  • Page 1 Gigabit Switch Quick Start Guide UD36249B...

  • Page 2: Applicable Models

    Preface Applicable Models This manual is applicable to NS-0500R series gigabit switches. Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text.

  • Page 3: Product Introduction

    1 Introduction 1.1 Product Introduction NS-0500R series switches are unmanaged gigabit network switches, providing sixteen or twenty-four gigabit Ethernet ports to upload data via convergence switches. The devices support one-button switching among four working modes: standard switch, port isolation, port aggregation, and network clone. The devices are reliable, easy to install and maintain, and equipped with rapid switching functions.

  • Page 4: Rear Panel

    Rear Panel NS-0516R/NS-0524R Series Table 1-2 Port/Indicator Description Port/Indicator Description ● Solid on: The switch is powered on normally. ● Unlit: No power supply is ① PWR Indicator connected or power supply is abnormal. ● Solid on: The switch works in this Working mode.

  • Page 5: Installation

    Working Mode Description All downlink ports are isolated from each other and can communicate only M2 Port with uplink ports. This mode is used for Isolation broadcast storm suppression network performance improvement. Uplink ports are aggregated into one M3 Port aggregation group.

  • Page 6: Rack Mounting

    Wall Mounting Rack Mounting Steps 1. Check the grounding and stability of the rack. 2. Use M3 screws provided in the package to fix the two L-shaped brackets to both sides of the device. Fix L-Shaped Brackets to the Device 3.
  • Page 7 Fix the Device to the Rack 3 Wiring Connect Grounding Cable Grounding is used to quickly release overvoltage and overcurrent induced by lightening on the device, and to protect personal safety. Select an appropriate grounding method according to the installation conditions. Note The following figures are for your reference only.
  • Page 8 Figure 3-2 Grounding with Angle Steel Connect RJ45 Port Use a network cable to connect the device to the RJ45 port of a peer device such as network camera (IPC), network video recorder (NVR), switch, etc. Figure 3-3 RJ45 Port Connection Note When the device is connected to a network camera (IPC), a separate power supply is required for the IPC.

This manual is also suitable for:

Ns-0524rNs-0516r
