Summary of Contents for Savitech LHDC ONE
- Page 1 Manual...
-
Page 2: Table Of Contents
Embrace true UltraRes audio Table of Contents User Guide Product Overview Inside the Box LED Indicator Overview Pairing with LHDC ONE Reconnect LHDC ONE to Bluetooth Device Button Switch Functionality Troubleshooting and Solutions Operational Guidelines... -
Page 3: Product Overview
Embrace true UltraRes audio Product Overview Inside the Box: SR_LED LHDC One Bluetooth Transmitter x 1 Sampling Rate Indicator (SR_LED) LHDC-X Spatial Audio Tool (S-PHRTF App) x 1 Operation Card x 1 USB-C BT_LED Bluetooth Indicator (BT_LED) Switch Button Analog Output... - Page 4 Bluetooth Indicator (BT_LED) Blue Light: Device connect Red Light: Device dis-connected Green Light: Device is in low latency mode Flashing Red and Blue Lights: LHDC ONE in pair- ing mode SR_LED Sampling Rate Indicator (SR_LED) BT_LED White Light : SBC 48Hz...
-
Page 5: Pairing With Lhdc One
Enable Bluetooth Pairing Mode on Your Device Turn on your Bluetooth-enabled device and set it to pairing mode, keeping it as close to LHDC ONE as possible. Wait for your device to connect to LHDC ONE. BT_LED Status of Indicator Lights:... -
Page 6: Reconnect Lhdc One To Bluetooth Device
BT_LED Reconnect LHDC ONE to Bluetooth Device Plug LHDC ONE into the USB-C port of your phone or computer. Enable pairing mode on your Blue- tooth device, and LHDC ONE will reconnect to the Bluetooth device. If BT_LED remains for more than 10 seconds, click the switch button to prompt LHDC ONE to actively reconnect to the previously paired Bluetooth device. -
Page 7: Button Switch Functionality
Button Switch Functionality Double-click to enter pairing mode. LHDC ONE can connect to Bluetooth devices in pairing mode. Single Click In the connected state, a single click of the switch button can toggle to low-latency mode. Light Indicator Status Sampling Rate... - Page 8 Green light) Analog Output LHDC ONE can output through the 3.5mm audio jack without the need for Bluetooth device connection (BT_LED: light), and the sampling rate will default to 48kHz. When connected to a Bluetooth device, LHDC ONE will automatically detect the current sam- pling rate of the Bluetooth device.
-
Page 9: Troubleshooting And Solutions
Troubleshooting and Solutions Operational Guidelines During steps 1 to 3, after connecting LHDC ONE to your phone or computer, ensure that the Bluetooth device enters pairing mode immediately after double-clicking the switch button. The interval between these actions should not be too long, as some Bluetooth devices may require a longer pairing time. -
Page 10: Faq
Bluetooth indicator light (BT_LED) will show red, indi- cating that the device is not connected. If you are plug- ging LHDC ONE into a mobile device for the first time, it will automatically enter pairing mode, and the Blue- tooth indicator light (BT_LED) will flash red and blue (this feature is only applicable the first time it is used). - Page 11 How do I operate LHDC To turn off LHDC ONE, simply disconnect it from your mobile device. ONE when not in use? When connecting LHDC Please first confirm whether your Bluetooth device supports the LHDC architecture and whether its ONE to a mobile device version can support 192kHz.
- Page 12 After connecting the headphones to the Android mobile device via Blue- tooth, open the app to view the model and status of the Edifier headphones. Click on the icon in the upper right corner for further settings. Click on "HD audio codec”...
- Page 13 Answering Calls with LHDC The primary function of LHDC ONE is to optimize the processed audio output and does not provide audio ONE on Mobile/Computer input capabilities. Therefore, when answering a call,...
- Page 14 Can LHDC One be used to LHDC One is capable of supporting audio input via USB and is compatible with USB devices that support USB listen to audio from a smart- audio. However, it is important to note that there may phone via USB connection? be a small number of specific devices that do not...
- Page 15 Mac OS iPhone15 and above with Type-C iPad with Type-C If your issue or malfunction still cannot be resolved, please contact us, and we will respond to you as soon as possible! service@lhdc.co...
