Version 1.1

USER MANUAL

MODEL: PENTA-5070

The information given in this document is carefully checked and believed to be reliable.

All manual are subject to change without notification.

Table of Contents

Need help?

Do you have a question about the PENTA-5070 and is the answer not in the manual?

Questions and answers

Summary of Contents for AHA PENTA-5070

Page 1 Version 1.1 USER MANUAL MODEL: PENTA-5070 The information given in this document is carefully checked and believed to be reliable. All manual are subject to change without notification.
Page 2: Table Of Contents
Contents 1. Important safety Instructions...………………………………………………….….3 1.1 Safety precautions 1.2 Care and maintenance 2. Introduction...………………….……………………………………………….…..8 3. Each Description..……………………..……………..…………………….……9 3.1 Front View 3.2 Rear View 4. PC Connection...……………..………..……......…….………….…12 5. Remote Control..……………..………..………....………….…………….13 6. Home Menu Description……..….….………………..……………………….…...14 7. Android Setup Menu Description……..….….……….………………….………..17 8. Product Specification..……..………………..………………………………….….26 9.
Page 3: Important Safety Instructions
1. Important Safety Instructions ICON NAME MEANING Warning Failing to follow the precautions marked with this sign may result in a serious injury or even a fatality. Caution Failing to follow the precautions marked with this sign may result in a personal injury or property damage. Before operating the set, please read this manual carefully.
Page 4 1) Read Instructions 2) Follow Instructions All operating and use instructions should be followed. 3) Retain Instructions The safety and operating instructions should be retained for future reference. 4) Heed Warnings All warnings on the product and in the operating instructions should be adhered to. 5) Cleaning Disconnect the unit from the electricity supply before cleaning.
Page 5 13) Lightning For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent possible damage to the product due to lightning and power-line surges. 14) Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits.
Page 6  Products at the same time holding the products when building or product, do not hold the back of the handle. under the product makes. the handle is a secondary role.  Table stand and put them on the table by using the installation gets the nose does not necessarily prevent a fall on the floor using the screws fixed.
Page 7: Care And Maintenance
1-2. Care and Maintenance External Surface and Screen Maintenance Clean the product with a soft dry cloth. • Avoid cleaning the product with an inflammable substance such as benzene or thinner or with a wet cloth. This may result in a problem with the product. •...
Page 8: Introduction
2. Introduction 2-1. Package Contents ∙ Unpack the product and check if all of the following contents have been included. ∙ Store the packaging box in case you need to move the product later. ∙ If any items are missing, contact your dealer. ∙...
Page 9: Each Description
3. Each description 3.1 Front View ① ② ① Sound Bar Interface - USB 1, 2 : Download-software update Play contents - Touch : External PC using USB touch sensor connection - HDMI : High Definition Multimedia Input- up to FHD input - MENU : Showing Android start menu.
Page 10: Rear View
3.2 Rear View ③ ② ① ① Interface Mini AV IN / YPbPr Audio In Mini YPbPr HDMI3 USB for RS-232C Audio S/PDIF AUDIO TOUCH Line Out Interface Description HDMI3 High Definition Multimedia Input- Up To Input USB For TOUCH External PC Using USB Touch Sensor Connection RS-232 Facility To Control The Screen Via RS232 Protocol...
Page 11 ② Interface HDMI 2 HDMI 1 USB 2 USB 1 R(8Ω)L(8Ω) SPEAKER Interface Description LAN(Local Area Networks) Ports WAN(Wide Area Networks) Ports DISPLAY PORT Input- up to Input HDMI 2 High Definition Multimedia Input 2 HDMI 1 High Definition Multimedia Input 1 USB 2 Download-software update Play contents USB 1...
Page 12: Pc Connection
4. PC Connection 1) Connect RGB cable to RGB, Voice connection will be connected to PC AUDIO IN with stereo cable. 2) HDMI cable will be connected to (display and voice are available at the same time) 3) External speaker will be connected to R , L input with using Ø 3.5 stereo cable and then connect same as below drawing.
Page 13: Remote Control
5. Remote Controller 5.1 How to insert battery Insert the battery into proper polarities Battery model:(CR-2025 3V)
Page 14: Home Menu Description
6. Home Menu Description 6.1 Menu Overview In this home menu screen, there are several buttons to change the sources or functions easily. USB Connect Status Ethernet Connect Time & Date Status Indicate Current Screen ① ② ③ ⑤ ⑥ ④...
Page 15 Dragging Home Menu If you drag the bottom of the screen upward, the hidden Home Menu pops up. With the Home Menu you can go to Brightness, Back, Home, Source, Volume...
Page 16 Home Bar UI Description Brightness Adjust the brightness. Volume Adjust the volume Back Moves to the previous screen step. Home Go to the home screen. Source Calls the external input window. Setup Go to the Android Setup...
Page 17 Dragging External Source Once selected, the corresponding screen is displayed as a preview. Select the preview screen, or double-tap Source button to go to that screen.
Page 18: Android Setup Menu Description
7. Android Setup Menu Description 7.1 Menu Overview Select for Android setup then you can see the below menu screen Tapping Dragging...
Page 19 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ① Network : to setup the Ethernet ② Picture : to setup the brightness, color, and contrast ③ Sound : to setup the sound features ④ Lock settings : to setup the lock style, unlock password ⑤...
Page 20 7.2 Network  Ethernet Setting To set up the IP automatically by DHCP (Dynamic Host Configuration Protocol) or input the IP address manually in Static IP setting  DHCP (Dynamic Host Configuration Protocol) To set up the IP automatically, select DHCP then “Getting IP” messages shows up and it automatically assigned the IP address.
Page 21  Static IP To set up IP address manually by inputting fixed IP. (IP, Netmask, Gateway, DNS)  WiFi Setting To set up the WiFi turn on / off...
Page 22  Network State To check the current network status of this system. Ethernet, PPOE, WiFi If it is not connected any network, shows “Unconnected”and shows “Connected” when it connected to network. Also, IP, Netmark, Gateway, DNS information turns on when connected 7.3 Picture ...
Page 23 7.4 Sound  Sound Mode : User can set the Sound Mode .There are Movie, Meeting, Classroom, Custom Mode. Users can adjust each value in Custom Mode. • Bass : (less) 0 to 100 (more) of bass sound • Treble : (less) 0 to 100 (more) of treble sound •...
Page 24 7.6 Advanced Advanced : to setup the advanced function. • Language : User can set the OSD menu language. • Input Method : User can set Keyboard type (AOSP and IME Type) • Sleep Off : User can set time to shut down automatically after setting time. (Off, 15, 30, 45, 60, 90, 120, 240 minutes) •...
Page 25 7.7 Restore Restore : To reset the system • Restore user Setting: to reset to user setting • Restore Default : to reset factory setting...
Page 26 7.8 System Info System Info : To check the system information (CPU, GPU, Memory, Android version) 7.9 Upgrade Local Update : To upgrade F/W, connect the USB on the back side “Bracket for F/W update” and then select Local Update.
Page 27: Product Specification
8. Product Specification 8-1. LED Specification System Specifications Items Specification Touch detection method Infrared blocking Detection Method Touch tool / Reaction Hand or other solid object / 20 Points Supported OS Window 7, 8, 10 / MAC 10.10 ~ 10.12 / Android 5.1 Resolution (Pixel) 1920 x 1080 (FHD) Front Glass...
Page 28 Input / Output Description Features Items Quad-Core, 64 bit Cortex-A53 Hexa-core ARM Mali-450 , Dual-core VPU CPU Clock Speed 1.2GHz System Flash 8GB Build in Emmc Parameter 2GB(2Gbit X 4) ; DDR3 ; 1866MHz SDRAM Version 5.1.1 Android Kernel 3. 1. 10 Display Format Auto/16:9/14:9/4:3/ZOOM1/ZOOM2/Spectacle Video...
Page 29: Product Dimensions
9. Product Dimensions...
Page 30: Troubleshooting
10. Troubleshooting 10-1. Product Self-Diagnosis ∙ You can check if the product is working properly using the Self-Diagnosis function. ∙ If a blank screen is displayed and the Power LED blinks even if the product and the PC are properly connected, perform the self-diagnosis function according to the procedures below.
Page 31: Customer Support And As Guide
2) A/S is the cost incurred to our bylaws, item rated A/S price is determined according to the criteria, accurate repair cost, please contacts a customer support counseling over the phone. 3) Even within the warranty period if you use a shipping and negligence A/S will be charged. 11-3. Contact Information aha@ahatouch.com...
