- Page 1 OWNER'S MANUAL LED LCD Monitor (LED Monitor*) *LG LED Monitors are LCD Monitors with LED Backlighting. Please read this manual carefully before operating your set and retain it for future reference. LED LCD MONITOR MODEL 17BR30T www.lg.com...
-
Page 2: Table Of Contents
CONTENTS CONTENTS ASSEMBLING AND PREPAR- Supported Drivers and Software Parts and buttons Moving and Lifting the Monitor - Basic Adjustment USING THE MONITOR SET Connecting to a PC - D-SUB connection - To Use Touch Screen CUSTOMIZING SETTINGS Customizing Settings - Menu Settings READER Setting - SMART ENERGY SAVING... -
Page 3: Assembling And Preparing
The product warranty will not cover damage or injury caused by the use of counterfeit components. It is recommend that use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noises. -
Page 4: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons Power Indicator LED On : Power is on LED Off : Power is off... -
Page 5: Moving And Lifting The Monitor
ASSEMBLING AND PREPARING Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. Place the monitor in the original box or packing material before attempting to move it. Before moving or lifting the monitor, disconnect the power cord and all other cables. -
Page 6: Basic Adjustment
ASSEMBLING AND PREPARING After installing the monitor, adjust the angle as follows. Basic Adjustment Adjust the angle of the panel as follows. How to adjust the angle of the panel ■ Tilt Range : 15° to 66° ■ Push back the panel to the end, and use from the point that it automatically returns. Panel Stand Do not push the stand with basic... -
Page 7: Using The Monitor Set
D-sub 15 pin signal cable as shown in the following illustrations. You can download and install the latest version from the LGE website (www.lg.com). NOTE When using a D-Sub signal input cable < USB cable for the touch screen >... -
Page 8: Customizing Settings
CUSTOMIZING SETTINGS CUSTOMIZING SETTINGS Press the desired button on the bottom of the Monitor set. Change the value of the menu item by pressing the buttons on the bottom of the Monitor set. To return to the upper menu or set other menu items, use the up arrow ( ) button. - Page 9 CUSTOMIZING SETTINGS Button Description Accesses the main menus. OSD Locked/OSD This function allow you to lock the current control settings, so Unlocked that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. Then OSD of “OSD Lock” will appear. After that, user can select lock or unlock by pressing left/right button.
-
Page 10: Customizing Settings
CUSTOMIZING SETTINGS Customizing Settings Menu Settings Menu Description Brightness To adjust the brightness of the screen. Contrast To adjust the contrast of the screen. ◄ ► Reset Restore all factory default settings. Press the buttons to reset immediately. Menu > Next Menu > Picture Description Sharpness To adjust the clearness of the screen. -
Page 11: Reader Setting
CUSTOMIZING SETTINGS Menu > Next Menu > Others Description Language To choose the language in which the control names are displayed. Power Indicator Use this function to set the power indicator on the bottom side of the monitor to On or Off.If you set Off, it will go off. If you set On at any time, the power indicator will automatically be turned on. -
Page 12: Smart Energy Saving
CUSTOMIZING SETTINGS SMART ENERGY SAVING SMART ENERGY SAVING Description High Enables SMART ENERGY SAVING you can save energy with this energy- high efficient function. Enables SMART ENERGY SAVING you can save energy with this energy- low efficient function. Disables SMART ENERGY SAVING. SMART ENERGY SAVING: Conserve energy by using luminance compensation algorithm. -
Page 13: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Nothing is displayed on the screen. Check if the power cord is correctly plugged into the power outlet. Is the monitor's power cord plugged Check the power cable connection and press the power button. Is the power LED on? Check that the connected input is enabled (Settings >... - Page 14 Do you see an "Unrecognized monitor, Plug and Play (VESA DDC) monitor found" message? Be sure to install the display driver from our web site: Have you installed the display driver? http://www.lg.com. Make sure to check if the graphics card supports Plug and Play function. No sound from the headphone port.
-
Page 15: Specifications
SPECIFICATIONS SPECIFICATIONS Color Depth 8-bit color is supported. Resolution 1280 x 1024 @ 75Hz Recommend 1280 x 1024 @ 60Hz Power Input AC 100-240V ~ 50/60Hz 0.8 A Dimensions With Stand (mm) 370 x 315 x 95 (Width x Height x Depth) Without Stand (mm) 370 x 315 x 62 Weight... -
Page 16: Preset Modes (Resolution)
SPECIFICATIONS Preset Modes (Resolution) Horizontal Vertical Display Modes (Resolution) Polarity(H/V) Frequency(kHz) Frequency(Hz) 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 1024 79.976 75.025 1280 x 1024 63.981 60.020 Recommend Mode... - Page 17 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
