Thermastone Mantel
Banded Beam 60", 72", 84" - DSTSM5-3, DSTSM6-3, DSTSM7-3
Chiseled Beam 72", 84" - DSTSM6-1, DSTSM7-1,
Classic Beam 60", 72", 84" - DSTSM5-2, DSTSM6-2, DSTSM7-2
Modern Beam 60", 72" 84" - DSTSM5-4, DSTSM6-4, DSTSM7-4
ATTACH YOUR RECEIPT HERE
Serial Number ________________________________ Purchase Date _________________________________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-414-371-1200, 8:00 a.m. – 5:00 p.m. CST, Monday – Friday, or
email us at info@designspecialties.com.
40-01-748
1
Rev 07/13/23
Advertisement
Table of Contents
Summary of Contents for Design Specialties Banded Beam DSTSM5-3
- Page 1 Thermastone Mantel Banded Beam 60", 72", 84" - DSTSM5-3, DSTSM6-3, DSTSM7-3 Chiseled Beam 72", 84" - DSTSM6-1, DSTSM7-1, Classic Beam 60", 72", 84" - DSTSM5-2, DSTSM6-2, DSTSM7-2 Modern Beam 60", 72" 84" - DSTSM5-4, DSTSM6-4, DSTSM7-4 ATTACH YOUR RECEIPT HERE Serial Number ________________________________ Purchase Date _________________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-414-371-1200, 8:00 a.m.
-
Page 2: Package Contents
PACKAGE CONTENTS Modern Beam, Classic Beam 60", & Banded Beam 60"Only PART DESCRIPTION QUANTITY Mantel Corbel Wooden Bracket Support Bracket... - Page 3 Thermastone Statment Thermastone mantels, by Design Specialties, are made of a proprietary mix consisting of industrial grade glass reinforced concrete, fiber mesh, magnesium oxide and poly-resin. The material has many years of proven performance history having been used in select outdoor heating products.
- Page 4 Thermastone mantels are designed to be installed into wood studs or masonry. We have included hardware for installation into wall studs. Installation into masonry may require different fasteners. CAUTION Do not overload the mantel shelf. Maximum weight limit is 100 lbs when using wood studs for mounting.
-
Page 5: Safety Information
HARDWARE CONTENTS CHISELED BEAM - MODELS DSTSM6-1, DSTSM7-1 Dia 8 x 60mm M6 x 35mm M6 Nut M6 x 30mm M5 x 75mm M6*20 Washer Plastic Wall Anchor Qty. 10 Threaded Stud Qty. 4 Washer Mounting Screw Qty. 5 Qty. 4 Qty. - Page 6 ASSEMBLY INSTRUCTIONS 1. CORBEL ASSEMBLY, IF DESIRED. If you do not want to include the corbels, skip this step and go to step # 2. Insert threaded stud (AA) into corbel (B) as illustrated in figure 1A. As illustrated in figure 1B, insert the threaded studs (AA) into the pre-drilled holes in the corbel (B).
- Page 7 ASSEMBLY INSTRUCTIONS 3. For the Modern Beam - models DSTSM5-4, DSTSM6-4 & DSTSM7-4, Classic Beam DSTSM5-2, & Banded Beam DSTSM5-3 ONLY. All other models, please go " to step 4. Insert the support bracket (D) into the man-tel. Place the M6 x 20mm washer (II) onto the support bracket screw (HH) and insert through the pre-drilled holes on the support bracket (D) and into the pre-drilled holes in the mantel (A)
-
Page 8: Year Limited Warranty
ASSEMBLY INSTRUCTIONS 5. Slide the already installed support bracket (D) in the mantel (A) over the wooden support (C) so the wedges line up like in figure 4. THERMASTONE SURFACE CARE Our Thermastone material has been sealed to prevent staining and moisture absorption, but it does require proper maintenance to ensure the integrity of the surface. - Page 9 REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-414-371-1200, 8:00 a.m. – 5:00 p.m. CST, Monday – Friday, or email us at info@designspecialties.com. CHISELED BEAM CHISELED BEAM CLASSIC BEAM CLASSIC BEAM PART DESCRIPTION DSTSM6-1 DSTSM7-1 DSTSM5-2 DSTSM6-2 Mantel 40-01-730...
-
Page 10: Replacement Parts List
REPLACEMENT PARTS LIST Modern Beam, Classic Beam 60", & Banded Beam 60"Only Printed in China...
