- Page 1 Feed adapter ® piFLOW...
-
Page 2: Table Of Contents
Table of Contents 1. Safety instruction .......................... 3 1.1. General safety ........................3 1.2. Grounding of pipe system and accessories ................3 2. Feed adapter for piFLOW®t overview ................... 4 3. Start-up ............................5 3.1. Adjust air inlet ........................5 3.2. -
Page 3: Safety Instruction
Safety instruction 1. Safety instruction 1.1. General safety ® Before use, see also piFLOW manual for safety instructions. Warning Vacuum power at the product and air inlet Grounding The feed adapter must be electrically bonded with the conveyor and other units or machines that are included in the conveyor system. -
Page 4: Feed Adapter For Piflow®T Overview
For details, see Accessories - Clamp rings and seals [7] Notice The air inlet (Pos. C) shall be covered with Piab Air inlet filters when the risk of cross-con- tamination needs to be eliminated. For details, see Accessories - Air inlet filters [6]... -
Page 5: Start-Up
Start-up 3. Start-up 3.1. Adjust air inlet To adjust the air inlet, rotate air inlet control (B) to desired position. *1: Side view : Air inlet open : Air inlet closed 3.2. Adjust to dense phase conveying (*a) Product flow (*b) Air flow Dense phase flow (X in the picture) is used for con- veying a delicate product. -
Page 6: Accessories And Spare Parts
4. Accessories and spare parts 4.1. Accessories - Air inlet filters Piab offers air inlet filters in Carbon steel (Pos. 3a) and Stainless steel with anti-static properties (Pos. 3b) to suit different applications. Air inlet filter suits feed adapter by connecting with a reducer (Pos. 2), which needs to be ordered separate- ly. -
Page 7: Accessories - Clamp Rings And Seals
Accessories and spare parts 4.2. Accessories - Clamp rings and seals Pos. Item no Description 0103972 Clamp ring 21 cpl 0206433 Module seal 21 NBR 0206448 Module seal 21 Q 0202797 U flange Ø340/215 0202798 U flange seal 21-Q 0202804 U flange seal 21-NBR Page 7 of 8 Feed adapter... - Page 8 +33 (0)16-430 82 67 +33 (0)16-430 82 67 +46 (0)8-630 25 00 +46 (0)8-630 25 00 +55 (0)11-449 290 50 +55 (0)11-449 290 50 +86 21 5237 6545 +86 21 5237 6545 info-france@piab.com info-france@piab.com info-sweden@piab.com info-sweden@piab.com info-brasil@piab.com info-brasil@piab.com info-china@piab.com info-china@piab.com...
