- Page 1 Instruction Manual Backup Sensor System (Waterproof) RVS-115-W Rear View Safety, Inc. © 2024...
-
Page 2: Table Of Contents
System Description......3 Safety Information......4 Before Beginning Installation . -
Page 3: System Description
This high-quality sensor system is the complete package that works independently of other systems and comes with everything needed for installation. This Backup Sensor System provides drivers with a detection range of 8 feet. The system comes with 4 sensors which mount on the rear bumper and a small LED display console. -
Page 4: Safety Information
If you have questions about this product, contact: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT. -
Page 5: Before Beginning Installation
Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. -
Page 6: Cable Connection Diagram
Cable Connection Diagram Installation Overview 1) Drill four holes for the four (4) waterproof sensors at equal distance in the rear bumper: 21.5 mm when not using grommet 25.00 mm when using grommet 2) Mount sensors using the included grommets (Optional) 3) Connect the sensors to the Sensor Harness Cable 4) Connect Sensor Harness Cable to Control Module 5) Connect LED Display to Power Harness Cable... -
Page 7: Display Diagram
Display Diagram Bracket Left Sensor Alarm Right Sensor Safety Zone Alarm Caution Zone Detection Distance Danger Zone Volume Settings High Volume Switch Display Switch DISPLAY SETTINGS Flip Numerical Display - Display installed on the Dashboard Mirror Numerical Display - Display installed on TOP of Rear Windshield Normal Numerical Display - Display installed on TOP of Windshield VOLUME SETTINGS --- High... -
Page 8: Sensor System Diagram
Sensor System Diagram Sensor Visual and Audible Warnings Distance from Sound Information Visual Information Warning Sensor & Obstacle Zone Sound Unit: In. Unit: Ft. LED Bar Display Code 0" < D < 8" 0' < D < 0.6' Bi… Danger Digits 8"... -
Page 9: Waterproof Control Module Diagram
Waterproof Control Module Diagram Sensor Power Harness Harness Connector Connector Reverse With Confidence ™... -
Page 10: Sensor Detecting Angles
Sensor Detecting Angles Horizontal Angle (50°) Vertical Angle (59°) Rear View Safety... -
Page 11: Sensor Specifications
Sensor Specifications Sensor Type: Analog Sensor Sensor Quantity: 4 Sensors Sensor Frequency: 40 kHz +/- kHz Static Capacitance: 2000± 15%pF Input Voltage max.: 140 Vp-p {at 40KHz) Decay Time: <1.2ms Decay Parameter : 20±3 (Admissible parameter) Echo Sensitivity: >200 mV Horizontal Angle: 50°... -
Page 12: Warranty
ONE YEAR WARRANTY REAR VIEW SAFETY, INC. WARRANTS THIS PRODUCT AGAINST MATERIAL DEFECTS FOR A PERIOD OF ONE YEAR FROM DATE OF PURCHASE. WE RESERVE THE RIGHT TO REPAIR OR REPLACE ANY SUCH DEFECTIVE UNIT AT OUR SOLE DISCRETION. REAR VIEW SAFETY, INC. IS NOT RESPONSIBLE FOR A DEFECT IN THE SYSTEM AS A RESULT OF MISUSE, IMPROPER INSTALLATION, DAMAGE OR MISHANDLING OF THE ELECTRONIC COMPONENTS. -
Page 13: D I S C L A I M E
DISCLAIMER REAR VIEW SAFETY AND/OR ITS AFFILIATES DOES NOT GUARANTEE OR PROMISE THAT THE USER OF OUR SYSTEMS WILL NOT BE IN/PART OF AN ACCIDENT OR OTHERWISE NOT COLLIDE WITH AN OBJECT AND/OR PERSON. OUR SYSTEMS ARE NOT A SUBSTITUTE FOR CAREFUL AND CAUTIOUS DRIVING OR FOR THE CONSISTENT ADHERENCE TO ALL APPLICABLE TRAFFIC LAWS AND MOTOR VEHICLE SAFETY REGULATIONS. - Page 14 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Engineered For Vehicle Safety™...
