- Page 1 Instruction Manual Wine Cooler BWS93BK...
-
Page 3: Table Of Contents
1 Safety warnings Warning 1.2 Meaning of safety warning symbols 1.3 Electricity related warnings 1.4 Related warnings for use 1.5 Warnings related to placing items Warnings for energy 1.7 Warnings related to disposal 2 Proper use of wine cooler 2.1 Names of components Temperature Control 2.3 Placement 2.4 Start to use... -
Page 4: Safety Warnings
1 Safety warnings 1.1 Warning THIS appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments; bed and breakfast type environments; catering and similar non- retail applications. - Page 5 REFRIGERANT and cyclopentane foaming material used for the appliance are flammable. Therefore, when the appliance is scrapped, it shall be kept away from any fire source and be recovered by a special recovering company with corresponding qualification other than be disposed by combustion, so as to prevent damage to the environment or any other harm.
-
Page 6: Meaning Of Safety Warning Symbols
1.2 Meaning of safety warning symbols The symbols indicate prohibited matters, and those behaviors are forbidden. Non-compliance with the instructions may result in product damages or endanger the personal safety of users. Prohibition symbols The symbols indicate matters that must be followed, and those behaviors must be strictly executed in line with the operation requirements. -
Page 7: Related Warnings For Use
1.4 Related warnings for use Do not arbitrarily disassemble or reconstruct the wine cooler , nor damage the refrigerant circuit; maintenance of the appliance must be conducted by a specialist. Damaged power cord must be replaced by the manufacturer, its maintenance department or related professionals in order to avoid danger. -
Page 8: Warnings Related To Placing Items
1.5 Warnings related to placing items Do not put flammable, explosive, volatile and highly corrosive items in the cooler to prevent damages to the product or fire accidents. Do not place flammable items near the cooler to avoid fires. This product is household cooler and this equipment can only be used for the storage of wine. -
Page 9: Proper Use Of Wine Cooler
2 Proper use of wine cooler Names of components Names of components LED lamp Refrigerator rollbond evaporator Wine shelf G ass door Wine shelf Wine shelf Wine shelf Steel column strip Levelling foot Levelling foot ( The picture above is only for reference. The actual configuration will depend on the physical product or statement by the distributor ) The recommended temperature is 12 the product is most energy efficient when the shelves... -
Page 10: Temperature Control
Temperature Control Temperature-rise key Lighting key Display area Locking and unlocking Temperature-drop key Display Control when power-on the cooler, the display screen will display in full last for 3 seconds, and the start-up tone will ring, and then enter into the display of normal operation; Normal operation display: In case of no failure, set temperature is displayed;... -
Page 11: Placement
Error code: If the failure happens, the display area will show corresponding error codes as shown as below table, the user shall contact a specialist for maintenance, so as to make sure the normal use of the cooler. Error code Ambient temperature sensor fault Description Communication fault... -
Page 12: Practical Skills For Grape Wine's Storage
The cork of the old bottle shall always be soaked in the wine when putting into wine cooler. Air space is not allowed between wine and cork. -
Page 13: Disconnect The Wine Cooler
Maintenance of wine cooler 3 1Disconnect the wine cooler Unplug power plug to disconnect the wine cooler. 3 2 Stop using the wine cooler If the cooler left unused for a long time, please: 1. Unplug the cooler; 2. Clean the cooler; 3. -
Page 14: Trouble Shooting
4 Trouble shooting Whether the cooler is plugged and connected to power; Low voltage; Not work Whether temperature control knob is in the work area; Failure power or tripping circuit. It is normal that cooler operates for longer time in Long-term operation summer when the ambient temperature is higher;... - Page 15 Table 1 Climate classes Ambient temperature range Class Symbol + 10 to + 32 Extended temperate Temperate + 16 to + 32 Subtropical + 16 to + 38 Tropical + 16 to + 43 Extended temperate: ‘this refrigerating appliance is intended to be used at ambient temperatures ranging from 10 °C to 32 °C’;...
- Page 16 Supplier`s trademark belling Supplier`s model BWS93BK Category of refrigerating appliance Wine Cooler Energy efficiency class 145kWh/year Annual energy consumption Wine torage volume Refrigerator storage volume Identification of frost free compartments Temperature rise time (power-cut off time) Freezing capacity SN/N/ST This appliance is...
- Page 18 Your Belling Appliance is guaranteed against breakdown for an initial period of 12 months from date of purchase (for guarantee conditions please refer to your instruction booklet) Your standard one year guarantee is extended for an additional 12 months when you register the product within 28 days of purchase with Glen Dimplex Ireland.
