HY06-RF-BW/WW/WE Thermostat User Manual
Many thanks for your selection of our products and services, and also for your trust and support to
us.
In the box you will find
Thermostat 1pc
User Guide 1pc
About Your Thermostats
The HY06 Series range has been developed to control electric underfloor,water heating or water/gas boiler
systems,all design have backlight function
Features
1． Standard total Size is 86*86mm
2． Display size is 64*64mm
3． Touch buttons to make simple operation
4． Color：white、black、champagne golden
5． The visible thickness above the wall is only
13mm
6． 86mm hidden box and about 60mm of box
is suitable for Europe
7． Flat mounting ,it is easy to install
8． Inclusive inner sensor and external sensor
Product Specifications
Power: two AA* 1.5V alkaline batteries
Display accuracy:：0.5℃
Probe sensor:：NTC(10k)1%
Contact capacity:：5A/230V
Working environment temperature:：0~50°C
Range of temperature adjustment:：5~35°C
Screws 2pc
Floor Sensor(3m) 1pc(Optional)
9． 0.5°C Accuracy keeps temperature within
the level you set.
10．Children lock ,to prevent misoperation by
children
11．Data memory when power is off.
12．5+2 days
support DIY programmable
13．Holiday mode, give your more choose in
holiday
14．There is a query function for external sensor
temperature
Range of temperature display:：0~40°C
Output: Switch relay
Insulating condition: Normal environment
Running program: Set per 1 week as a cycle
Installation: Wall mounted or on battery seat
Size(mm)：86*86*23
programmable ,meanwhile
