Summary of Contents for Solid Signal Rover Duo RV
- Page 1 Rover Duo RV Car-to-RV Cellular Signal Booster Kit powered by Need help? info@solidsignal.com 877-312-4547...
- Page 2 ©2022, Signal Group, LLC This owner’s manual and all materials are proprietary to Signal Group, LLC, and may not be reproduced without permission. Contents of package may change without prior notice and may not represent the exact contents shown in this owner’s manual. For licensing or other inquiries, contact Signal Group at 877-312-4547.
-
Page 3: Table Of Contents
Step 6: Connect cables and power supply (for RV) ............12 Moving the 2-in-1 amplifier from your car to your RV (or back to your car) ..........13 Booster Light Patterns ..........14 Troubleshooting ..........15 Safety Guidelines ..........16 Specifications ............17 Warranty ............17 ROVER DUO RV... -
Page 4: What's In The Box
RV Power 2-in-1 Amplifier RV Antenna with mast Antenna Supply (470054) and cable with cable (850015) (311230) (311160) Antenna Outdoor Antenna Indoor Antenna Power Adapters (2) with attached cable with attached cable Supply (970019) (311216) (314401) (850029) ROVER DUO RV... -
Page 5: Step 1: Attaching The Antenna Adapters
They should hold securely. If they do detach, simply push them back in. These adapters give your amplifier the ability to use screw-on antennas, which makes moving the amplifier from vehicle to vehicle easy! ROVER DUO RV... -
Page 6: Step 2A: Mounting The Antenna To The Outside Of Your Car
(do not use if outside antenna will magnetize to the top of any coating that is on the roof. your vehicle). WORKS WITH ALL VEHICLES WORKS WITH ALL VEHICLES WORKS WITH ALL VEHICLES DRIVE REACH VEHICLE SIGNAL BOOSTER DRIVE REACH VEHICLE SIGNAL BOOSTER DRIVE REACH VEHICLE SIGNAL BOOSTER ROVER DUO RV... - Page 7 VEHICLE SIGNAL BOOSTER DRIVE REACH VEHICLE SIGNAL BOOSTER DRIVE REACH ROVER DUO RV...
-
Page 8: Step 2B: Mounting The Antenna To The Inside Of Your Car
2-sided adhesive strip provided and attach to the side of the antenna labeled “MOUNTING SIDE”. Then mount to desired location. WARNING: DO NOT MOUNT WHERE AIRBAGS WILL DEPLOY. Inside antenna seat mount Inside antenna dash mount ROVER DUO RV... -
Page 9: Step 3: Connecting The Outside Antenna And Power Supply To The Booster (For Car)
VEHICLE SIGNAL BOOSTER DRIVE REACH the booster off by switching the rocker to the “OFF” position. This will prevent the booster from draining the battery in your vehicle. Plug into vehicle’s 12V DC power supply ROVER DUO RV... -
Page 10: Step 4: Mounting The Outside Antenna On Your Rv
To assemble the outside antenna, insert cable through mast extension then through side exit adapter. NOTE: Antenna spring can be used optionally. 13” mast cable from Outside Antenna Side Exit run cable through Adapter Mast Extension(s) Optional Antenna Spring ROVER DUO RV... - Page 11 NOTE: When adding the side exit adapter hold the outside antenna vertically and screw the side exit adapter from the bottom up. This reduces cable twisting Outside Antenna mast thread locker thread locker mast Side Exit Adapter (cable from antenna) ROVER DUO RV...
- Page 12 NOTE: Outside antenna location must be within reach of the booster with the 25’ coax cable. The system performs best with maximum vertical and horizontal separation. Side Exit Adapter thread locker Spring (Optional) Ladder rail thread locker L-Bracket Mount & Hardware ROVER DUO RV...
-
Page 13: Step 5A: Route Cable And Connect Outside Antenna On Your Rv
Step 5b: Connect cable to inside antenna on your RV Place inside antenna where stronger signal is desired in the RV. If necessary, connect the cable to the inside antenna. Inside Antenna Indoor Cable ROVER DUO RV... -
Page 14: Step 6: Connect Cables And Power Supply (For Rv)
Connect cable from inside antenna to labeled booster port. from Inside Antenna Connect the power supply cord to the end of the booster, labeled “12V DC”, and connect into a 12V wall plug. Plug into wall socket ROVER DUO RV... -
Page 15: Moving The 2-In-1 Amplifier From Your Car To Your Rv (Or Back To Your Car)
Moving the 2-in-1 amplifier from your car to your RV (or back to your car) The Rover Duo RV’s amplifier can be taken from vehicle to vehicle easily by disconnecting it from your car’s antennas. Simply unscrew the outside and inside antennas and gently pull the power supply cord. -
Page 16: Booster Light Patterns
“on” position. NOTE: The signal booster can be reset by disconnecting and reconnecting the power supply. After troubleshooting you must initiate a new power cycle by disconnecting and then reconnecting power to the booster. ROVER DUO RV... -
Page 17: Troubleshooting
The best way to keep these spheres of signal from overlapping is to maximize separation between the inside and outside antennas. ROVER DUO RV... -
Page 18: Safety Guidelines
FOR MORE INFORMATION ON REQUIREMENTS SET OUT IN ISED CPC-2-1-05, SEE BELOW: http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08942.html FOR MORE INFORMATION ON REGISTERING YOUR SIGNAL BOOSTER WITH YOUR WIRELESS PROVIDER, PLEASE SEE BELOW: T-Mobile/Sprint/MetroPCS: https://www.t-mobile.com/support/coverage/register-a-signal- booster Verizon Wireless: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html AT&T: https://securec45.securewebsession.com/attsignalbooster.com/ U.S. Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp ROVER DUO RV... -
Page 19: Specifications
Specifications Rover Duo RV Model Number 78048 FCC ID PWO460061 4726A-460061 Connectors SMA/SMB-Female Antenna Impedance 50 Ohms Frequency 698-716 MHz, 728-756 MHz, 777-787 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755/2110-2155 MHz Maximum Power 700 MHz 700 MHz 800 MHz 1700 MHz... - Page 20 22285 Roethel Drive, Novi MI 48375 877-312-4547 • www.solidsignal.com © 2022, Signal Group, LLC. All rights reserved. Based with permission on prior art, ©2019, weBoost. For further information, call 877-312-4547.
