Summary of Contents for StarLogixs FARM HAWK 2.5D-1
- Page 1 Instruction Manual Model: 2.5D-1 Designed and Made in Australia by...
-
Page 2: Table Of Contents
Table of Contents Package Contents……………………………………………………………..1 Fitting the Solar Assembly…………………………………………………2 Setting up the Energiser……………………………………………………2 Connecting the Fence & Earth Leads…………………………..…...4 Operating the Energiser…………………………………………….……..4 Earthing the Energiser………………………………………………….…..5 Fence Construction……………………………………………………….….6 Fence Conditions ……………………………………………………….…….7 Pulse Repetition Rate……………………………………………………….8 Low Battery……………………………………………………………..……….8 Low Fence Voltage……………………………………………………………9 D-Pulse Technology………………………………………………………….9 Fence Issues that can Impact D-Pulse Performance………..10 Replacing Parts……………………………………………………………….11 Lightning Protection &... -
Page 3: Package Contents
Package Contents 1 x Main case 1 x Solar Assembly 1 x Screw to attach solar assembly 2 x Connection Leads (1 Earth, 1 Fence) 1 x Manual 1_________________________________________________________________________... -
Page 4: Fitting The Solar Assembly
Fitting the Solar Assembly Refer to Diagram 1 (Page 3) 1) Align the solar assembly with the main case as shown below and slide straight down. Ensure dovetails on solar assembly engages behind ribs on main case to form a secure connection. - Page 5 Diagram 1 3_______________________________________________________________________...
-
Page 6: Connecting The Fence & Earth Leads
Connecting the Fence & Earth Leads To connect the Fence & Earth leads, unscrew and remove each black nut located on the unit. Connect the red lead to the fence terminal and replace corresponding knob. Connect the black lead to the earth terminal and replace corresponding knob. Operating the Energiser Press the power button and the centre bars in the display will flash on for 0.5... -
Page 7: Earthing The Energiser
Earthing the Energiser The earthing system will play an important role in the efficiency of your energiser and is also critically important in case of lightning strike. The earth connecting lead should be kept as straight as practical and never coiled or bundled up. -
Page 8: Fence Construction
Fence Construction The construction of rural electric fences are subject to the following standards: AS/NZS 60335.2.76:2019 and IEC 60335-2-76 Ed3, MOD The points below are a summary of the relevant clauses and should be adhered to when building an electric fence system on your property. A complete list of requirements can be found in the above referenced standards. -
Page 9: Fence Conditions
6). Any part of an electric fence installed along a public road must be identified with signs at regular intervals. These signs must be firmly attached to posts or attached to the fence wires. These signs must be yellow with black markings at least 25mm (1") high and either show an approved shock hazard warning symbol or the words "CAUTION: Electric Fence"... -
Page 10: Pulse Repetition Rate
Pulse Repetition Rate During the day when the battery is receiving charge from the solar panel the energiser will pulse once every second. At night or during periods of low solar charge this pulse rate is automatically extended to once every 1.5 seconds, to conserve battery charge. Low Battery If the battery charge falls to a low state then the dot on the right hand end of the display will illuminate. -
Page 11: Low Fence Voltage
The ideal situation is to have the convenience and portability of a small solar panel with a high energy output pulse. The StarLogixs D-Pulse technology is the first solar energiser to achieve this. -
Page 12: Fence Issues That Can Impact D-Pulse Performance
Fence Issues that can Impact D-Pulse Performance The D-Pulse technology works by sending a low energy pulse, and monitoring fence voltage for sudden changes. The assumption is that animal activity involving fence contact will on average be a very low proportion of the total time the energizer is running. So a small battery and solar panel can provide power for the small energy output pulses and the occasional animal contact. -
Page 13: Replacing Parts
Replacing Parts We recommend you scan our QR codes to view instructions for replacing parts. Scan our QR Code for a video demonstration: Replacing Battery: Alternatively, this video can be accessed via – https://youtu.be/9re3c-08L1s Replacing Solar Panel: Alternatively, this video can be accessed via – https://youtu.be/ZjDPClxQ3uc 11_______________________________________________________________________... -
Page 14: Lightning Protection & Warranty
StarLogixs service facility, or transportation cost. StarLogixs is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the energiser or other damages with respect to any economic loss, loss or profits, loss or revenues or profit, cost of removal, installation or re-installation. -
Page 15: Specifications & Industry Standards
Specifications Stored Energy: Low Energy Pulse Output = 0.27 Joules High Energy Pulse Output = 2.5 joules Solar Output: Greater than 150mA in full sun Output Voltage: No Load – 8000V 2000 OMH Load – 5400V 1200 OHM Load – 4100V Battery: 12V 7AH Sealed Lead Acid –... -
Page 16: Copyright, Warnings & Contact Us
StarLogixs Pty. Ltd. The technology in this product is subject to patents applied and exclusively the property of StarLogixs.
