- Page 1 Nasal Aspirator Model: LA131103 RoHS REACH MDSS GmbH Schiffgraben 41 30175 Hannover Germany AViTA Corporation 9F., No. 78, Sec. 1, Kwang Fu Rd., San Chung Dist., New Taipei City 24158, Taiwan. China, AViTA(WUJIANG) Importer Distributor...
-
Page 2: Table Of Contents
INSTRUCTION MANUAL Please read this instruction manual carefully before operating this unit Contents Intended Use ............................1 Introduction ............................1 Important Information Before Use ..................... 3 Product Features ..........................6 Battery Installation ........................... 7 Instructions For Use ......................... 9 Cleaning and Disinfecting......................11 Technical Specifications ........................ -
Page 3: Intended Use
Intended Use The device is designed for using intermittent suction to remove nasal secretion and mucus in Children (age 0~12 years old) at home environment. Note: Children of age 0~12 years old are intended population, the device should be operated on the children by their parents. Introduction Place the silicone tip into the nostril, turn on the device, then you may use the device to remove nasal secretions. - Page 4 comfortable for baby use. Washable Head Module Design: tips, collection cup and head module can be removed from the device for cleaning. (Collection cup can also be disinfected with hot water.) Light Weight & Low Noise: easy to use while the baby is sleeping. Replaceable Tip: Long / Short Tip Available.
-
Page 5: Important Information Before Use
Important Information Before Use Contra-indications Users with damage to the integrity of the mucous membrane of the nasal passages and some individual features of the structure of the nasal septum. Caution - Do not modify this equipment without authorization of the manufacturer. - Page 6 - It is recommended to use this device intermittently. Press the power button to generate vacuum for removing nasal secretions. To stop the suction, release the power button. - The Nasal Aspirator is intended for cleaning/removing the nasal secretions only. Do not use the device other than the designated purposes.
- Page 7 NOTE: ．This Nasal Aspirator must only be used with AViTA NS series Tip. Please contact local retailer to buy replacement of the accessories.
-
Page 8: Product Features
Product Features... -
Page 9: Battery Installation
Battery Installation Replacing the Battery: - Slide the battery cover off. - Insert or replace 2 x 1.5 V AA batteries into the battery compartment, ensuring to match the indicated polarity symbols. - Replace the battery cover. Battery-operated - Always use NEW batteries; never mix old and new batteries. - Page 10 away from small children and heat. - It is recommended to remove the batteries if the unit will not be used for an extended period of time. - Batteries must be disposed of in accordance with local environmental and institutional policies. - Remove the battery during extended storage.
-
Page 11: Instructions For Use
Instructions For Use 1. Choose the most favorable tip based on the anticipated use. ．Short tip: recommended when the mucus is more solid. ．Long tip: recommended when the mucus is more liquid or thin. 2. Attach the selected tip firmly to the head module. 3. - Page 12 4. Press and hold the power button to activate the aspirator and ensure it is operating correctly before placing into the nostril. 5. Place the silicone tip into the nostril and allow the suction to clear the mucus. Repeat in the other nostril as needed. Discontinue using immediately if the user is uncomfortable.
-
Page 13: Cleaning And Disinfecting
Cleaning and Disinfecting The following cleaning procedures should be performed daily or as needed when the device is being used regularly; failure to properly clean your unit may result in clogging and shortened product life. Carefully separate the tip and head module from the device housing. - Page 14 It is recommended that the silicone tip, head module and collection cup to be rinsed with hot water between uses to prevent mucus from drying and clogging the unit. Cleaning (at the end of the day / as needed): Wash the collection cup and tip with mild, non-abrasive soap and water.
- Page 15 extreme temperatures, high humidity, direct sunlight, or shock. Allow all pieces to dry completely before reassembly. NOTE: Protect the nasal aspirator from mechanical shock or heavy impact. Store the unit in an area away from sunlight, dust and humidity.
-
Page 16: Technical Specifications
Technical Specifications Effective Vacuum Pressure: 350~500 mmHg(±5%) - Sound Pressure Level: ≦75dB - Motor: 3V/DC - Power supply: 2 x 1.5V “AA” alkaline batteries - Aspiration Tip: Soft Silicone - Operating environment: 16℃~35℃ (60.8℉~95℉) relative humidity 15%~85% (non condensing) atmospheric pressure 700~1060 hPa - Storage/ Transportation environment: -25℃~+55℃... - Page 17 - Product Life Time: 3 years.
-
Page 18: Troubleshooting
Troubleshooting Problem Cause Remedy The suction Batteries are low or Check or replace batteries. is weak or improperly installed. there is no The gray rubber ring Make sure there is a gray suction at all located where the rubber ring where the collection cup screws in collection cup screws in. -
Page 19: Emc Tables
EMC Tables LA131103 is intended for use in the electromagnetic environment specified below. The customer or the user of LA131103 must make sure that it is used in such an environment. Guidance and manufacturer’s declaration - Electromagnetic emissions Professional healthcare... - Page 20 Voltage fluctuations Not applicable and flickering (Note: Power by Battery or DC Input) Only the AC input needs to be tested a) The equipment is suitable for use in Home Health Environments and Professional Health Care Environments limited to patient rooms and respiratory treatment facilities in hospital or clinics.
- Page 21 RF wireless NOTE: Further information about communications distances to be maintained between equipment portable and mobile RF communications equipment (transmitters) and the LA131103 can be requested from supplier using the contact information provided in this manual. However, it is advisable to...
- Page 22 keep the equipment at an adequate distance of, at least, 0.5 m from mobile phones or other RF communications transmitters to minimise possible interference. RATED power IEC 61000-4-8 30 A/m c) frequency 50 Hz or 60 Hz magnetic fields. a) The equipment is suitable for use in Home Health Environments and Professional Health Care Environments limited to patient rooms and respiratory treatment facilities in hospital or clinics.
-
Page 23: Explanation Of Symbols
Explanation of Symbols The CE marking with the Registration Number of the Notified Body. This denotes the compliance of Regulation (EU) 2017/745 Medical Device Manufacturer Authorized representative in the European Community... - Page 24 Date of manufacture (YYYY-MM-DD or YYYY-MM) Batch code (YYMMWWWW) Serial number (YYMWWWXXXXX) Keep dry Indicates a medical device that needs protection from light sources.
- Page 25 Temperature limit Humidity limitation Atmospheric pressure limitation Caution Consult the instruction for use...
- Page 26 Disposal information: Should you wish to dispose of the article, do so in accordance with current regulations. Details are available from your local authority. WEEE 2012/19/EU Directives This product fulfilling the requirements of the RoHS RoHS Directive 2011/65/EU. This product fulfilling the requirements of the REACH Directive EC 1907/2006 and its amendments, do not contain Substances of Very High Concern in REACH...
- Page 27 Device classification type BF This product meets the basic safety and essential performance requirements indicated in the IP22 conditioning test (protection against solid foreign objects of 12.5mm ∅ and greater and against vertically falling water drops when enclosure tiled up to 15°) The empty, completely flat batteries must be disposed of through specially designated collection boxes, recycling points or electronics retailers.
- Page 28 Distributor Model Number Country of Manufacturer Unique Device Identifier Electronic IFU available at http://www.avita.com.tw NS17P-22245LA 2023-2-1...
