12.TROUBLESHOOTING ........................16 Table 1. Troubleshooting ........................... 17 The employees of NAGANO KEIKI CO.,LTD. (NAGANO) and its subsidiaries, and agents and brokers of NAGANO shall not change the descriptions, except for the arrow heads to clarify objects, in this operation manual without permission.
TY13-42A 3/18 1.INTRODUCTION The CL13 differential pressure switch is designed for detecting air filter pressure drop used in an air- conditioning system and warning for filter clogging, etc. Applications include clean room/bio clean room pressure monitoring. When using the CL13, read carefully this manual, which describes the operation procedure, and use the product correctly and effectively after understanding sufficiently the description.
Page 4
Rev.3 TY13-42A 4/18 (4) Precautions ①It is strictly prohibited to apply this differential pressure switch to life support systems or relevant equipment without our permission. ②This differential pressure switch is designed and manufactured to measure the difference of the pressure applied to the pressure lead-in unit. It is prohibited to use this differential pressure gauge for any other applications.
Be sure to turn off the power on both sides. 2.APPLICATIONS CL13 fine differential pressure switch will detect pressure difference between two selected locations (differential pressure), and close or open electric circuits as appropriate, or give an alarm. This switch is mainly used for detecting differential pressure associated with pressure loss in the air filter in air conditioning systems.
Rev.3 TY13-42A 6/18 4.SPECIFICATIONS (1) Standard range Table 4-1 Setpoint range Differential Deadband pressure range Upper limit type Lower limit type 70Pa 15Pa and below 70Pa 55Pa ~ ~ ~ 100Pa 20Pa and below 100Pa 80Pa ~ ~ ~ 200Pa 40Pa and below 200Pa 160Pa...
Page 7
Rev.3 TY13-42A 7/18 (3) Standard specifications ・Measuring object : Air or non-corrosive gas, but not to condense It is not suitable for measuring object containing a many of foreign matter. ・Connection : 5.5 DIA. Barb fitting (For tubing with 4 DIA. Inner diameter vinyl tube) ・Material of gas contacting parts : Diaphragm Silicone rubber...
Rev.3 TY13-42A 9/18 6.INSTRUCTIONS FOR TRANSPORTATION, STORAGE AND UNPACKING (1) Precautions for Transportation This product is a precision instrument. Performance can be lost if it is dropped or given shock. Be extremely careful of the transportation of the instrument. (2) Precautions for Storage Store the product in a dry place free from vibrations or dust.
10/18 7.STRUCTURE AND OPERATION PRINCIPLE Fig. 7-1 is the cross-sectional view of CL13. Pressure introduced from the high pressure connecting port is applied on the upper side of the diaphragm. Pressure from the low pressure side works on the lower side of the diaphragm.
Page 11
Machine the M4 screw hole or 4.5DIA. mounting hole for mounting with a pitch of 80 mm on the panel and fix with M4 screws. (4) Wiring ①Contact type CL13 can select upper limit single-contact and lower limit single-contact by connecting terminal. Table 8-1 shows the contact type. Table 8-1 Connecting...
Page 12
Rev.3 TY13-42A 12/18 ②Connection Wiring is done with a terminal block. Since the screw of the terminal block is M4, please securely connect using the crimp terminal and the cable suitable for the load. Figure 8-1 shows the connection diagram. Micro switch Terminal ・...
Page 13
Rev.3 TY13-42A 13/18 Typical examples of arc killers Table 8-2 Application Circuit example Features, etc. Element selection Standard C and R values For operation on AC are as shown below. voltage C: 0.5 to 1μF for 1 A contact current Load impedance should R: 0.5 to 1 Ω...
Page 14
Rev.3 TY13-42A 14/18 Table 8-2 Continued from previous page. Application Circuit example Features, etc. Element selection This type makes use of the constant-voltage characteristics of the varistor to prevent high voltage from being applied between the contacts. Reset time of this type is also ○...
Rev.3 TY13-42A 15/18 ⑥Note that insulation may be impaired if a large amount of moisture is contained in the measurement gas. (Measuring gas reaches the inside energized portion.) Also, as water accumulates inside the instrument, caution is necessary as the instrument breaks if water freezes.
Rev.3 TY13-42A 16/18 10.OPERATIONS (1) Please check leakage of pressure receiving part before operation and check that there is no leakage of measured fluid. (2) Please check whether piping is correct. (3) Please check whether the notes stated in this instruction manual are observed before starting operation.
Page 17
Rev.3 TY13-42A 17/18 Table 1. Troubleshooting (1/2) Troubles Check points Possible causes Countermeasures Remarks Clogging of lead Install strainer. Slow response pipe to gauge, pipe Clogging of lead speed. diameter and fluid pipe. Use thicker pipe. viscosity. Change the installation position or radiate heat from the piping, etc.
Page 18
Rev.3 TY13-42A 18/18 Table 1. Troubleshooting (2/2) Troubles Check points Possible causes Countermeasures Remarks Readjust, or replace Number of times of Service life of the the differential switching. switch has expired. pressure switch. It is not suitable Water in differential for measuring fluid Corrosion of parts ―...
