- Page 1 APERTO 1300 | QAP13 Assembly Instructions May 2024 © Quadro Concepts International 2024...
- Page 2 Please contact Quadro Concepts International through the website for support. 7. Ensure that all parts are included before starting to assemble. Please contact Quadro Concepts International through the website with any issues or enquiries. 8. Assembly on flat, level surface using a soft underlay to avoid damage.
-
Page 3: Limited Warranty
6. If the product has any defects or does not work as intended during the Warranty Period, Quadro Concepts International Pty Ltd will at its election and at its expense repair or replace the product. 7. The Warranty does not apply: to cosmetic damage sustained during or after initial assembly;... - Page 4 Content : Box [1 of 4] 1300 - Bench Top and Back Panel Bench Top Content : Box [2&3 of 4] Legs x2 - LHS and RHS Identical QAP 13 Assembly Instructions May 2024 QAP 2400 | Assembly Instructions September 2021...
- Page 5 LHS & RHS Hardware 20x Bolt- M6 16x Washer- Small 4x Adjustable feet- M8 1x M-F brass extension 1x F-F brass elbow adaptor 4x Washer- Large © Quadro Concepts International 2024 | 5 QAP 2400 | Assembly Instructions September 2021...
-
Page 6: Setup Options
Set-Up Options BENCH LEFT-ORIENTED BENCH RIGHT-ORIENTED *APERTO Outdoor Kitchens are designed to be set up either left or right-oriented by simply rotating the bench top QAP 13 Assembly Instructions May 2024 QAP 2400 | Assembly Instructions September 2021... -
Page 7: Step 1: Base Assembly
*assemble Base on a soft underlay *do not stand parts on the stone edge *avoid stone-on-stone contact *assemble with two people to avoid damage to the porcelain stone © Quadro Concepts International 2024 | 7 QAP 2400 | Assembly Instructions September 2021... - Page 8 QAP 13 Assembly Instructions May 2024...
-
Page 9: Step 2: Bench Top
Step 2: Bench Top NOTE: *do not stand parts on the stone edge *avoid stone-on-stone contact *assemble with two people to avoid damage to the porcelain stone © Quadro Concepts International 2024 | 9... - Page 10 QAP 13 Assembly Instructions May 2024 © Quadro Concepts International 2021...
- Page 11 *do not stand parts on the stone edge *avoid stone-on-stone contact *assemble with two people to avoid damage to the porcelain stone *hand-tighten all bolts first, align components, then tighten using tool *access from underneath the bench top © Quadro Concepts International 2024 | 11...
- Page 12 Step 2: Bench Top NOTE: *lift bench into final position with two people *adjust feet to ensure stable and level position *be careful not to tip the unit onto a stone edge to avoid porcelain stone damage QAP 13 Assembly Instructions May 2024...
- Page 13 *there is a dedicated left-hand and a dedicated right-hand bracket *brackets are mounted to the inside of the bench top frame *Use slots to locate brackets correctly © Quadro Concepts International 2024 | 13 QAP 2400 | Assembly Instructions September 2021...
- Page 14 Step 4: Tray NOTE: *slide tray onto brackets *tray acts as heat shield QAP 13 Assembly Instructions May 2024 QAP 2400 | Assembly Instructions September 2021...
- Page 15 Example: Artusi ABBQ Range IMPORTANT Follow the ULPG gas installation instructions in the appliance user manual. Preparation and connection for natural gas has to be done by a certified professional. © Quadro Concepts International 2024 | 15 © Quadro Concepts International 2021...
- Page 16 Note: All content and visuals accurate at time of printing. www.quadroconcepts.com For latest information about the Quadro Concepts range of products be sure to email contact@quadroconcepts.com IG @quadroconcepts or visit quadroconcepts.com...
