Quick Start Guide
for RackMac Studio
Rackmount Enclosure for Mac Studio
™
Support Note:
This document was up to date at
the time of printing. However, changes to the
hardware may have occurred since then. Please check the
Sonnet website for the latest documentation.
1. Go to https://www.sonnettech.com/support/kb/kb.php
2. Navigate to and click the RackMac Studio link.
3. Click the Manual link.
4. Click the RackMac Studio Quick Start Guide [English]
link and then check the Document Version information.
If the version listed is later than this document
(revision B), click the Download Now button for the
latest version.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sonnettech RackMac Studio
Summary of Contents for Sonnettech RackMac Studio
- Page 1 Please check the Sonnet website for the latest documentation. for RackMac Studio 1. Go to https://www.sonnettech.com/support/kb/kb.php 2. Navigate to and click the RackMac Studio link. Rackmount Enclosure for Mac Studio 3. Click the Manual link. ™...
- Page 2 RackMac Studio Package Contents Description Rackmount Enclosure USB-A Ports 1 – These connect to the installed Mac Studio computers to the right of the ports through cables attached to the front panel. 2 – Power Switches These buttons activate the Mac Studios’ rear-mounted power switches.
- Page 3 Computer Installation Steps 1. Remove the RackMac Studio rackmount enclosure from its packaging, and then set it on a flat, level surface. 2. Using the eight supplied screws, secure the included rack ears to the rackmount enclosure (Figure 1). Figure 1 3.
- Page 4 Computer Installation Steps 4. Remove a Mac Studio computer from its packaging, and then carefully insert it into the rackmount enclosure as shown. Push the computer in until it stops (Figure 3). Repeat this step if you are installing a second computer. Figure 3 5.
- Page 5 8. If you are planning to place SSDs or other devices in one or both accessory spaces beneath each computer, skip to the Accessory Installation Steps below. 9. If you haven’t already installed the RackMac Studio into its rack or case, do so now. 10. Connect interface and power cables between devices and computers as necessary;...
- Page 6 Accessory Installation Steps Support Notes: If the rack or case the RackMac Studio is installed in will be moved around, you should secure any drives or other devices you install inside the enclosure. If you are installing SSDs or some other device, use the included self-adhesive magnets to secure them.
- Page 7 Mac Studios from drawing in warm air through the accessory space openings. 6. If you haven’t yet installed the RackMac Studio into its rack or case, do so now. 7. Connect interface and power cables between devices and computers as necessary;...
-
Page 8: Safety Precautions
©2022 Sonnet Technologies, Inc. All rights reserved. Sonnet, SONNETTECH and the Sonnettech logotype are trademarks of Sonnet Technologies, Inc. Mac Studio is a trademark of Apple Inc., registered in the United States and other countries.
