Summary of Contents for RPS BTC 2000 480V 3T Series
- Page 1 BATTERY CABINET BTC 2000 480V xx xx 3T For UPS MPW AVARA Multi Power User's Manual BTC 2000 480V AB V9 3T USAB480MV9 BTC 2000 480V BB V6 3T USBB480MV6 BTC 2000 480V BB V7 3T USBB480MV7 BTC 2000 480V BB V8 3T USBB480MV8 BTC 2000 480V BB V9 3T USBB480MV9...
- Page 2 0MN200480NPENUC page 2 / 18...
- Page 3 Thank you for choosing our product. The manufacturer is highly specialised in the development and production of UPS and UPS accessories. The equipment in this series are carefully designed and manufactured in order to ensure the highest levels of performance. SYMBOLS USED IN THIS MANUAL Graphic symbols drawing attention to the dangers of some operations are found in this manual: Possibility of serious injury or substantial damage to equipment if...
- Page 4 Definition of "operator" and "skilled technician" Operators are those professional persons authorised to access equipment for routine maintenance purposes. This definition involves those persons who are familiar with equipment operation and maintenance and meet the following requirements: 1. Trained to operate in accordance with safety standards in relation to the presence of high voltages. 2.
- Page 5 GENERAL WARNINGS This manual contains instructions on the installation and commissioning of battery cabinets. Reading this manual is of essential importance but cannot replace the expertise of technical personnel who must have received adequate training beforehand. This manual should be kept intact and in good condition throughout the life of the equipment This battery cabinet can only be connected to an uninterruptible power supply (UPS).
-
Page 6: Table Of Contents
INDEX BATTERY CABINET STORAGE ..................7 PRELIMINARY OPERATIONS ..................7 BATTERY CABINET HANDLING ..................7 INSTALLATION ENVIRONMENT ..................8 AIR RENEWAL FOR THE BATTERY SITE ..............9 INSTALLATION AND BATTERY CONNECTION ............10 BATTERY CONNECTION ....................11 CONNECTION OF BATTERY CABINET WITH 20+20 BATTERIES ......12 –... -
Page 7: Battery Cabinet Storage
BATTERY CABINET STORAGE The storage site must meet the following requirements: ➢ Temperature: 0°-40°C (32°-104°F) ➢ Degree of relative humidity: 95% max If the batteries contained in the cabinet are not recharged, they become subject to self-discharge. Self- discharge happens faster in higher temperatures (e.g. 40°C) and slower in lower temperatures (e.g. 25°C). -
Page 8: Installation Environment
1 Insert the forks of the forklift at the bottom of the equipment from the front or back, making sure that they protrude about 30 cm on the opposite side. If you plan to use a transpallet, lift the equipment only if absolutely necessary. 2 Fasten the equipment to the transpallet or forklift and move. -
Page 9: Air Renewal For The Battery Site
AIR RENEWAL FOR THE BATTERY SITE The room in which the battery box is installed must be provided ventilated so as to keep the concentration of hydrogen generated during charging within safe limits. The room should preferably be ventilated naturally; if it cannot be, forced ventilation may be employed. Standard EN 50272-2 regarding air exchange provides that the minimum aperture must satisfy the following equation: A = 28 x Q = 28 x 0.05 x n x Igas x C10 (1/10³) [cm²] where:... -
Page 10: Installation And Battery Connection
INSTALLATION AND BATTERY CONNECTION Operations described in this chapter should be performed only by a skilled technician wearing appropriate protective equipment For battery cabinets complete with battery, follow instructions contained in "INSTALLATION INSTRUCTIONS." For empty battery cabinets, first follow instructions contained in "SINGLE UNIT CONNECTION", then in "INSTALLATION INSTRUCTIONS."... -
Page 11: Battery Connection
BATTERY CONNECTION To assemble batteries/single units: • Open and remove the front door to facilitate handling • Remove the two internal "A" and "B" panels, see Fig.1. • Remove the left and right-side panels to facilitate battery installation and connection. THE REAR PANEL OF THE BATTERY CABINET MUST NEVER BE REMOVED. -
Page 12: Connection Of Battery Cabinet With 20+20 Batteries
CONNECTION OF BATTERY CABINET WITH 20+20 BATTERIES Connect batteries to one another as shown in the following drawing, respecting the position of the shelves SHELF 5: BATTERIES 33÷40 SHELF 4: BATTERIES 25÷32 SHELF 3: BATTERIES 17÷24 SHELF 2: BATTERIES 9÷16 SWBAT Table of corrisponding cables nr. -
Page 13: Interconnexions Armoire Batterie - Ups
INTERCONNEXIONS ARMOIRE BATTERIE – UPS Operations described in this chapter should only be performed by a skilled technician wearing appropriate protective equipment. The first connection to be performed is that of the earth conductor. THE BATTERY CABINET MUST NOT OPERATE WITHOUT EARTH CONNECTION Connect wires (not supplied) from the battery cabinet to the UPS terminals. -
Page 14: Start-Up Procedure
START-UP PROCEDURE Checks to be made on the battery cabinet: • Check grounding connection (PE) • Check that the battery switch (-SWBAT) is open • Verify proper “+”, “N” and “–“ polarity in the connection between the battery cabinet and the •... -
Page 15: Auxiliary Contacts, State Of Battery Switch
AUXILIARY CONTACTS, STATE OF BATTERY SWITCH The battery disconnector switch (SWBAT) is equipped with auxiliary contacts to be able to understand and manage their status of a supervision systems. In the following picture the two states of the battery disconnector. With the battery disconnector open the NC contact is closed and the NO contact is open With the battery disconnector closed the NC contact is open and the NO contact is closed How to get the status of the switch (SWBAT) in exchange:... -
Page 16: Technical Features
TECHNICAL FEATURES Composition 20+20 0 40°C (32 104°F) Storage temperature Relative humidity <95 % no condensing 20 25°C (68 77°F) Recommended operating temperature Maximum installation altitude (according Up to 4000m a.s.l. to IEC/EN 62040-3) Pollution degree Vibration resistance 1m/s2 Overvoltage Category / Protection Class... - Page 17 The Company reserves the right to change the product described in this manual at any time without prior notice 0MN200480NPENUC page 17 / 18...
- Page 18 RPS SpA Viale Europa 7 37045 Legnago (VR) Italy...
