RIG-A-LITE EXHBF Series Installation Datasheet

LED LUMINAIRE FOR USE IN HAZARDOUS LOCATIONS
• To reduce risk of fire or explosion, do not install where the marked operating temperature exceeds the
ignition temperature of the hazardous atmosphere(s).
• These luminaires should be installed by qualified technicians using suitable hazardous location wiring
methods in strict accordance with the National Electrical Code, NFPA 70 and any local requirements.
• To prevent risk of electrical shock, deactivate/ disconnect power supply before opening. Keep tightly
closed when in operation.
• DO NOT OPEN WHEN ENERGIZED.
• DO NOT OPEN WHEN AN EXPLOSIVE GAS ATMOSPHERE IS PRESENT
• POTENTIAL ELECTROSTATIC CHARGING HAZARD – SEE MAINTENANCE DATA
• Install the luminaire in a location that minimizes the risk of impact
EQUIPMENT APPLICATION
This luminaire is intended for use in a hazardous atmosphere in Zone 1 and 21 to the requirements of ATEX Directive
2014/34/EU. The product can be used inside or outside to illuminate areas with potentially hazardous atmosphere.
CONFORMITY WITH STANDARDS
This luminaire conforms to the standards specified in the Declaration of Conformity. It has been designed, manufactured
and tested in accordance with BS EN 9001. 94/9 EC: Equipment and protective systems intended for use in potentially
explosive atmospheres.
IEC 60079-0: 7 th Edition (2017)– Explosive Atmospheres, General Requirements
IEC 60079-1: 7 th Edition (2014-06) – Explosive Atmospheres - Equipment protection by flameproof enclosures "d"
IEC 60079-28:2015 - 2 nd
optical radiation
IEC 60079-31: 2013 - 2 nd
EN 60079-0:2018 – Explosive Atmospheres, General Requirements
EN 60079-1:2014 – Explosive Atmospheres - Equipment protection by flameproof enclosures "d"
EN 60079-28:2015 - Explosive atmospheres - Protection of equipment and transmission systems using optical radiation
EN 60079-31:2014 - Explosive Atmospheres - Equipment protection by flameproof enclosures "t"
8500 Hansen Rd.
Houston, TX 77075 USA
86305EXHBF
INSTALLATION DATA SHEET
EXHBF SERIES
II 2 G Ex db op is IIB+H2 T5 Gb
-40°C ≤Tamb≤+65°C, IP66
II 2 D Ex op is tb IIIC T100°C Db
-40°C ≤Tamb≤+55°C, IP66
Edition - Explosive atmospheres - Protection of equipment and transmission systems using
Edition - Explosive Atmospheres - Equipment protection by flameproof enclosures "t"
Tel: 713-943-0340
2903
WARNING!
Oct 2022
ATEX: ETL22ATEX0137X
IECEx: IECEx ITS 19.0026X
availinfra.com/rig-a-lite/
Rev. 3
