QUICK START GUIDE –
For 79761 (79861)
1
Insert USB-C PSU to power grid 230 V
3
LED functionality
Further information on DKTCOMEGA.COM
Sign up for our email newsletter and always be informed first!
2
230 V
POWER
Green:
Off:
DATA
Green Solid: There is data transmission between
Off:
OPT
Green Solid: ONT is ranged to OLT successfully
Red Solid:
Red Flash:
SIGN UP
Insert USB connector into ONT
Power on
Power off
ONT and OLT
There is no data transmission
between ONT and OLT
LOS/LOF
Received optical power is lower
than sensitivity (-27 dBm)
1
Version 1.0.0
Advertisement
Summary of Contents for DKT 79761
- Page 1 QUICK START GUIDE – For 79761 (79861) Insert USB-C PSU to power grid 230 V Insert USB connector into ONT 230 V LED functionality POWER Green: Power on Off: Power off DATA Green Solid: There is data transmission between ONT and OLT...
- Page 2 10G LAN port CAT6a quality of LAN cable or higher Notice that this port supports 1Gbps, 2.5Gbps, 5Gbps and 10Gbps (the ONT auto detects the correct speed) 1G LAN ports CAT5 quality of LAN cable or higher Connect LAN ports to Router LAN port LED will link Traffic it will blink CAT5...
