Westward 450G83A Operating Instructions Manual

Operating Instructions Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could
result in personal injury and/or damage to product or property. Please retain instructions for future reference.
Description
This unit is designed as an emergency jump starter for 12-24 volt batteries.
Before using this product, read this manual thoroughly and follow the directions carefully, with particular emphasis on
the safety precautions. This will ensure all personal safety and prevent costly property damage.
Unpacking
After unpacking unit, inspect carefully for any damage
that may have occurred during transit. Check for loose,
missing, or damaged parts. Shipping damage claim
must be filed with carrier.
LED display for battery status
12V / Off / 24V Selector switch
Automatic internal charger
Test button for
charges internal battery
internal battery check
Printed in CHINA
SGI100 03/2018
450G83A
Battery Jump Starter
Westward Operating Instructions Manual
Battery Jump Starter
Specifications and Dimensions
Model Battery Cranking Amps Peak Amps
12/24VDC 22AH
1700A / 3400A /
450G83A
Sealed Lead
850A
Acid Battery
General Safety Information
Failure to follow instructions may
cause damage or explosion. Always wear eye
protection when using product. Read entire instruction
manual before use. Use in a well ventilated area.
To incresae the product's life and efficiency,
please note:
Fully charge the battery when first received.
Fully charge the battery after each use.
Fully charge the battery every 3 months.
This unit contains Sealed Lead Acid Battery
Battery must be recycled.
Do not incinerate.
Do not dispose of in household trash.
Lead is known in California to cause birth defects
and reproductive harm.
Wash hands thoroughly after handling!
1. To reduce risk of injury, charge
only wet cell, lead-acid, automotive type
rechargeable batteries. Other types of batteries may
burst causing personal injury and property damage.
2. Do not expose jump starter to rain or snow.
3. Use of an accessories are not recommended or sold by
the jump starter manufacturer and may result in a
risk of fire, electric shock, or injury to persons.
4. Do not operate jump starter if it has received a sharp
blow, been dropped, or otherwise damaged in any way;
take it to a qualified serviceman.
5. Do not disassemble jump starter; take it to a qualified
serviceman when service or repair is required. Incorrect
reassembly may result in a risk of electric shock or fire.
450G83A
Dimensions (Inches) Weight
Width Height Depth (Lbs)
13-1/2" 15-1/2" 7-1/2" 41.89
1700A
6. RISK OF EXPLOSIVE GASES
a. WORKING IN VICINITY OF A LEAD-ACID BATTERY
IS DANGEROUS. BATTERIES GENERATE
EXPLOSIVE GASES DURING NORMAL BATTERY
OPERATION. FOR THIS REASON IT IS OF
UTMOST IMPORTANCE THAT EACH TIME
BEFORE USING YOUR JUMP STARTER, YOU READ
THIS MANUAL AND FOLLOW THE INSTRUCTIONS
EXACTLY.
b. To reduce risk of jump starter explosion, follow these
instructions and those published by battery
manufacturer and manufacturer of any equipment
you intend to use in vicinity of battery. Review
CAUTION notices on jump starter and engine.
7. PERSONAL PRECAUTIONS
a. Someone should be within range of your voice or
close enough to come to your aid when you work
near a lead-acid battery.
b. Have plenty of fresh water and soap nearby in case
battery acid contacts skin, clothing, or eyes.
c. Wear complete eye protection, and clothing
protection. Avoid touching eyes while working near
battery.
d. If battery acid contacts skin or clothing, wash
immediately with soap and water. If acid contacts
eyes, immediately flood eye by running cold water for
at least 10 minutes and get medical attention
immediately.
e. NEVER smoke or allow a spark or flame in vicinity
of battery or engine.
f. Be extra cautious to reduce risk of dropping a metal
tool onto battery. It might spark or short circuit battery
or other electrical part that may cause explosion.
g. Remove personal metal items such as rings, bracelets,
necklaces, and watches when working with a lead-acid
battery. A lead-acid battery can produce a short circuit
current high enough to weld a ring or the like to metal,
causing a severe burn.
h. Use jump starter for jumping a LEAD-ACID battery only.
It is not intended to supply power to a low-voltage
electrical system. Do not use jump starter for charging
2
