Summary of Contents for Ferlin FED 15/30(HT)
- Page 1 USE AND MAINTENANCE MANUAL FOR HONEY CUMB DEHUMIDIFIER TYPES OF MACHINE FED 15/30(HT) FED 20/50(HT) FED 25/75(HT) FED 30/100(HT)
- Page 2 PREMISE This manual was drawn up with the intention of providing operators with the right information for proper use and maintenance of the machine. It is therefore essential to carefully read the manual, in its entirety, in order to prevent any inconvenience that could compromise proper operation or possibly cause irreparable damage to the machine.
-
Page 3: Table Of Contents
INDEX ............................3 1 MANUFACTURER ........................4 2 RISKS AND DANGERS ......................5 2.1 Symbols shown ........................5 2.2 Warnings and danger warnings ..................6 2.3 Noisiness..........................7 2.4 User obligations ......................... 7 2.5 Transport and unpacking ....................7 3 DESCRIPTION OF THE MACHINE AND OPERATING CYCLE ............. 8 3.1 Description ......................... -
Page 4: Manufacturer
1 MANUFACTURER Company name: Ferlin Plastics Automation Legal and administrative residence: Rudolf Dieselstraat 15A 7442DR Nijverdal (NL) Telephone: +31 (0)548 745 370 e-mail: info@ferlin.nl Chamber of Commerce registration number: 05034007 Tax code and VAT number: NL805065507B01 Assistance Service Tele: +31 (0)548 745 370 e-mail: service@ferlin.nl... -
Page 5: Risks And Dangers
2 RISKS AND DANGERS 2.1 Symbols shown Table 2.1 shows the risks for the operator together with the mandatory signs regarding the use of personal protective equipment to be worn when using the machine. Table 2.1: risks to the user ________________________________________________________________________ GENERIC DANGER ________________________________________________________________________... -
Page 6: Warnings And Danger Warnings
2.2 Warnings and danger warnings Filter cleaning Filter cleaning must be performed with the machine stopped and after the blower has stopped. Opening the side panel of the machine Operating with the side panel open is very risky. Therefore make sure that the electrical circuit is suitably sectioned. -
Page 7: Noisiness
2.3 Noisiness The noise level is measured in free field at 1 m from the source and 1.5 m from the ground and is less than 80 dB or below the legal limits. Even if the limit threshold is not exceeded, it is still advisable for the operator to use hearing protection devices (earplugs, headphones). -
Page 8: Description Of The Machine And Operating Cycle
During unpacking operations, the operator must use protective gloves and clothing to avoid possible cuts or grazes due to the presence of wooden parts and plastic bands. The machine is delivered inside a carton or on a wooden pallet. Inside there are: •... -
Page 9: Other Characteristics
2) regeneration where part of the cavities release moisture to the heated ambient air with which it comes into contact; 3) the cooling necessary to prepare the wheel cavities to carry out the process step again. The process is able to maintain low-variable dew point values over time thanks to the cyclicality provided by the movement of the wheel. - Page 10 FED 15/30 (HT) FED 20/50 (HT) FED 25/75 (HT) FED 30/100 (HT)
-
Page 11: Installation
4 INSTALLATION The machine must be installed by expert personnel and in full compliance with all applicable regulations. The installation interventions must be carried out in conditions of absolute safety both for those who carry out the work and for those in the vicinity. To achieve this, the workers must be equipped with all the necessary devices, which delimit the work area with signaling tapes and have danger signs at strategic points. -
Page 12: Cooling Water Connection (Only For Ht Models)
4.3 Cooling water connection (ONLY FOR HT MODELS). The couplings for the cooling water connection have a diameter of 1/4 inch. The pressure must not be greater than 3 bar. The cooling water temperature must be below or equal to 18 ° C. -
Page 13: Human Machine Interface
5 HUMAN MACHINE INTERFACE The dehumidifier is equipped with a graphic (TOUCH SCREEN) for managing the machine status and any alarms. When the machine is turned on, after a few seconds, the display shows the screen in which describes the status of the machine, the type of material and the actual operating temperature. - Page 14 6) Main pages Operating status: 1) if the machine status is in start pressing this button once changes the status to ventilation after about 10 minutes (cooling time) the machine stops and the status is changed to stop START STOP VENTILATION 2) Receiver: If the machine has the receiver (Hopper Loader) MOVAC Easy-4 or MOVAC Easy-5 physically connected, press the icon the figure 5.3 is shown.
- Page 15 5) Main pages: The Touch screen contains 4 main pages pressing the icon shows the first page. On this page the user can change the type of material (the recipe) by pressing once on the material icon. Up and down arrows for choice of recipe (material).
- Page 16 III. The third page contains the machine data; Model, serial number, software version and date and time. The fourth page shows all temperatures of the machines. • RT : the actual operating temperature. • REG: the regeneration temperature. • RAT: return air temperature. •...
-
Page 17: Atr Safety Thermoregulator
Pressing each icon on the screen shows the graph that describes the temperature trend over time. 5.1 Safety thermoregulator The thermoregulator display shows two temperature values: the larger green one represents the temperature detected by the instrument while the smaller red one represents the set for which there is an alarm. -
Page 18: Operational Problems And Possible Remedies
6 OPERATIONAL PROBLEMS AND POSSIBLE REMEDIES Before asking e-service, verify the possible remedies in the following table. Problem Remedy Alarm 01 Clean hopper filter. Check process blower and pipes conditions as well as process temp. proces over temperature selection. Check if SSRP works properly. Alarm 02 Clean regeneration filter. -
Page 19: Maintenance
It is therefore essential to establish and follow a regular inspection and maintenance program. Ferlin Plastics Automation declines any responsibility for damage to persons and / or things deriving from non-compliance with the aforementioned standards or from irregular and / or improper use of the machine. -
Page 20: Machine Disposal
ACHINE NOT AVAILABLE TO BE DISPOSED Before disposing please always get in touch with Ferlin Plastics Automation. In many cases we can give a refund for a used machine. This also enables us to recycle the machine as much as possible. -
Page 21: Warranty
9 WARRANTY Ferlin Plastics Automation (hereinafter referred to as the SELLER) guarantees the BUYER, but not its ASSIGNORS, the machinery produced under the SALE contract, for a period of 12 months from the invoice date. The guarantee is applied for the free repair or replacement of parts found to be unserviceable due to faults or defects in material, construction or workmanship, provided that these parts are delivered ex factory of the SELLER. -
Page 22: Attention
10 ATTENTION It is absolutely forbidden to connect the compressed air pipes to the fitting dedicated to measuring the DEW POINT shown in the photos in the below picture. Failure to comply with this indication will result in the loss of the warranty of the device.
