TIMEBIRDS BigBird Quick Start Manual

Thank You for purchasing the Timebirds® BigBird workout
timer. Upon receipt of the product, check for any defects prior to
first use. If defects are found, do not use and contact Timebirds
immediately.
Safety | It is important to read an understand all instructions
before using Timebirds® BigBird. Only use Timebirds® BigBird as
described in the manual.
Warning | Do not overload wall outlets, extension cords, or
adapters beyond their capacity. Avoid placing the device near
extreme heat. Refrain from attempting to repair the device on
your own. Avoid placing your ears next to the buzzer, as it may
cause significant pain and possible hearing loss. Always recycle
or dispose of your device according to your local environmental
laws and guidelines. Remember that poorly structured or
executed workouts may cause personal injury. Proper setup and
use of this device are the responsibility of the user. Timebirds®
bears no liability beyond the replacement value of the device
Notice | Timebirds® BigBird is not waterproof and may incur
damage if exposed to water. Please ensure it is always kept in
a dry or covered area. Avoid dropping, throwing, or bumping
the device to prevent damage. Ensure that Timebirds® products
are not used as toys, and do not allow children to use the device
without proper supervision or instruction.
Product Care | Always store Timebirds® BigBird in a clean and
dry environment. To clean, wipe it with a damp cloth; do not use
harsh chemicals or cleaning agents. Do not disassemble, attempt
to repair, or modify it.
Specifications
Model: TIMEBI-BIG-1A1-BLA
FCC ID: 2BC92-TIMEBI-BIG
Power Input: 9v 2.5A 22.5W
Weight: approximatively 5kg.
Maximum volume: of the Piezo is 103db.
Operating Temp: 10 – 60 degrees Celsius / 50 – 140 Fahrenheit.
Dimensions: 715 x 213 x 42mm or 28.2 x 8.4 x 1.6 in.
Warranty | Timebirds® BigBird is covered by a 12-month limited
warranty for manufacturer's defects and faults. The warranty
does not cover normal wear and tear or cosmetic damage. The
warranty does not cover negligent or improper use, alteration,
mishandling, self-repair, poor maintenance, water damage
or incorrect storage. For more information about Timebirds®
warranty, visit www.timebirds.com
Customer Service | For more information, troubleshooting,
warranty, and replacement information please visit
www.timebirds.com. Please contact us at team@timebirds.com
for return addresses and replacements before returning your
product.
@timebirdstimers @timebirds @timebirds
In the box
• 1x BigBird Timer
• 1x remote control
• 1x 220/110v power adapter
Remote control | Install two AAA batteries (not included) in the
back of the remote control. You can change the system code by
holding + any of the key pad.
Pull down the
cover, insert 2x
AAA batteries
(not included)
as indicated,
and then close
the cover.
Installation | Timebirds® BigBird can stand on its edge or be
mounted on a wall using the optional wall mount. Power your
BigBird using the provided power adapter.
Front
Buzzer
Power
(9v 2.5A 22.5W)
Front lens
1. SCREENS
General Screens
Off
Home screen
Count up mode
Count down mode
Interval training mode
Tabata mode
Fight gone bad mode
Beep test
Clock mode
Timer settings
Clock setting
Sound setting
memory setting
Timebirds OS version
Stopwatch
Paired with device
Sound off (muted)
Sound on
Timer ready
Time out.
2. SETTINGS
Set the clock
• Press the increment button to cycle modes until
• Press to accept and display settings
• Press the increment button to cycle settings until
• Press to accept and advance
back
• Select for a 12 or 24 hour format and press
• Use the key pad to adjust the flashing digits and Press
accept
NOTE: Timebirds® BigBird will autmatically synchronize to your
local time zone once paired with your device.
On the clock screen, use the backward and forward buttons to
toggle between HH:MM and HH:MM:SS time formats
When a timer is running
Wall mount
(optional)
• Press once to pause
• Press once to start
• Hold for 2s to restart your workout
Timebirds and Timebirds logo are Trademarks of Timebirds Pty Ltd registered in Australia and other countries.
2023 Timebirds Australia Pty Ltd, all rights reserved. BigBird_how_to_v1_SEPT23
1
Clock Screens
AM time
PM time
12 hours clock format
24 hours clock format
Workout Memory
Reset last workout settings
Save last workout settings
Mode Setting Screens
Counting up
Counting down
Set a working time
Set a test time
Set number of rounds
Counting up
Count down
to advance
to
