Pertronic F100 Installation

PERTRONIC F100 IN-PANEL
with Enhanced Information & Secondary System
1. Installation
a. Install CTU on to Pertronic F100 Fire Alarm Panel Masterboard using supplied
stand-offs
2. Data Interface Connections (Loom / RS-485)
a. Connect 5 wire loom (SGD Ribbon) on CTU board C2 connector (cable to the right)
b. Connect to F100 Masterboard 5 wire loom connector (cable to the bottom)
c. Connect 3 wire cable to CTU SGD Port 1 (A,B,Neg)
d. Plug the 3 wire/4 pin connector to the F100 Masterboard "Internal RS-485"
connector
e. For the secondary connection; run SGD wire from the SGD/DBA and wire into CTU
Port 2
3. Mains Power Supply (24v DC)
a. Connect one end of supplied 2 wire cable in to DC input on CTU
b. Connect to the 24v DC output on the F100 Masterboard
4. Backup CTU Battery (6v 1.3ah)
a. Connect battery leads in to BATT input on CTU
b. Attach to 6v 1.3ah battery placed behind F100 Masterboard batteries
c. Note light will momentarily illuminate red when charging or running on battery
5. CTU Aerials
a. Dual aerials required. Connect aerial flyleads/cables to both the Main and
Diversity connectors on the CTU
i. Dome Antenna – Install aerial in to knockout hole. Feed leads through
ii. Patch Antenna - Run cabling through top of F100 panel and mount
6. Commissioning Tests
a. Comms light illuminates solid green to show CTU is connected to the cellular
network
b. Contact office on 03 341 0464 to test and commission the CTU and complete the
connection to Fire & Emergency NZ.
M:\General\Technical Info\Pertronic\Pertronic F100 In Panel Instructions\F100 Rev K In Panel CTU Installation (WITH Enhanced Information)\Pertronic F100 In
Panel CTU Installation With Secondary System (WITH Enhanced Information).docx
CTU INSTALLATION
panel, then washer and nut. Connect cabling to CTU. Screw washer and nut
tight.
following '4G LTE Aerial Installation' recommendations (approx. 150-
200mm apart). Temporarily fix aerials to window ready for commission
testing.
28/06/23
