ANTSPACE HK3 Liquid Cooling System Operation and Maintenance V1.3
ANTSPACE HK3
V2/V3/V5
Liquid Cooling System
Operation and Maintenance Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANTSPACE HK3 V2 and is the answer not in the manual?

Questions and answers

Jiwan
January 23, 2025

I **** constantly getting PT02 outlet pressure low issue in my AntSpace hydro container system. What could cause the issue and what are he solutions or what things need to be checked.

1 comments:
Mr. Anderson
May 14, 2025

The PT02 outlet pressure low issue in a BITMAIN AntSpace HK3 V2 hydro container system could be caused by the following:

1. Filter is clogged – Solution: Clean the filter element.
2. System is short of liquid (low return pressure) – Solution: Refill the system with liquid.
3. Water pump cavitation – Solution: Detect the pressure on the suction side and refill in time.
4. Pump shaft connection problem – Solution: Check the mechanical connection of the pump shaft.
5. Insufficient lubrication of motor shaft – Solution: Add lubricating oil.
6. Water pump shaft seal issue – Solution: Replace the water pump.

These checks and solutions help restore proper outlet pressure in the cooling system.

This answer is automatically generated

Summary of Contents for BITMAIN ANTSPACE HK3 V2

  • Page 1 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance V1.3 ANTSPACE HK3 V2/V3/V5 Liquid Cooling System Operation and Maintenance Manual...
  • Page 2 Catalogue 1. Summary of the ANTSPACE HK3 2. Composition and Working Principles of the ANTSPACE HK3 3. Main technical specification of the ANTSPACE HK3 4. Structural view of ANTSPACE HK3 5. Use and Operation of ANTSPACE HK3 6. Common faults and troubleshooting methods of ANTSPACE HK3 7.
  • Page 3: Working Principles

    ANTSPACE HK3 Liquid Cooling System Operation and Maintenance 1. Summary of the ANTSPACE HK3 ANTSPACE liquid cooling system aims to continuously provide coolant that meets the requirements of pressure, temperature and flow rate for the internal heat dissipation unit of mining machine, and ensure a good working environment for load.
  • Page 4 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance The working principle of Dry-Wet Combined Type Air Cooling Tower is divided into dry working condition and wet working condition. Its working principle under wet condition is as follows: The cooling tower takes water and air as the cooling medium, and USES partial evaporation of cooling water to take away the heat generated by cooling fluid flowing in the coil.
  • Page 5 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Figure 2-1 Schematic diagram of ANTSPACE liquid cooling system - 3 -...
  • Page 6 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Summary of functions of valves in schematic diagram Name Function State Remark 1#ball valve Drain of Liquid separator Closed 2#ball valve Drain of Main pipeline Closed 3#ball valve Drain of Main pipeline Closed The safety valve can be closed for maintenance in case of safety valve Open...
  • Page 7 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance The pressure gauge of main liquid supply pipeline shall cooperate with 3# Pressure gauge 2# pressure gauge to analyze whether the outlet pressure of water pump is normal and whether there is fault in the system The pressure gauge of the left branch pipe for liquid supply, together 4# Pressure gauge with 6# pressure gauge, can analyze whether the flow resistance of the...
  • Page 8 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance The container contains two power 1200A(V2 version) distribution cabinets, each with a PDU main switch capacity (A) 1200A (UL)/1250A(CE)main 1250A(V3/V5 version) switch. The rated current of each Rated Current (A) distribution cabinet in the container is 952 A.
  • Page 9 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance 4. Structural view of ANTSPACE HK3 4.1 External view of ANTSPACE Liquid Cooling System Dry and wet closed cooling tower Water-cooled container Cable inlet hole Automatic exhaust valve Exhaust fan Liquid return inlet Liquid supply inlet...
  • Page 10 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Figure 4-1-2 External view 02 of ANTSPACE liquid cooling system 4.2 Internal view of ANTSPACE Liquid Cooling System Shelf and water separator assembly Container Pump set Figure 4-2-1 Internal view 01 of the container Three stage water separator for liquid supply Three stage water separator...
  • Page 11 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Access control switch Shutter Mounting plate for face recognition Emergency button Lighting switch Figure 4-2-3 Internal view 01 of the front door of the container Liquid filling pump NO.9 Ball Valve NO.8 Ball Valve NO.4 Ball Valve Safety valve NO.7 Ball Valve...
  • Page 12 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance 9#ball valve(closed): After opening this valve, the external liquid can be replenished to the inside of the system / tank during liquid filling; When discharging liquid, the liquid inside the tank can also be discharged. Y-type filter Figure 4-2-5 Internal view 02 of the pump station NO.8 Ball Valve...
  • Page 13 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Automatic breathing valve Manual liquid filling inlet Make-up water tank Liquid indicator High Level Switch Low Level Switch Figure 4-2-7 Internal view 04 of the pump station Main Switch Frequency converter Temperature Sensor Contactors Thermal Relay Figure 4-2-8 Internal view 01 of ECC...
  • Page 14: Precautions For Operation

    ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Main Switch Switches Circuit breaker Figure 4-2-9 Internal view 01 of PDC 5. Use and Operation of ANTSPACE HK3 5.1 Safety regulations 5.1.1 A symbolic distinction indicating the degree of danger “ ” is the logo for electrical charge. It is forbidden to open the cover plate with the logo. 5.1.2 Precautions for operation 1)...
  • Page 15 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance 4) If the equipment has abnormal conditions (such as burning smells, etc.), it should be shut down, disconnected from the power supply, and checked. 5) There is an emergency stop on the entry door and on the door of electric cabinet A and B, when an emergency occurs, press the emergency stop, then the power circuit breaker will be disconnected immediately.After the emergency is reset, turn the main circuit breaker to the OFF position before power on the switch again;...
  • Page 16 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance the computing unit in PDC, disconnect with the corresponding network cable, water supply of the computing unit, and finally disconnect with the power supply of the computing unit. To power off the entire container, perform the following steps: a)...
  • Page 17 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance c) Disconnect the main switch of the two PDC. Note: The lighting circuit of the container is led from the main PDC. Bring a portable lighting lamp with you if you want to perform the above operation.
  • Page 18 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance NO.1 Air Vent Valve NO.2 Air Vent Valve Automatic breathing valve Figure 5-2-1 Pump station - automatic exhaust valve Status of closing: The vent of the automatic Status of opening: The vent of the automatic exhaust valve is unblocked. exhaust valve is blocked with a plug.
  • Page 19 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Automatic exhaust valve Figure 5-2-3 External connecting pipelines - automatic exhaust valve Status of opening: the handle of ball valve is Status of closing: the handle parallel to the pipeline. of ball valve is perpendicular to the pipeline.
  • Page 20 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance 4) Connect the air pipe to any fast plug-in interface, and close the corresponding ball valve. Port of air pump Mini ball valve Bellows Close this ball valve Figure 5-2-5 System - ball valve for connecting pipelines 5)...
  • Page 21 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Flange joint Welded joint Thread joint Figure 5-2-7 System - Flange/thread/welded joints 7) The check methods are as follows: a) Seeing, hearing and touching are applicable to leakage inspection. b) Choose one of soap, washing powder and detergent, add water to one of them to make soapy liquid and apply it to the suspected leakage points, especially at the connections.
  • Page 22 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance NO.2 Air Vent Valve NO.1 Air Vent Valve Automatic breathing valve Figure 5-3-1 Internal container - automatic exhaust valve NO.4 Air Vent NO.6 Air Vent Valve Valve NO.5 Air Vent Valve NO.3 Air Vent Valve Figure 5-3-2 Manifold-Air Vent Valve - 20 -...
  • Page 23 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Automatic exhaust valve Figure 5-3-3 External connecting pipelines - automatic exhaust valve Step 2-3:Procedures for the coolant charge: 1) A self-priming pump must be installed outside the container,The self-priming pump needs to inject liquid into the pump head for the first time.
  • Page 24 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Filling pump NO.9 Ball Valve NO.2 Pressure Gauge NO.8 Ball Valve Safety valve NO.6 Ball Valve NO.7 Ball Valve Figure 5-3-5 Pump station - charging valve Manual liquid filling port Liquid level meter Figure 5-3-6 Pump station - liquid level meter 2)...
  • Page 25: Electrical Wiring

    ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Figure 5-3-7 pressure sensor reading on main interface 6) Then open the circulation pump again, circulate the medium in the system, ensure that the exhaust valves are all opened. 7) Then open NO.6 Ball Valve, close NO.7 Ball Valve, click on the refilling pump on the touch screen interface, and turn it on.
  • Page 26 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Cable inlet hole Cable inlet hole Figure 5-4-1 Cable inlet hole Both sides of the container have grounding studs, and PDC must also be grounded securely. Therefore, ensure that both the container shell and PDC shell are grounded securely. When leaving the factory, the phase sequence of the equipment has been determined.
  • Page 27 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance / 2 nut and gasket from the cooling tower spare parts box, remove the cooling tower air inlet grid, install the liquid level sensor from inside to outside, and install the liquid level sensor as shown in figure 5-4-4 below. The indicator point (depression) - upwards required...
  • Page 28 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Level switch Figure 5-4-4 Installation diagram of liquid level sensor 5.5 System power on and power off process The switches in the electric cabinet are shown in the figure below: MCB17 MCB17 MCB-DC1、DC2、DC3 Figure 5-5-1 ECC 5.5.1 Function description of circuit breaker in the system...
  • Page 29 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Switching function components (No.) MCB17 Main switch of system control power supply and pump station power supply. The system controls the switch of power supply. After the switch is powered on, the system MCB18 has AC220V power supply.
  • Page 30 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance that it can be powered on normally. If there is a short circuit in any of the above items, the fault shall be found out first and then powered on. After the front-end of the system is powered on (the system itself is not powered on), it is also necessary to measure the voltage of the front-end to see whether it meets the power requirements of the equipment.
  • Page 31 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance When the computing unit is powered off, manually stop the liquid cooling system through the touch screen. At this time, the water temperature will rise slightly, but it has no impact on the system. Finally, disconnect the main power supply of the electric control box and distribution cabinet to make the whole system completely powered off.
  • Page 32: Manual Control Screen

    ANTSPACE HK3 Liquid Cooling System Operation and Maintenance main screen, and the motors in the system will be executed according to the automatic control logic sequence. When it needs to be closed, please click "automatic stop" in the main screen. 5.6.2 Manual control screen When the unit needs to add liquid for commissioning, the unit control mode needs to be adjusted to the "manual"...
  • Page 33 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance 5.6.4 Alarm display screen After the system runs, if there is a fault in the system, it will be displayed in this screen. Figure 5-6-4 Alarm display screen After a fault occurs, the alarm sound will sound. You can click "Silence" to first analyze the cause of the fault, then troubleshoot the fault, and finally click "reset"...
  • Page 34 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Figure 5-6-6 Data curve screen Figure 6-6-7 temperature curve Figure 5-6-8 Pressure curve Figure 5-6-9 Flow curve - 32 -...
  • Page 35 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance 5.6.7 Power and positioning picture The screen can display the ambient temperature in the three cabinets,the power used by the two distribution cabinets, and the longitude and latitude of the equipment. Among them, power information and longitude and latitude information are used for debugging and display, and the reading format is float type.
  • Page 36 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance blades, hindering the operation of 2: If there is debris in the fan blade, clean the debris first; if there is no debris, and the fan fails for no reason, operator needs to contact the manufacturer 3: Then reset the thermal relay in the electric control box (1# exhaust fan corresponds to FR21;...
  • Page 37 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance stops spraying. In order to prevent the miner from overheating due to the spray pump stopping spraying, please replenish the cooling tower in time after the alarm. Check whether the fan is running normally, check 1: The cooling fan does not run whether the power supply circuit of the fan is normal...
  • Page 38 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance flow is (refer to the maintenance manual for specific insufficient operations) 2: The filter is clogged Clean the filter element 3: The system is short of liquid System rehydration (low return pressure) 1: Motor burns out Replace the fan In the case of electrification, use a multimeter to...
  • Page 39 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Inspection requirements: the return pressure value is higher than 0.05Mpa (observe the main interface of the touch screen or 1# pressure gauge). If the pressure is lower than this value, it needs to be replenished. Inspection method: visual inspection and data comparison.
  • Page 40: Filter Element

    ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Butterfly repair valve 2 Butterfly repair valve1 Y-type filter of the system Figure 8-3-1 Positions of the butterfly repair valve and the Y-type filter in the pipelines d) After finding the filter, unscrew the cap on the filter with an adjustable wrench. Filter element Drainage tooling Figure 7-3-2 View of filter...
  • Page 41: Maintenance Of Electrical Components

    ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Filter element Figure 7-3-3 Schematic diagram of filter cap unscrewed Sealing gasket End cover of the filter Figure 7-3-4 Schematic diagram of filter cap e) Remove the filter inside the filter for cleaning (or replacement) Installation methods: a)...
  • Page 42 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance 7.3.4 System sewage discharge After two years of operation of the system and the water tank, there may be some sundries in the system pipelines, so the sewage in the system should be discharged in a timely fashion. Sewage discharge steps: a)...
  • Page 43 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Water tank in the container Water tank in the cooling tower Figure 7-3-6 Water tanks in the container and in the cooling tower 7.3.6 Maintenance of coolant 1) As the core unit of ANTSPACE Liquid Cooling System, it is recommended to track and test the coolant regularly, at least once half year.
  • Page 44 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance <20 mg/kg <50 mg/L <50 mg/L <50 mg/L Note 1: Table 7-3-1 is for the working environment temperature is lower than 0 ℃ working conditions need to use the media requirements, if the working environment temperature is higher than 0 ℃ for a long time, you can use deionized water as the secondary side of the internal circulation medium, the corresponding media requirements are shown in Table 7-3-2.
  • Page 45: Operation

    ANTSPACE HK3 Liquid Cooling System Operation and Maintenance Cooling water quality Inclination Items Reference value Corrosion Scaling ⚪ ⚪ PH value(25℃) 6.5~8.0 ⚪ ⚪ Conductivity(25℃) μS/cm <800 ⚪ mg(Cl <200 Benchmark term ⚪ mg(SO <200 ⚪ Acid consumption(pH=4.8) mg(CaCO <100 ⚪...
  • Page 46 ANTSPACE HK3 Liquid Cooling System Operation and Maintenance (4)Be sure to check whether the valve (if there is a valve) is open before starting the system; (5)Safety operation of PDC and electric control cabinet: During the operation of PDC A, B and control cabinet, it shall be ensure that the cabinet door is in a locked state to prevent personal injury such as electric shock, while avoiding salt, moisture, dust or other conductive substances in the air from entering the interior of the cabinet.
