User Guide
Variable Refrigerant Flow (VRF) System
SimpleTouch Wired Remote Controller
Model Numbers:
Only qualified personnel should install and service the equipment. The
installation, starting up, and servicing of heating, ventilating, and air-
conditioning equipment can be hazardous and requires specific knowledge and
training. Improperly installed, adjusted or altered equipment by an unqualified
person could result in death or serious injury. When working on the equipment,
observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
May 2017
TVCTRLTWR0002T
TVCTRLTWR0002A
SAFETY WARNING
VRF-SVU047C-EN
© 2017 Ingersoll Rand
Advertisement
Table of Contents
Related Manuals for Ingersoll-Rand TVCTRLTWR0002T
Summary of Contents for Ingersoll-Rand TVCTRLTWR0002T
- Page 1 User Guide Variable Refrigerant Flow (VRF) System SimpleTouch Wired Remote Controller Model Numbers: TVCTRLTWR0002T TVCTRLTWR0002A SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air- conditioning equipment can be hazardous and requires specific knowledge and training.
-
Page 2: Warnings, Cautions, And Notices
Introduction Read this manual thoroughly before operating or servicing this unit. Warnings, Cautions, and Notices Safety advisories appear throughout this manual as required.Your personal safety and the proper operation of this machine depend upon the strict observance of these precautions. The three types of advisories are defined as follows: Indicates a potentially hazardous situation which, if not avoided, could result WARNING... -
Page 3: Revision History
WARNING Personal Protective Equipment (PPE) Required! Failure to wear proper PPE for the job being undertaken could result in death or serious injury. Technicians, in order to protect themselves from potential electrical, mechanical, and chemical hazards, MUST follow precautions in this manual and on the tags, stickers, and labels, as well as the instructions below: •... - Page 4 Display Display ⑩ ⑪ ⑬ ⑧ ⑫ ⑦ ① ② ⑤ ④ ③ ⑥ Table 1. Icon descriptions Item number Icon Description Unit operation Quiet operation Indoor temperature/setpointVRF-SVU047C-EN Fan speed Air swing (up/down) On/Off timer (scheduled time) Filter cleaning Service required Centralized control...
- Page 5 Buttons Buttons ④ ① ② ③ ⑥ ⑧ ⑤ ⑪ ⑦ ⑨ ⑩ Table 2. Buttons functions Item number Button Function Power button Press to turn the indoor unit On or Off. Mode button Press to select an operating mode: Auto, Cool, Dry, Fan, Heat. Temperature setting button Press to select an indoor temperature setpoint and to change the time when setting the timer On/Off feature.
-
Page 6: Basic Operation
Basic Operation Basic Operation Turning On/Off the Indoor Unit To turn On or Off the indoor unit, press the Power button. Selecting the Operating Mode To select an operating mode, press the Mode button until the desired operating mode appears on the display. Each time the Mode button is pressed, the screen displays a different mode, in the order shown in Figure Figure 1. -
Page 7: Selecting The Fan Speed
Basic Operation Selecting the Fan Speed To select a fan speed, press the Fan Speed button repeatedly until the desired fan speed appears on the display. Fan speed availability is dependent on the current indoor unit operating mode, as shown in Table Table 4. -
Page 8: Selecting Quiet Operation
Basic Operation Figure 2. Example of Air Swing being activated Selecting Quiet Operation Quiet operation reduces the noise of the indoor unit.To activate this feature, press the Quiet button.To cancel quiet operation, press the button again. Note: If an indoor unit is operating in Fan mode, the lock icon light ( ) will blink on the display. -
Page 9: Setting The Off Timer
Basic Operation Figure 4. Example of timer set to turn the unit On in 30 minutes Note: To cancel the On time, press and hold the OK button for 3 seconds. Setting the Off Timer The OffTimer feature is used to set the indoor unit to turn off at a specific time. Note: To set the Off timer, the indoor unit must be turned On. - Page 10 Basic Operation Figure 6. Example of Sleep function activation Lock The Lock function locks the display so that no changes can be made to the unit by using the display. 1. Press the Lock button for 3 seconds.The Lock icon will appear in the upper right corner of the display.The Lock icon will blink if any button is pressed other than the Lock button.
- Page 11 Basic Operation Figure 8. Example of the display showing the Outing (Unoccupied) function 9°F (5°C) difference between indoor temperature and outing setting temperature After 12 hr Notes: • The Outing (Unoccupied) function – is valid only when the unit is operating in Heating or Cooling mode. –...
-
Page 12: Additional Functions
Additional Functions Additional Functions To set or change additional functions using the SimpleTouch Wired Remote Controller, use the following procedure and refer to Figure 9 Table 6, p. Figure 9. User setting mode and main menu Option code Submenu Page Menu ①②... - Page 13 Additional Functions In the example on the right (menu “3” , submenu “2” , page “01” , option code “1”) locking the On/Off (Power) button has been selected. Important: If you leave the page number set to “01” , you will be changing the option code setting for the option that has a page number of “01”...
- Page 14 Additional Functions Table 6. Options and settings for additional user functions (continued) Setting Main menu Option code/ Factory code menu Function description value default Page Lock operation mode 0: Clear button 1: Lock 0: Clear Hide Auto mode 1: Lock 0: Clear Hide Cool mode Operation...
- Page 15 Additional Functions VRF-SVU047C-EN...
- Page 16 Ingersoll Rand (NYSE:IR) advances the quality of life by creating comfortable, sustainable and efficient ® ® ® environments. Our people and our family of brands—including Club Car , Ingersoll Rand , Thermo King ® and Trane —work together to enhance the quality and comfort of air in homes and buildings; transport and protect food and perishables;...
