Summary of Contents for Hours SRC-201
- Page 1 Remote Controller SRC-201・Instruction Manual Ver. 1.0 HOURS www.hours-shop.com...
- Page 2 Please do not hesitate to contact us for any inquiries regarding the use of product. Contact information is listed below. Sigma Koki Co.,Ltd. Tokyo Head office, International sales division TEL +81-3-5638-8228 / FAX +81-3-5638-6550 E-mail: international@sigma-koki.com URL: http://www.sigma-koki.com/ HOURS www.hours-shop.com...
-
Page 3: Table Of Contents
ONNECTING RDER 8. C ....................15 OMMUNICATION ETTINGS 9. C ........................16 OMMAND LIST CHAPTER 4. RS232C SERIAL COMMUNICATION OPERATING SRC-201 FROM PC . 22 10. SRC-201 C RS232C ..............22 ONNECTING RDER FOR 11. C & C ..............22 OMMUNICATION... -
Page 4: For Your Safety
●Do not touch the product when your hands are wet. ●Do not use in outdoors. ●Do not leave the product in an enclosed area or in areas in which it would be exposed to direct sunlight or vibration. HOURS www.hours-shop.com... -
Page 5: Chapter 1. Before You Begin
※Driver should be installed in PC for PC control. Please refer to Chapter 3 for installation. 2. Overview The SRC-201 is exclusive controller for Remote Actuator operation. Micromotion similar to Micrometer head by Micromotion Knob, and simple manual operation by JOG Switch can be performed. Actuator can be controlled from PC connected using USB and RS232C interface. -
Page 6: Name And Function Of Each Part
3. Name and Function of Each Part 3-1. Name of Each Part ①POWER LED ⑦Micromotion Knob ②Interface Selector Switch ⑥JOG Switch ⑤STOP LED ③Transmission Handle ④RUN LED ⑧ I/O Connector ⑨ RS232 Connector ⑩ USB Connector ⑪Motor Connector ⑫Power Terminal ⑬Power Switch HOURS www.hours-shop.com... - Page 7 ※ Equivalent to TCS7147-012177 by Hosiden ⑫Power Terminal Connect to our exclusive use AC adapter. Do not use the adapter other than the attached. ⑬Power Switch Power is on/off when the switch is set to ON/OFF. HOURS www.hours-shop.com...
- Page 8 ② When the switch position is PANEL, a drive command is received via a front panel or USB. Inquiry command is received via USB. ③ When the switch position is I/O, a drive command is received from external device. Inquiry command is received via RS232C. HOURS www.hours-shop.com...
-
Page 9: Chapter 2. Operation Manual For Src-201
Chapter 2. Operation Manual for SRC-201 4. SRC-201 Connecting Order ① Connection between SRC-201 and Remote Actuator Please make sure that this product has been powered off. Connect actuator to motor connecter of this product. ② Connection between SRC-201 and I/O jump connector Please connect I/O jump connector attached to the I/O connector. - Page 10 ・ Jog operation will be performed with constant speed corresponding to the number of click turned when the pressed condition is maintained. ・ RUN LED is lit when actuator is operated. ・ It stops when handle is released. Turn while pressing HOURS www.hours-shop.com...
-
Page 11: Alarm
This product detects overload at internal circuit and automatically stops its operation. When internal circuit alarm is detected, STOP LED on front panel flashes twice per second. Please power down once and check the status of the load. HOURS www.hours-shop.com... -
Page 12: Chapter 3. Usb Serial Communication Operating Src-201 From Pc
Chapter 3. USB Serial Communication Operating SRC-201 from PC 7. SRC-201 Connecting Order 7-1. Driver Installation (for Windows XP) This product performs USB serial conversion using FT232 by FTDI. For PC control, driver should be installed in PC. Installation order of Windows 32bit driver Ver.2.08.08 will be described below as an example. Windows is registered trademark for Microsoft Corporation USA in the USA and other countries. - Page 13 ⑤Connect AC adapter to power terminal of this product. ⑥Power this product on by setting power switch to ON. ⑦Install driver after startup of new hardware search wizard. Select ‘Install from a list or specific location (Advanced)’ ⑧Assign a folder unzipped. HOURS www.hours-shop.com...
- Page 14 ⑨Install USB Serial Converter. Select ‘Continue Anyway’ ⑩Select ‘Install from a list or specific location (Advanced)’ HOURS www.hours-shop.com...
- Page 15 ⑪Assign a folder unzipped. ⑫Install USB Serial Port. HOURS www.hours-shop.com...
- Page 16 Device Manager and check COM number for USB Serial Port. (COM2 is used in example) ②Set COM Port number you wish to use from Port settings Setting details. ※Do not select Port number currently in use. It may cause communication problem with other device in connection. Unused Port Number HOURS www.hours-shop.com...
-
Page 17: Communication Settings
7-3. Connect SRC-201 to PC Connect SRC-201 to PC. ①Please make sure that power has been set off. ②Connect actuator of your choice to motor connecter of this actuator. ③Connect I/O jump connector to I/O connector of this product. ④Connect AC adapter to power terminal of this product. -
Page 18: Command List
※Attention 5. Also, when the actuator reached at stroke end, it is mostly mechanically locked, and overload may be falsely detected when recovering from stroke end. When recovering from stroke end, make operation at maximum speed. HOURS www.hours-shop.com... - Page 19 ：＋ or － Set to + for (＋) direction, Set to － for (－) direction ・Comments It sets jog operation and operation direction. G command is required after implementing this command. Example) J:1－ Jog operation towards (－) direction Activation starts. HOURS www.hours-shop.com...
- Page 20 ・Command type L:1 (or L:W) ・Comments It stops activation of actuator. (6)R Command ・Command type R:1 (or R:W) ・Comments It sets current coordinates to electric (logical) origin. Coordinate will be set to zero after this command has been implemented. HOURS www.hours-shop.com...
- Page 21 Default value is set according to the position of transmission handle. Once the power is switched off, speed will be reset. Example) D:1S0F2100R0 Set to speed 2100. HOURS www.hours-shop.com...
- Page 22 (Status check command 2) ・Command type ・Returning data type Busy status L, Q, and ! commands are acceptable Ready status Ready to accept any commands ・Comment It responds status of stage movement. (ACK3 : response data of Q command) HOURS www.hours-shop.com...
- Page 23 ・Returning data type (Example) V01.00 ・Comment It responds software version (ex. Ver.1.00) (12)?:S Command (Speed check command) ・Command type ・Returning data type (Example) 00043 ・Comment It responds the speed setting. Available speed settings range from 1 to 48. HOURS www.hours-shop.com...
-
Page 24: Chapter 4. Rs232C Serial Communication Operating Src-201 From Pc
Chapter 4. RS232C Serial Communication Operating SRC-201 from PC 10. SRC-201 Connecting Order for RS232C Connect SRC-201 to PC. ①Please make sure that power has been set off. ②Connect actuator of your choice to motor connecter of this actuator. ③Connect I/O jump connector to I/O connector of this product. -
Page 25: Chapter 5. I/O Control
H=0, L=1 ⇒ Speed 14 0：Open H =1, L =0 ⇒ Speed 39 1：Short Speed set H input H =1, L =1 ⇒ Speed 47 Disabled Output common Connecter used is equivalent to 10214-52A2PL by Sumitomo 3M I/O connector wiring diagram HOURS www.hours-shop.com... - Page 26 I/O port Connection Example HOURS www.hours-shop.com...
-
Page 27: Src-201 Connecting Order For I/O Control
13. SRC-201 Connecting Order for I/O Control Connect SRC-201 to PC. ①Please make sure that power has been set off. ②Connect actuator of your choice to motor connecter of this actuator. ③Connect I/O jump connector to I/O connector of this product. -
Page 28: Chapter 6. Specifications
8bits None ・Parity ・Stop Bit 1bit ・Flow Control None CR+LF ・Delimiters 16. Connector Pin Assignment 16-１.MOTOR connecter Number Name Number Name Motor ＋ Motor － Motor ＋ Motor － Connecter used is equivalent to TCS7147-012177 by Hosiden Corporation HOURS www.hours-shop.com... - Page 29 Connecter used is equivalent to DX2R005HN2 by JAE 16-3. I/O connector I/O connector signal Please refer to page 23 for 16-4. RS232C connector Number Name Connected to 8 pin Connected to 7 pin Connecter used is equivalent to XM3B-0942-502L by Omron HOURS www.hours-shop.com...
-
Page 30: Outlines
17. Outlines HOURS www.hours-shop.com...
