will flash Green. If the LED power indicator does not flash once connected, please double check your power connections. The Ghost Box has built-in voltage protection to prevent the vehicle battery from draining in case an accessory controlled by the Ghost Box is accidentally left on. LED indicator will turn off automatically and the Ghost Box will be on sleep mode when the voltage drops to approximately 12.2V. Once on sleep mode, do not turn on the Ghost Box until you start the engine again or until the battery is recharged to 13V or higher. The Ghost Box has a small parasitic draw that will not affect your vehicle if driven regularly. If you are planning to store your vehicle or leave it non-operational for a long period of time, we recommend either hooking it up to a battery charger or removing the fuses in each Ghost Box to avoid draining the battery. WARNING: DO NOT mix up the cables or allow the metal ends to touch together because this may damage the battery, charging system and/or electronics on your vehicle. When installing, please make sure the battery is disconnected.
-
Page 6: Download App
Press again Standby Mode Ghost Box turns off output power Press and Hold Pairing Mode Ghost Box enters Pairing Mode Blinking for 3 Sec (0.25sec.) Press and Hold Sleep Mode 1. Ghost Box enters Sleep Mode to reduce for 8 Sec power drainage 2. Ghost Box returns to Standby Mode when voltage is over 13V (e.g. when the engine starts) Press and Hold Reset Ghost Box resets to factory settings Flash Green for 15 Sec DOWNLOAD APP PROJECT X Off-Road Compatible with iPhone 4s and Compatible with phones with higher, iPad3, iPad Mini, iPad Air Android™ 5.0 or higher. and higher, and iPod touch 5th Generation and higher. Requires iOS 9.0 or higher. Scan the above QR code or search “PROJECT X Off-Road” in the App Store or Google Play. Download and install the App. Once installed, open the App and begin enjoying your PROJECT X Off-Road App. NOTE: The App is only available on smartphones with apple iOS 9 or newer, and Android 5.0 or newer. The PROJECT X Off-Road App is not accessible from browsers or PCs. -
Page 7: Add Device
ADD DEVICE We recommend you to connect a battery charger to the vehicle during the set up and pairing process if your vehicle is not running. Follow these instructions to add the Ghost Box to the App. 1. Tap ADD DEVICE on 2. Tap GHOST BOX 3. Tap GHOST BOX 4. Ghost Box is added to the home page. SYSTEM. CONTROLLER. list of device. Tap GHOST BOX CONTROLLER again to start customizing your 12V accessories. NOTE: For detailed instructions on customizing your accessories with the PROJECT X Off-Road App, check out our video library at www.projectxoffroad.com. Cautions 1. Do not install or the use the product if it, in any way, impairs the safe operation of your vehicle. 2. F ollow manufacturer’ s instructions to ensure the product is properly and safely installed. 3. C heck your state or provincial laws before installing. Vehicle owner must comply with all applicable laws. 4. T his product is intended solely for off-road purposes. Manufacturer and seller assume no liability for installation or use, which are solely the responsibility of the purchaser. 5. T his product is not DOT approved and is designed and intended for off-road uses only. -
Page 8: Warranty
Warranty This PROJECT X product carries a 1 year warranty on Ghost Box, as referenced on the website: www.projectxoffroad.com/pages/returns-warranty DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY OF MERCHANTABILITY AND WARRANTY OF FITNESS FOR PARTICULAR PURPOSE: EXCEPT AS SPECIFICALLY SET FORTH HEREIN, NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIES, IS MADE AS TO THE GHOST BOX. PROJECT X AND/OR ITS AFFILIATES EXPRESSLY DISCLAIMS, WITHOUT LIMITATION, ANY STATUTORY WARRANTIES AND ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. PROJECT X 2975 Red Hill Ave. Ste. 100 Costa Mesa, CA 92626 FCC Compliance statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:...
