- Page 1 Hunan Next Generation Instrumental T&C Tech. Co., Ltd. NXI-5100 Series Programmable Resistor Module User Manual © Copyright Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Version: V20230323 NXI-5100 Series Programmable Resistor Module...
-
Page 2: Table Of Contents
3.1.1 Features ....................3 3.2 Appearance ...................... 4 3.3 Hardware Interface ..................4 3.4 Dimension ......................9 3.4.1 NXI-5100 Dimension ................9 4 WIRING INSTRUCTION ..................11 5 PRECAUTIONS ....................11 6 MAIN TECHNICAL DATA ..................12 NXI-5100 Series Programmable Resistor Module... -
Page 3: Contents
This manual is applied to NXI-5100 series programmable resistance module, including installation, operation, specifications and other detailed information. The copyright of the manual is owned by NGI. Due to the upgrade of instrument, this manual may be revised without notice in future versions. -
Page 4: Safety Instructions
NGI shall not be liable for the results caused by the neglect of those instructions. 2.1 Safety Notes Confirm the AC input voltage before supplying power. -
Page 5: Product
Switch life: low load > 100 million operations, full load > 1 million operations Fast action, supporting 2000 times resistance programming per second Supporting specification and model customization LAN communication control NXI-5100 Series Programmable Resistor Module... -
Page 6: Appearance
NXI-5100 adopts standard RJ45 socket for network communication interface. The following table is description of hardware interfaces on NXI-5100. Table 2 Number Description Status indicator light Test connector 12VDC power supply port RJ45 LAN port NXI-5100 Series Programmable Resistor Module... - Page 7 Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. R2_A R6_A NXI-5100 Series Programmable Resistor Module...
- Page 8 Reserved. Please do not use. R3_A R9_A R4_B R10_B Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. NXI-5100 Series Programmable Resistor Module...
- Page 9 Reserved. Please do not use. Reserved. Please do not use. R5_A R13_A R6_B R14_B Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. R6_A R14_A R7_B R15_B NXI-5100 Series Programmable Resistor Module...
- Page 10 Reserved. Please do not use. R8_A R20_A R9_B R21_B R9_A R21_A R10_B R22_B R10_A R22_A R11_B R23_B Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. Reserved. Please do not use. NXI-5100 Series Programmable Resistor Module...
-
Page 11: Dimension
Hunan Next Generation Instrumental T&C Tech. Co., Ltd. R11_A R23_A R12_B R24_B R12_A R24_A 3.4 Dimension 3.4.1 NXI-5100 Dimension Figure 3 NXI-5100 Dimension Figure 4 Test Connector Dimension NXI-5100 Series Programmable Resistor Module... - Page 12 Hunan Next Generation Instrumental T&C Tech. Co., Ltd. Figure 5 LAN Port Dimension Figure 6 Status Indicator Light Dimension Figure 7 12VDC Power Supply Port Dimension NXI-5100 Series Programmable Resistor Module...
-
Page 13: Wiring Instruction
High-precision resistor module: Please ensure good cooling and ventilation conditions. If using NXI-5100 alone, please use a standard wire sequence Ethernet cable. Before use, please pay attention to whether the state of status light is normal. NXI-5100 Series Programmable Resistor Module... -
Page 14: Main Technical Data
Resolution 10Ω 1Ω Resistance accuracy ±0.1%+Rr, 25ppm Maximum switching voltage 125 VAC, 60 VDC Residual resistance Rr, typical value (when the resistance is programmed 3Ω to 0Ω) Resistor maximum power 0.25W Maximum switching current 0.5A NXI-5100 Series Programmable Resistor Module... - Page 15 Switch closing time <1.1ms Switch release time <0.4ms Expected switch life Low load application >1×10 times operation Expected switch life Full load application >1×10 times operation Power supply +12VDC Interface Dimension 20(H)*130.5(W)*193.9(D)mm Net Weight Approx. 0.7kg NXI-5100 Series Programmable Resistor Module...
- Page 16 Maximum switching voltage 125 VAC, 60 VDC Residual resistance Rr, typical value (when the resistance is programmed 3Ω to 0Ω) Resistor maximum power 0.25W Maximum switching current 0.5A Switch closing time <1.1ms Switch release time <0.4ms NXI-5100 Series Programmable Resistor Module...
- Page 17 Switch closing time <1.1ms Switch release time <0.4ms Expected switch life Low load application >1×10 times operation Expected switch life Full load application >1×10 times operation Power supply +12VDC Interface Dimension 20(H)*130.5(W)*193.9(D)mm Net Weight Approx. 0.7kg NXI-5100 Series Programmable Resistor Module...
- Page 18 Expected switch life Full load application >1×10 times operation Power supply +12VDC Interface Dimension 20(H)*130.5(W)*193.9(D)mm Net Weight Approx. 0.7kg Note 1: For other specifications, please contact NGI. Note 2: All specifications are subject to change without notice. NXI-5100 Series Programmable Resistor Module...
