- Page 1 Wireless Card and Antenna (Port C) Kit Instructions 7772-K167/K168 Issue C © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 2: Copyright
NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current. -
Page 3: Table Of Contents
Table of Contents Copyright Wireless Card and Antenna (Port C) Kit Contents 7772-K167 WiFi 6 Wireless Card and Antenna, CX7ii 7772-K168 Wireless Card and Antenna, CX7 and CX5 Installation Procedure Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 4 Revision Record Issue Date Remarks Jun 2020 First Issue Dec 2021 Added Warning statement Apr 2024 Added 7772-K167 WiFi 6 Wireless Card and Antenna, CX7ii Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 5: Wireless Card And Antenna (Port C)
Kit Number Description 7772-K167 WiFi 6 Wireless Card and Antenna (Port C), CX7ii CX7ii (7772) 7772-K168 Wireless Card and Antenna (Port C) CX7 (7772) CX5 (7773) Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 6: Kit Contents
Kit Contents 7772-K167 WiFi 6 Wireless Card and Antenna, CX7ii Item Part Number Description 497-0534991 KIT - Wireless Card and Antenna, CX7ii 006-8627556 Screw - M3x4mm Phillips, Low Profile, Black 006-8628633 WiFi 6E AX210 (Gig+) Commercial Temperature Embedded Module, vPro, M.2... -
Page 7: 7772-K168 Wireless Card And Antenna, Cx7 And Cx5
FCC ID / IC Label for 9260 497-0423108 Instructions — Kit (Reference Sheet) * Items marked with an asterisk are not called out on the image. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 8: Installation Procedure
Remove the two (2) screws that secure the Cable Cover to the Back Cover. b. Rotate and unhook the Cable Cover from the Back Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 9 Remove the Ethernet Cable from the Cable Management Hook then disconnect the Cable. 4. Loosen the two (2) captive screws that secure the Back Cover to the Display. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 10 5. Rotate the Back Cover away from the Display and unhook the Back Cover Tabs. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 11 6. Insert a flat screw driver in the slot to unsnap the Peripheral Filler Plate from Port C of the display housing. 7. Insert the Wireless Card into the connector. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 12 8. Secure the Card with a screw. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 13 9. Route the first Antenna Cable through the port opening located as shown and pull the Cable completely through. If present, remove the protective cover from the Micro Coax Connector. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 14 10. Remove the adhesive liner from the Antenna and place the Antenna on the location marked “1” on the display housing. Ensure the solder joint of the Antenna is within the opening. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 15 11. Route and secure the Antenna Cable under the Cable Management Hooks as shown. Route the Cable above the upper edge of the Speaker. 12. Connect the first Antenna Cable to Connector 1 (Aux) of the Wireless Card. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 16 13. Route the second Antenna Cable through the port opening located as shown and pull the Cable completely through. If present, remove the protective cover from the Micro Coax Connector. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 17 14. Remove the adhesive liner from the Antenna and place the Antenna on the location marked “2” on the display housing. Ensure the solder joint of the Antenna is within the opening. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 18 16. Connect the second Antenna Cable to Connector 2 (Main) of the Wireless Card. For clarity, the first Antenna Cable is not shown in the illustration. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 19 19. Reconnect the 180-degree USB-C Cable and Ethernet Cable. 20. Reinstall the Cable Cover. 21. Place the FCC ID / IC Label on the Certification Label as shown. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
