English
Diagram Reference
Appearance
1
RS-485 Wireless Receiver
Status Indicator
1
Enrollment or Deleting: Red and green alternately flash every second.
Notes:
Product Information
-For remote enrollment, the device will automatically exit the registration
mode.
©2021 Hangzhou Hikvision Digital Technology Co., Ltd.
-For local enrollment, the device will exit the enrollment mode 1 minute
All rights reserved.
after the operation.
About this Manual
Operation Completed: flashing green
The Manual includes instructions for using and
Operation Failed: flashing red
Receiver Power Down: solid red
managing the Product. Pictures, charts, images and all
Working Properly: solid green
other information hereinafter are for description and
Control Panel Power Not Ready/Receiver Deleted: off
explanation only. The information contained in the
Signal Strength Check: solid yellow
Manual is subject to change, without notice, due to
Reset Compeleted: flashing green 3 times
firmware updates or other reasons. Please find the
2
Power Indicator
latest version of this Manual at the Hikvision website
Solid green after power-on
(https://www.hikvision.com/).
Please use this Manual with the guidance and
3
RS-485 Terminal
assistance of professionals trained in supporting the
4
Tamper Button
Product.
Power Terminal
5
Trademarks
and other Hikvision's trademarks and
6
DIP Switch
logos are the properties of Hikvision in various
Reset Button
7
jurisdictions. Other trademarks and logos mentioned
are the properties of their respective owners.
Note:
The power can also be supplied by control panel on the model of DS-PHA20-P,
DS-PHA20-W2P, and so on. The power supply of the control panel is made by
Disclaimer
Shenzhen Honor Electronic Co., Ltd and meets LPS.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
THIS MANUAL AND THE PRODUCT DESCRIBED, WITH ITS
Wiring
2
HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES
1
RS-485 Terminal
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
2
Power Terminal
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY
QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE
DIP Address Settings
3
OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO
EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL,
The DIP address can be set as 0 to 23.
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
When the switch is towards ON, the binary value is 1. You can set the
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
DIP switch as the
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
Note:
DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
The address of the receiver should be unique.
DOCUMENTATION, WHETHER BASED ON BREACH OF
Installation
4
CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
a. Front Panel b. PCB Board c. Screws d. Rear Panel
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF
1. Install the rear panel.
THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
Secure the rear panel on the wall with 5 screws.
POSSIBILITY OF SUCH DAMAGES OR LOSS.
Loosen the screw on the bottom of the receiver to dissemble the device
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET
before installation and wiring.
PROVIDES FOR INHERENT SECURITY RISKS, AND HIKVISION
2. Fix the PCB board on the rear panel.
SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL
3. Route the cables.
OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES
4. Fix the front panel on the rear panel by tightening the set screw.
RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER,
Reset:
HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF
Press and hold the reset button to power on, and continue to hold the
REQUIRED.
reset button for 2 s, the device will reset.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL
APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR
Specification
ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE
LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS
Wireless zone
PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE
RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION,
Wireless keyfob
RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR
DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL
Output
NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES,
INCLUDING THE DEVELOPMENT OR PRODUCTION OF
Wireless siren
WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY
RF frequency
ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR
RF modulation
EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN
SUPPORT OF HUMAN RIGHTS ABUSES.
RF distance
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL
AND THE APPLICABLE LAW, THE LATER PREVAILS.
Tamper-proof
INSTALLATION CAUTION
Reset button
1. The additional force shall be equal to three
times the weight of the equipment but not less
Power supply
than 50N. The equipment and its associated
Power consumption 1.2W
mounting means shall remain secure during the
installation. After the installation, the equipment,
Temperature
including any associated mounting plate, shall not
Humidity
be damaged.
2. Install the equipment according to the
Dimension
instructions in this manual.
(L × W × H)
3. To prevent injury, this equipment must be
securely attached to the wall in accordance with
Weight
the installation instructions.
Note: The 868 Mhz wireless sounder can be enrolled to the hybrid control
panel via the wireless receiver that is at the address of 9.
UD15866B-C
1
2
2
table displayed in diagram 3.
3
1
2
Lowbit
00010 ->2
00000 ->0
00001 ->1
00010 ->2
00011 ->3
16
00100 ->4
8
00101 ->5
00110 ->6
2 output expander
00111 ->7
2
01000 ->8
433 MHz, 868 MHz
01001 ->9
2 GFSK
01010 ->10
400 m (opean area)
01011 ->10
2 (front/rear panel)
1
12 VDC, 100 mA
a
-10 °C to 55 °C
10% to 90%
160 mm × 105 mm × 28 mm
195 g (no packaging)
7
1
6
5
2
4
3
1
Security Control Panel
D +
D
-
+
12V
G
RS-485 Terminal
Power Terminal
RS-485 Wireless Receiver
3
4
5
1
2
3
4
5
Highbit
Lowbit
Highbit
01000 ->8
4
105mm
01100 ->12
01101 ->13
01110 ->14
01111 ->15
10000 ->16
10001 ->17
10010 ->18
10011 ->19
10100 ->20
10101 ->21
10110 ->22
10111 ->23
b
c
d
Español
Diagrama de referencia
Apariencia
1
1
Indicador de estado
Registro o eliminación: cada segundo, parpadeará alternativamente en
color rojo y verde.
Notas:
-En el registro remoto, el dispositivo saldrá automáticamente del modo de
registro.
-En el registro local, el dispositivo saldrá del modo de registro 1 minuto
después de la operación.
Operación completada: parpadeará en color verde
Error de funcionamiento: parpadeará en color rojo
Receptor apagado: color rojo fijo
Funciona correctamente: color verde fijo
Panel de control no preparado/receptor eliminado: apagado
Comprobación de la fuerza de la señal: color amarillo fijo
Reinicio completado: Parpadeará 3 veces en verde
Piloto de alimentación
2
Color verde fijo tras el encendido
3
Terminal RS-485
Botón antimanipulación
4
Borne de alimentación
5
Interruptor DIP
6
7
Botón de reinicio
Nota:
En los modelos DS-PHA20-P, DS-PHA20-W2P y sucesivos, también se puede
suministrar la alimentación a través del panel de control. La fuente de
alimentación del panel de control ha sido fabricada por Shenzhen Honor
Electronic Co., Ltd. y cumple con el suministro eléctrico de baja tensión.
Cableado
2
1
Terminal RS-485
2
Borne de alimentación
Ajustes de la dirección del DIP
3
La dirección del DIP se puede establecer de 0 a 23.
Cuando el interruptor está en ON, el valor binario es 1. Puede ajustar
el interruptor DIP siguiendo la tabla
que se muestra en el
diagrama 3.
Nota:
la dirección del receptor debe ser exclusiva.
Instalación
4
a. Panel frontal b. Placa de circuito impreso c. Tornillos d. Panel trasero
1. Instale el panel trasero.
Asegure el panel trasero a la pared con 5 tornillos.
Antes de realizar la instalación y el cableado, desmonte el receptor
aflojando el tornillo en la parte inferior del mismo.
2. Fije la placa PCB en el panel trasero.
3. Pase los cables.
4. Fije el panel frontal sobre el panel trasero apretando el tornillo de
ajuste.
Reiniciar:
Mantenga pulsado el botón de reinicio para encender el dispositivo y
manténgalo pulsado durante 2 s más para que se reinicie.
Especificación
Zona inalámbrica
16
Llavero transmisor inalámbrico 8
Salida
Expansor de 2 salidas
Sirena inalámbrica
2
Frecuencia de RF
433 MHz, 868 MHz
Modulación de radiofrecuencia 2 GFSK
Distancia de RF
400 m (área abierta)
Antimanipulación
2 (panel frontal/trasero)
Botón de reinicio
1
Fuente de alimentación
12 VCC, 100 mA
Consumo eléctrico
1,2 W
Temperatura
De -10 °C a 55 °C
Humedad
10 % a 90 %
Dimensiones
160 × 105 × 28 mm
(La. x An. x Al.)
Peso
195 g (sin embalaje)
Nota: La sirena inalámbrica de 868 Mhz se puede registrar en el panel de
control híbrido a través del receptor inalámbrico que se encuentra en la
dirección 9.
