Summary of Contents for GiRAFFE TOOLS HC03C
- Page 1 HOSE CART WITH HOSE GUIDE INSTALLED Model HC03C For more information visit giraffetools.com or contact our customer service by sending an email to service@giraffetools.com...
- Page 2 MANUAL CONTENTS Installation Steps Product Information ---------- ---------------- Problems Solution What’s Included -------------- --------------- Warranty Open-Box Check ------------- ------------------------- Recommended Products Tools Requirement ----------- --------...
-
Page 3: Product Information
PRODUCT INFORMATION Thank you for choosing Giraffe Tools garden hose reel cart which features a large capacity of 250-feet of 5/8" garden hose. Our product contains a 5ft lead in hose. Before using the hose reel cart, please read the following installation instructions and refer to them when necessary. -
Page 4: What's Included
WHAT’S INCLUDED Crank Handle ×1 Hose Reel ×1 ① ② Push Handle ×1 Accessories Basket ×1 ③ ④ Hose Guide Frame ×1 Axel ×2 ⑤ ⑥ Wheel ×4 Leader Hose ×1 ⑦ ⑧ M6 X 45 bolt ×4 M6 X 30 bolt ×1 M6 flat washer ×5... -
Page 5: Open-Box Check
Check for any scratches or damage done to the product. If your product is missing parts or has visible damage upon receipt, please contact the Giraffe Tools customer service team at service@giraffetools.com. If you notice an initial aroma upon opening your package,this is due to the sealed Note: environment in which the package traveled overseas. - Page 6 Step 1 ： Press the snap button on axel ⑥ and insert it through the holes of the frame ⑤ . Press the snap button on each side again and insert the holes of the wheels ⑦ . The snap button is on both sides of the axels. Note:...
- Page 7 Step 2 ： Insert the crank handle ① to the hole of the bearing bracket (do not cross the belt). Put the hose reel ② on hose guide frame and assemble the belt on the gear of the hose reel. Last, insert the crank handle all in. Use the M6 x 30 bolt (B), M6 flat washer (C), M6 Nylon nut (D) to install the crank handle.
- Page 8 Step 3 ： Adjust screw rod brackets on both sides to make sure the belt is connected with driving gear and drive gear. And tighten the screws on both sides. Step 4 ： Insert Push Handle into Frame in the direction shown in the photo. When Push Handle touches the Snap Button, press the Snap Button on both sides of Push Handle and continue to insert Push Handle until the Snap Button pop up.
- Page 9 Step 5 ： Assemble accessories basket ④ on push handle in the direction shown in the photo. Assemble M6 x 45 bolt (A), M6 flat washer (C) and M6 Nylon nuts (D) to tighten them. Step 6 ： Screw leader hose ⑧ into water inlet as shown in the photo and fully tighten it with a wrench (not included).
- Page 10 Step 7 ： Turn the crank handle to move the hose guide system to the water inlet side. Insert one side of long hose (not included) through the hole of hose guide system and then connect it to water outlet joint.
- Page 11 PROBLEMS SOLUTION Part Missing / Other Quality Damage If your package is missing some parts or any other quality damage, please contact customer service at service@giraffetools.com with your order number, shipping info, and an accompanying photo of the damaged parts. Lead-in Hose Leakage First please check the rubber washer of the two connectors.
- Page 12 It may be necessary to return an item for quality inspection. ● For defective items that Giraffe Tools needs to have returned, warrantion those replacements are voided if the wrong item is returned to Giraffe Tools or if the defective item is not returned.
- Page 13 Valid proof of purchase: ● Order number from online purchases made through Giraffe Tools or Giraffe Tools’s authorized resellers. ● Sales invoice that shows a description of the product along with its price. Not Covered Under Warranty: ● Purchases from unauthorized resellers.
- Page 14 Hybrid Hose with Customized Garden 150-250ft Swivel Grip 2.5-100ft Hose 6-100ft Scan code to visit Giraffe Tools Scan code to visit giraffetools.com Scan code to join our store on Amazon.com facebook group If you are interested in the above products, you can visit giraffetools.com or search for...
- Page 15 WE WILL DO THE HEAVY LIFTING To purchase Giraffe Tools products and more, visit giraffetools.com or search for Giraffe Tools on Amazon.com. Complete your registration online for a 100 DAYS WARRANTY EXTENSION giraffetools.com service@giraffetools.com +1 (833)583-0881 (9am - 5pm EST)
