FUSION 6000-X
USER MANUAL
INTELLECTUAL PROPERTY
All Intellectual Properties, as defined below, owned by or which is otherwise the property of Chemyx Inc. or its suppliers relating to the Chemyx syringe pumps, including but not limited to, accessories,
parts or software relating thereto (Chemyx Syringe Pumps), are proprietary to federal and state laws, and international treaty provisions. Intellectual Property includes but is not limited to, inventions
(patentable or unpatentable), patents, trade secrets, copyrights, software, firmware, computer programs, and related documentation and other works of authorship. Moreover, you agree that you will
not, and will not attempt to, modify, prepare derivative works of, reverse engineer, disassemble the Chemyx syringe pumps, decompile or otherwise attempt to create source code from the related
software/firmware. No title to or ownership in Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with Chemyx and its suppliers.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FUSION 6000-X and is the answer not in the manual?

Questions and answers

Related Manuals for Chemyx FUSION 6000-X

Summary of Contents for Chemyx FUSION 6000-X

  • Page 1 INTELLECTUAL PROPERTY All Intellectual Properties, as defined below, owned by or which is otherwise the property of Chemyx Inc. or its suppliers relating to the Chemyx syringe pumps, including but not limited to, accessories, parts or software relating thereto (Chemyx Syringe Pumps), are proprietary to federal and state laws, and international treaty provisions. Intellectual Property includes but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, firmware, computer programs, and related documentation and other works of authorship.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents..............................2 General Description...............................4 Product Overview..............................5 Principle of Operation..........................5 Controlled Elements..........................6 Specifications...............................8 Prime Button................................9 Pump Setup................................10 Powering On/Off the Pump........................10 Loading a Syringe.............................10 Adjusting the Safety Nut/Stall Rod......................11 Pump Operation............................13 Mode Selection Screen..........................14 Pressure & Temperature Settings........................15 Pressure Mode..............................16 Basic Mode................................17 Syringe...
  • Page 3 Pump Control..............................26 System Settings...............................27 Motor Force..............................28 Pump Control by Computer...........................29 Cable Requirements............................29 Connecting ................................29 COM Port Settings..........................30 Pump Commands............................31 Chemyx Pump Controller Programs......................36 Warranty and Repair Information.........................37 Warranty Information........................37 Dead Pixel Policy..........................38 Serial Numbers...........................38 Calibrations............................38 Pump Maintenance.............................39 Lubricating the Pump.........................39 Lubrication Instructions........................39...

  • Page 4: General Description

    CHEMYX PRODUCTS ARE NOT APPROVED FOR CLINICAL USE ON HUMANS. USE PROPER POWER SUPPLY Chemyx is not responsible for the use of power supplies outside the stated electrical specifications or failure to switch the power converter from 220V to 110 V while in the 220V environment or vice versa.

  • Page 5: Product Overview

    Product Overview FUSION 6000-X The Chemyx Fusion product line serve a wide variety of applications. The Chemyx Fusion 6000-X is a high-pressure syringe pump designed for dosing viscous solutions, and semi-solid material injections against pressure. The units’ flexibility with syringe types and sizes and an advanced software interface make this high-pressure syringe pumps integrable into any operation or laboratory work flow.

  • Page 6: Controlled Elements

    The two guide rods keep the pusher block horizontal and perfectly perpendicular to the lead screw. Tightening the knob will lock the pusher block back in place. As for the Fusion 6000-X, the pusher block can only be moved back and forth from the pump screen in the menu section.
  • Page 7 FUSION 6000-X SPECIFIC COMPO- Flange Retaining Bracket Bracket Release Knob The Fusion 6000-X is capable of both infusion and withdrawal on a single pump channel. The Fusion 6000-X also uses an adjustable retaining brackets on the pusher block and the syringe holder block that keep the syringe in place during both infusion and withdrawal.

  • Page 8: Specifications

    Fusion 6000-X Data Sheet The Fusion 6000-X high-pressure syringe pump is designed for dosing viscous solutions, and semi-solid material injections against pressure. This system allows also for heated temperature control and pressure modulation while providing precision flow and performance. It includes prime buttons that allow you to easily adjust the push blocker to the syringe.

  • Page 9: Prime Button

    Prime Button The Fusion 6000-X includes a Prime Button that allows you to easily adjust the push blocker of your syringe. To learn more and see how it works visit: https:/ /www.chemyx.com/support/knowledge-base/the-difference-between-the-new- chemyx-fusion-6000-x-and-fusion-6000-syringe-pump/...

  • Page 10: Pump Setup

    Pump Setup Powering On/Off the Pump To provide power to the pump, a power cable should be plugged into the power socket on the back of the pump. The cable should be plugged into an appropriate power source (110V or 220V) with proper grounding. The power switch for the pump is located on the back, above the power socket.

  • Page 11: Adjusting The Safety Nut/Stall Rod

    FUSION 6000-X 1. If necessary, move and tighten the infusion safety rod (see Adjusting the Safety Rod). 2. To move the pusher block use the Forward and Reverse functions that can be found on the menu screen of the pump. Move the pusher block all the way to the right 3.
  • Page 12 To protect against this potential problem, Fusion 6000-X use a stall rod to physically stop the pusher block before it can completely depress the syringe plunger. When a pusher block hits the safety mechanism and can no longer move forward, the pump will stop running, emit a long beep, and enter pump-stalled mode.

  • Page 13: Pump Operation

    Pump Operation Operating Interface Limits for selected fields Selected Fields Deselected Field The LCD screen displays a graphical user interface (GUI) from which all the pump settings and run parameters are entered. Whenever an item is currently selected, the color scheme of the element typically turns to a darker shade of the color. For example, the light blue buttons turn dark blue when selected, and the white background surrounding a deselected editable text field turns blue when the field is selected and available for editing.

  • Page 14: Mode Selection Screen

    NAVIGATING BETWEEN SCREENS All of the screens in the Fusion Series GUI exist in a hierarchy, with the Mode Selection screen at the top. Entering a new screen is performed simply by activating, or tapping, a button or icon that opens the new screen. To return to the previous screen, tap or activate the red “X”...

  • Page 15: Pressure & Temperature Settings

    Pressure & Temperature Settings (Fusion 6000-X The Temperature Settings screen allows you to control the optional syringe heaters for the Fusion 6000-X pump. The options on the screen allow you to start the heater with flow, control temperature, pre-heat the syringe and then start the pump as well as setting a timer on the syringe heater.

  • Page 16: Pressure Mode

    How To Set Up Constant Pressure Mode 1. Go to the main manual and press Pressure into the pressure set up page. Fusion 6000-X Main Menu 2. Enter the Target Pressure number. The default number of Flow Rate Adjustment is 1. If the time to reach the target pressure is too long, increase the flow rate adjustment number slowly.

  • Page 17: Basic Mode

    Basic Mode Basic Mode (or Single-Step Mode) is used for applications that do not require advanced automation, variable volume and rate settings, step looping, or ramping rates. The Basic Mode screen can be reached by tapping on the water droplet icon on the Mode Selection screen. Basic Mode allows users to select the syringe being used, to set a valid volume and rate, and to choose whether to infuse or withdraw.

  • Page 18: Volume

    When a particular syringe is selected from the list on the right, an Import button will appear next to the selected item. Tapping the Import button (or pressing the Enter key on the navigation keypad) will import the inner diameter associated with the selected syringe and exit the Syringe Library screen.

  • Page 19: Infusion/Withdrawal

    Additionally, high flow rates can exert tremendous pressure within a syringe that may cause glass or plastic syringes to burst. In the case of high-pressure experiments, users should consider using Chemyx Stainless-Steel Syringes and the high-pressure Chemyx Fusion 6000-X pump.

  • Page 20: Start-Time Delay

    START-TIME DELAY The Delay field represents the amount of time (in minutes and seconds) to delay starting the pump after the current step begins. When entering this value with the numeric keypad, the decimal key is used to indicate the separation between minutes and seconds.

  • Page 21: Options

    Options The Fusion Series is capable of both infusion and withdrawal. On the systems, an Infusion/Withdrawal toggle button should appear when the Volume field is selected. The bubble form indicates the mode that is currently set and direction that the pusher block will move upon starting the run. Volume Settings screen FLOW-RATE UNITS The flow-rate units determine which units of volume and time will be used for the Volume and Rate fields.

  • Page 22: Multi-Step Mode

    Multi-Step Mode Multi-Step Mode is used for more advanced applications that may require numerous steps, multiple different volume and rate settings, step looping, or ramping rates. The Multi-Step Mode screen can be reached by tapping on the Menu icon on the Mode Selection screen. The pump can only be started in Multi-Step Mode when the Multi-Step Mode screen is showing.

  • Page 23: Total Steps

    TOTAL STEPS The Total Steps field determines how many steps will occur in the method. Each step has independent values for Volume, Rate, Delay, and Infusion/Withdrawal. Upon entering the number of steps, the list on the left of the screen will update to show all of the steps.

  • Page 24: Flow-Rate Units

    FLOW-RATE UNITS Tapping the Volume or Pump Rate button opens a screen that allows flow-rate units to be set. The flow-rate unit determines which unit of volume and time will be used for the Volume and Rate fields for all of the steps. This setting in Multi-Step Mode also changes the units for Basic Mode.

  • Page 25: Step Parameters

    Step Parameters Every step in the multi-step method will have a selectable entry in the list. At the top of the screen you will find a place to enter your syringe size as well as the number of steps the multi-step method to take. Tapping the step will allow you to change the Volume and Rate.

  • Page 26: Pump Control

    PUMP CONTROL The pump’s actions are controlled by the Stop, Pause, and Start keys on the front. In order to start a run, the screen should be showing either the Basic Mode (for basic runs) or Multi-Step Mode (for multi-step runs) main screens. Pressing the Start key in either other these screens will start a run with the currently set parameters.

  • Page 27: System Settings

    System Settings The System Settings screen can be reached by tapping on the Menu icon on the Mode Selection screen. System Settings screen BAUD RATE The baud rate is the rate at which information is transferred through the serial connection. This rate is often limited by the type of serial connection used.

  • Page 28: Motor Force

    MOTOR FORCE The Fusion 6000-X pumps can generate up 700 lbs of linear force. LCD POWER-OFF TIME The LCD display goes to sleep after 1 hour after the last interaction with the pump controls. When the display goes to sleep, the pump is still on. It will continue to run the current method and is able to receive commands via computer...

  • Page 29: Pump Control By Computer

    Pump Control by Computer Cable Requirements Two types of connections are available for external computer control: DB9 and USB, cables for each are available for purchase through Chemyx (call 1-281-277-5499 or visit www.chemyx.com/contact-us). DB9 Serial Cable (Male-to-Female) USB-A to USB-B cable For the DB9 serial connection, a Male-to-Female DB9 cable must be used.

  • Page 30: Com Port Settings

    COM PORT SETTINGS Regardless of the operating system being used, the terminal program controlling the serial connection should use the following connection settings: Baud Rate 9600 or 115200 Data Bits Parity None Stop Bits Flow Control None The baud rate setting for the serial connection must match the baud rate set in the pump settings GUI (See Baud Rate in System Settings).

  • Page 31: Pump Commands

    Pump Commands Regardless of the operating system being used, the terminal program controlling the serial connection should use the following connection settings: Command Description help Displays a list of available commands. Starts the pump with the currently set parameters. The parameters that will run depend upon start which mode (Basic Mode or Multi-Step Mode) the pump touchscreen is showing.
  • Page 32 Command Description Sets the transfer volume. The pump will run until the volume infused or withdrawn equals this volume. This command also sets whether the pump is infusing or withdrawing (Fusion 200 only) and the number of steps used in Multi-Step Mode. X must be an integer or decimal (up to five decimal places) within the volume limits for the syringe (See read limit parameter command).
  • Page 33 Command Description Sets the transfer rate for infusion/withdrawal. X must be an integer or decimal (up to five decimal places) within the rate limits for the syringe (See read limit parameter command). For Basic Mode, only one value is required. Example set rate 1.0 To set rates in Multi-Step Mode, the pump must be manually switched to Multi-Step...
  • Page 34 Command Description Sets the start time delay (in minutes) prior to each step of a pump run. Upon starting the a step, the pump will wait until the delay time elapses before starting to transfer volume. X must be an integer or decimal (up to five decimal places) within the rate limits for the syringe (See read limit parameter command).
  • Page 35 Command Description Returns the current status of the pump. The returned integer correlates to the status of the pump. 0: Pump stopped 1: Pump running status 2: Pump paused 3: Pump delayed 4: Pump stalled Returns: integer that represents the current status of the pump. Sets multiple parameters in one command (Basic Mode only).

  • Page 36: Chemyx Pump Controller Programs

    Chemyx Pump Controller Programs In addition to the manual control of the pumps through a terminal, Chemyx provides pump controller programs as an unsupported open-source applications written in Python, a LabVIEW package, and a MATLAB package. More information on these tools can be found on the website at www.chemyx.com/support.

  • Page 37: Warranty And Repair Information

    Warranty Information Chemyx provides a two-year limited warranty (1) first year for parts and labor (2) second-year for parts only from the shipment date for its pumps against defects in materials and workmanship. Chemyx will repair product that proves defective during its stated warranty period.

  • Page 38: Dead Pixel Policy

    Although the pump is highly accurate, syringes of different materials can attribute significant volume errors. Typically, these errors can range from 1% for glass syringes to 5% for plastic syringes. Chemyx is not responsible for errors generated from syringes.

  • Page 39: Pump Maintenance

    Pump lubrication should be performed every three months. Approved Lubricants • Engine/motor oil • Silicone oil • Machine oil • Tooling oil or “WD-40” • Lithium-based grease Please contact Chemyx (call +1 281-277-5499 or visit www.chemyx.com/contact-us) to confirm the safe use of a different lubricant.

  • Page 40: Pump Accessories

    Chemyx syringes. For more information visit chemyx.com/products/stainless-steel-syringes/ Stainless Steel Syringes Detect pressure digitally on the Fusion 6000-X. This Fluke PV350 Pressure Vacuum Module is able to maintain a user-defined pressure throughout the withdrawal or infusion process.
  • Page 41 Chemyx Stainless-Steel Syringes. O-Ring Streamline laboratory operations with this electric foot switch control that lets you start, stop, or pause your Chemyx syringe pump systems—even when your hands are full. The electric foot pedal switch connects seamlessly to computerized pumping programs,...

  • Page 42: Attaching Rack

    ATTACHING THE RACK ON THE FUSION 6000-X Fusion 6000-X Syringe 4 Channel Rack Holder Syringe Clamp Screws for Syringe 4-Channel Rack Holder Plunger Retaining Bracket Screws for Plunger Retaining Bracket 4-Channel Syringe Rack fully assembled on the Fusion 6000-X with 4 steel syringes...

  • Page 43: Appendices

    Appendices Appendix A: Syringe Volume/ Inner Diameter Reference CHEMYX STAINLESS STEEL HAMILTON GLASS Size Diameter Size Diameter 6.00 mL 9.53 mm 0.50 μL 0.10 mm 20.00 mL 19.13 mm 1.00 μL 0.15 mm 50.00 mL 28.6 mm 2.00 μL 0.21 mm 5.00 μL...
  • Page 44 NORM-JECT PLASTIC JMC AIR-TITE PLASTIC Size Diameter Size Diameter 1.00 mL 4.66 mm 1.00 mL 4.70 mm 2.00 mL 6.90 mm 2.50 mL 9.70 mm 2.50 mL 9.10 mm 5.00 mL 12.48 mm 5.00 mL 12.62 mm 10.00 mL 15.89 mm 10.00 mL 14.34 mm 20.00 mL...
  • Page 45 TERUMO JAPAN SGE GLASS Size Diameter Size Diameter 1.00 mL 4.73 mm 25.00 μL 0.73 mm 1.00 mL 6.50 mm 50.00 μL 1.03 mm 3.00 mL 8.65 mm 100.00 μL 1.46 mm 5.00 mL 13.00 mm 250.00 μL 2.30 mm 10.00 mL 15.80 mm 500.00 μL...
