START-UP GUIDE
Set Bar
Thumb Grips
Easy-Set
Latch
LED
Indicator
Light
Power
Button
Trap
Mounting Holes
Bait Tie
Kill-Bar
Down
QR Code
Label
Victor
VLINK
Rat Trap Model: V430B
®
®
1. Before you begin, confirm that you have a VLINK account
created and an Admin has added you to the account. Contact
your VLINK sales representative for confirmation if you are unsure.
2. Confirm that you can successfully log-in at
www.app.digitalpestmanagement.com.
Rodent Grabbing
2. CONNECT THE GATEWAY
Teeth
Plug in the gateway.
Bait Cup
For all other gateway instructions, contact your VLINK
Sales Representative.
3. DOWNLOAD THE APP
1. Search for the Victor VLINK Digital Pest Management app
from the Apple App Store or Google Play Store and download
to your device.
2. Log-in using your VLINK account credentials.
Kill-Bar
3. Follow the VLINK site setup to ensure your deployment
site is correctly set up in the VLINK app.
4. CONNECT TRAP TO THE NETWORK
1. Remove the plastic battery pull tab at the front end of the trap.
2. Press the power button to turn the trap on.
3. You will see three green LED lights indicating that the trap
is on.
4. Follow the steps in the VLINK app to add the trap to
the site.
LED Light Sequences
• 3 quick green flashes – trap powering on
• 3 quick red flashes – trap powering off
• 3 long green flashes – LoRa message successfully sent
• 1 long orange flash – trap is set
• 2 quick orange flashes – trap going into sleep mode
1. ACCOUNT SET-UP
5. BAIT TRAPS
Paste Baits
1. Place paste baits in the bait cup container.
2. Ensure bait is firmly in cup to prevent it
from being pulled out easily by the rodent.
3. Placing bait on the trigger petal may lead
to non-capture triggers.
Tied Baits
1. Tie desired bait to raised Victor® V.
2. Orient bait towards middle of trap pedal.
After Baiting
Pull back using thumb grips to set the trap. You will see 1 long
orange flash to indicate trap is set, immediately followed by
three long green flashes to indicate a message has been sent.
Note: Setting the trap can only be accomplished if the
trap is level. If it is tilted significantly, it will not set.
6. PLACE TRAP
Once your trap is connected, place it in the area of rodent
activity and wait for the trap to alert you of a capture.
7. RESET TRAP AFTER A KILL
1. If a rodent has been captured, record your kill data using the
VLINK Mobile App.
2. Once the rodent is removed, the trap is ready to be baited
and reset for another capture.
3. To reset, simply pull the kill bar back to the set position
and wait for the three green LED flashes to let you know the
trap is communicating and ready for another kill.
4. The trap must send a message for the kill notification to clear.
Pro Tip: Avoid using strong cleaning products on the traps.
A captured rodent can leave behind scent and odor that can
make the trap more attractive to other rodents.
