Kamar LA0217 User Manual

User manual
LA0217
Tourist handheld flashlight LAT-KMR17
Technical data
• Product dimensions: 207x140x110mm
• Flashlight weight: 563g
• USB charging cable(included)
• 2 x 18650 lithium 1200mAh battery(built-in)
• Built-in solar panel
• Battery life:
XPG 3W 100% power - 4.5 hours
COB 1W 100% power - 4 hours
• Charging time: 5 hours
• Battery life: 800 charge cycles
• Led Quantity: 1x XPG 3W 230LM + 1x COB 1W 380LM
• Material:
ABS Plastic + Metal
• Manufacturer's CE declaration of conformity
Functions
The handheld LED flashlight illuminates the working area from the position of the user's hand. The flashlight has 6 light functions
and 3 utility functions:
• Press the top ON/OFF button once: XPG 3W 100% light
• Press the top ON/OFF button twice: XPG 3W 50% light
• Press the top ON/OFF button 3 times: XPG 3W 100% strobe light
• Double press and hold the upper ON/OFF button: light intensity adjustment 100%-50%-100%
• Press the bottom ON/OFF button once: COB light 1W one side 100% power
• Press the lower ON/OFF button twice: COB 1W light intensity adjustment 100%-50%-100% for one or both sides
** disabling each of the above functions is done by toggling all functions until flashlight is turned off.
• Powerbank function to charge another device
• Built-in solar panel located at the bottom of the flashlight that allows you to charge the batteries using energy from daylight
• A metal holder that allows you to hang the flashlight in the selected place
Wire connection
• Charging the product using a USB cable (the USB Type-C socket is located under the rubber seal in the body of the flashlight)
• The USB 5V 1A output socket is located next to the USB-C input socket
The source of charging can be devices with a USB socket and electrical sockets of a home or car installation with the use of an
•
appropriate adapter
Warnings
• Use as intended
• The flashlight may become warm during long use
•
Product not for use by children
• The flashlight is not waterproof
We reserve the right to change technical data and possible errors. Photos/drawing and technical data
are only illustrative, and given product may slightly differ from them. Coping the part or the entire
package without the written authorization is forbidden. All rights reserved.
The marking on the product or in the related texts indicates that it should not be disposed of with other household waste at the end of its useful life. To avoid damaging the environment and human health by
uncontrolled disposal, please separate the product from another type of waste and recycle it responsibly to promote the reuse of material resources as a permanent practice.For information on where and how to
safely recycle this product, household users should contact the retailer where they purchased the product. Users in companies should contact their supplier and check the terms of the purchase agreement.The
product should NOT be disposed of with other commercial waste.
Important! Do not look directly at the light. It can cause the eye damage
Correct disposal of the product(used electrical and electronic equipment)
Manufacturer: KAMAR Knapkiewicz S.K.A.
• ATTENTION! The ba ery is not replaceable
It is forbidden to interfere with the device.
Terms of warranty:
- we provide a guarantee for a period of 24 months from the date of sale,
- any unauthorized interference with the item entails the loss of the guarantee.
al. Armii Krajowej 254
85-689 Bydgoszcz, Poland
Country of origin: PRC
www.myKAMAR.com
