G-Series PoE NVR Quick Start Guide
Introduction
The exacqVision G-Series Power over Ethernet (PoE) systems are part of the exacqVision series of network video recorders (NVR). Depending on
the model, the G-Series PoE has either 8 or 16 PoE camera ports. The exacqVision G-Series PoE is an easy-to-use video recording solution that
has the full sophistication of exacqVision video management system (VMS) on a purpose built NVR, without the need to wire cameras to a power
supply.
Installation
Before you turn on the exacqVision G-Series PoE server, ensure that the installation environment meets the following requirements:
Electrical requirements
CAUTION:
Danger of explosion if the battery is incorrectly replaced. Replace the battery with the same or equivalent type according to the
manufacturer's instructions. Discard used batteries according to the manufacturer's instructions.
CAUTION: Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel.
• This equipment is not suitable for use in locations where children are likely to be present.
• This product must be supplied by a UL listed certificate power supply, with an output rated 54 VDC, 3.33 A minimum, TMA 104°F (40°C)
minimum, and an altitude of 16404 ft (5000 m). If you need further assistance, contact https://www.exacq.com/support/techsupport/.
• Connect the information technology equipment (ITE) only to PoE networks without routing to the outside plant.
• The unit uses a three-wire ground cable that is equipped with a third pin to ground the unit and prevent electric shock. Do not remove or
alter this pin in any way. If your outlet does not support this kind of plug, contact your electrician to replace your obsolete outlet.
• The PoE port supports 10/100 Mbps, 802.3 af/at in compliance with a total of 120 W for 8 port and 240 W for 16 port.
Mounting and operating environment requirements
• Mount the G-Series PoE in a dust-free and climate-controlled location where the temperature is between 40°F to 95°F (4.5°C to 35°C) and the
humidity level is less than 80% non-condensing.
•
CAUTION: Dust may cause components of the server to overheat, and elevated temperatures can contribute to premature hard drive
failures.
• If the hard drives dispatch separately to the system, insert each drive into the hard drive slots. If the drives are numbered, ensure that you
insert the correct drive into the appropriate slot.
Electrical environment requirements
• For maximum reliability, connect the G-Series PoE to a UPS power supply. An online UPS filters power surges and dips that can damage the
server.
• Connect a keyboard, a monitor, and a mouse to the server.
• Connect the G-Series PoE network interface cards (NIC) to the appropriate network switch ports.
• Use cables with a ferrite core to connect to the monitors. If the cable does not have a ferrite core, the unit performs as expected, but may
not meet CE safety regulation standards.
Starting the server
When you start the G-Series PoE for the first time, create a user name and password for the operating system, then create a root user name and
password for the Enterprise Manager.
1. Turn on the G-Series PoE.
Create a user name and password for the operating system when the Log on dialog box appears.
2.
500-00121 Rev A
2024-06-21
