Returns & Faulty Items
• If any problem is encountered during or after installation, please call the All LED technical
department to get the problem resolved as soon as possible.
• Please do not just return the item to the outlet you purchased it from, as you are only entitled to
a replacement or refund after the unit has undergone testing and the unit has been confirmed as
having a manufacturing defect/fault. Your statutory rights are not affected.
• The manufacturer will not be deemed liable or held responsible for any damages caused by faults
or manufacturing defects that may be present in any of its products or the misuse or incorrect
installation of this device. Please refer to our troubleshooting guide for further information.
• All goods are supplied under the terms and conditions of All LED LTD, a copy of which may be
obtained upon written request.
General Information
• Interference may occur with other products on the same frequency of 2.4Ghz
• Product may differ in colour from image on box
• Range signal can be reduced when using within materials such as concrete & metal
Environmental Protection
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
Local Authority or retailer for
recycling advice
The manufacturer will not be deemed liable or held responsible for any damages
caused by faults or manufacturing defects that may be present in any of its products
or the misuse or incorrect installation of this device
Your statutory rights are not affected.
Dimmable Live/Live - Screw Terminal Module
Technical Specifications
Product Code
Operating Voltage (V)
Input Current (A) Max
Max Output Power (W)
Output Voltage (Max)
PF
Efficiency %
Network Standby Power (W)
Class
Body Material
Ingress Protection
Ambient Operating Temperature (°C)
Guarantee
Minimum Load*
ALL LED LTD
42 Sedgwick Road,
*May Require Load Stabiliser if <7W
Luton, LU4 9DT
www.allledgroup.com
sales@allledgroup.com
Tel: +44 (0)208 841 9000
INSTALLATION GUIDE
Smart-R
AiQ/DIM400M/LL
AiQ/DIM400M/LL
100-240VAC
1.84A Max
400W (Halogen); 250W (LED)
100-240VAC
0.99
94%
0.37W
II
White Polymer
IP20
-20°C ~ +50°C
5 Years
7W
!
PLEASE READ
BEFORE USE!
1
