- Page 1 SZ11LR-GW-1 manual LORAWAN GATEWAY PRODUCT MANUAL SZ11LR-GW-1 SHANGHAI SHUNCOM AIOT CO., LTD. www.shuncom.com V1.0...
-
Page 2: Table Of Contents
SZ11LR-GW-1 manual Contents 1. Product Description ............- 1 - Functions and Features ..........- 2 - Product Appearance and Interface ........- 3 - 1.2.1 Product Appearance ..........- 3 - 1.2.2 Interface Definition ..........- 4 - 2. Product Specification ............- 5 - 3. -
Page 3: Product Description
1.Product Description SZ11LR-GW-1 is a kind of Internet of Things wireless communication gateway, which uses the public network wireless network + LoRa network to provide users with the function of eliminating the need of field wiring and wireless long-distance data transmission. -
Page 4: Functions And Features
● Industrial Design, Metal Case, Stable 7x24 Hours Uninterrupted Work Under - 2 - Various Industrial Environments & Strong Interference. ● Standard DIN35 rail installation, also supports wall-mounted installation, suitable for different application scenarios. www.shuncom.com V1.0... -
Page 5: Product Appearance And Interface
1.2 Product Appearance and Interface 1.2.1 Product Appearance - 3 - www.shuncom.com V1.0... -
Page 6: Interface Definition
4G antenna 5G optional LoRa LoRa antenna ZigBee optional Reset button, long press 10s to restore Please consult Shuncom factory settings before reset System operating indicator a) always on when powered, functioning normally, and connected to the Internet; b) flashes once... -
Page 7: Product Specification
2.Product Specification Specification Specification Description Remarks Name Product model SZ11LR-GW-1 Edge Computing Gateway WAN port 10/100/1000Mbps Adaptive network port Network Type Optional Optional Power supply Power supply range DC9~12V / 2A Length × width × height (mm) Dimensions 115 × 131 × 55 Working temperature -40～+80ºC... - Page 8 TDD B41: -93.5dBm (20M) TDSCDMA B34: -110dbm TDSCDMA B39: -110dbm CDMA BC0: -108dbm GSM 900: -110dBm GSM 1800: -109dBm MIPS1004Kc, dual-core, main frequency 880MHz System 256MB eMMC - 6 - Dual-core Cortex-A53 processor, (Optional) Highest main frequency 1.4GHz www.shuncom.com V1.0...
-
Page 9: Device Assembly
If it is not correct, please contact the equipment supplier in time. A packing list is included in the box. Please follow the checklist to check if the equipment accessories are complete. The packing list is shown below. Name Qty(pcs) Remark SZ11LR-GW-1 gateway Power adapter Ethernet cable LoRa antenna 4G antenna Optional... -
Page 10: Maintenance And Support
Device damage due to water ingress is not covered by warranty. For any aftersales service or technical supports, please contact our sales team or technical engineers. SHANGHAI SHUNCOM AIOT CO., LTD TEL: +86(21)-33933988 FAX: +86(21)-33933968-6809 EMAIL: 6831@shuncom.com...
