USER MANUAL

U N I Q S M A R T D O O R L O C K

OZ-FDL-05 LIFE STD

Fingerprint

Password

OzoLife

Mobile App

DOORBELL

RFID Card

Emergency

Key

DOWNLOAD NOW

OzoLife

OzoLife iOS

OzoLife Android

WWW.OZONESECUTECH.COM

EMAIL ID: INFO@OZONESECUTECH.COM | CUSTOMER CARE: +91-9310012300

Table of Contents

Need help?

Do you have a question about the OZ-FDL-05 LIFE STD and is the answer not in the manual?

Questions and answers

Summary of Contents for Zone OZ-FDL-05 LIFE STD

Page 1 USER MANUAL U N I Q S M A R T D O O R L O C K OZ-FDL-05 LIFE STD Fingerprint Password OzoLife Mobile App DOORBELL RFID Card Emergency DOWNLOAD NOW OzoLife OzoLife iOS OzoLife Android WWW.OZONESECUTECH.COM EMAIL ID: INFO@OZONESECUTECH.COM | CUSTOMER CARE: +91-9310012300...
Page 2 INDEX Introduction Lock Structure And Product Feature Installation Steps Product Speciﬁcation Packing Detail & Dimensions 11-19 Operation Steps Warranty Card 21-22...
Page 3 INTRODUCTION CAUTION - Necessary safety measures must be ensured before starting the installation to prevent damage to assets and personnel. - Accuracy of the door preparation is a critical parameter for the proper door installation, Lock functioning, and security of the product.
Page 4 INTRODUCTION CAUTION Special Note Before Installation Special Note Before Installation - Necessary safety measures must be ensured before starting the installation to prevent damage to assets and personnel. - Necessary safety measures must be ensured before starting the installation to prevent damage to assets and personnel. - Accuracy of the door preparation is a critical parameter for the proper door installation, Lock functioning, and security of the - Accuracy of the door preparation is a critical parameter for the proper door installation, Lock functioning, and security of the product.
Page 5 1.1 LOCK STRUCTURE Battery Indicator Cover Keypad & RFID card 1 2 3 4 5 6 Door bell 7 8 9 On/Off * 0 # Button Fingerprint Reset Button Mechanical Knob Emergency USB emergency power supply 1.2 Product Features 1) Micro USB emergency power supply: Incase of emergency the product could be operated by USB through power bank.
Page 6: Installation Steps
Installation Steps 1) Drilling template: Please follow the template to drill hole ﬁrst 64.5 2) Installation mortise: First insert the mortise into the door hole, and then ﬁx the screws, see the ﬁgure below. INTRODUCTION OPERATION APPENDIX...
Page 7 3) Installation of stop screws: Right door open shown in ﬁgure 1 below (Front panel screw ﬁxed in R position, back panel screws ﬁxed in R position); left door open shown in ﬁgure 2 below (Front panel screws ﬁxed in position, back panel screws ﬁxed in L position) Front Back...
Page 8 5) Installation of the front panel: First conﬁrm the opening direction, see ﬁgure 1 below, and then adjust the location of the mortise connection as shown in ﬁgure 2 below, connect the mortice moto cable and insert the screw into the hole (see ﬁgure 3 below). Figure 1 6) Installation of the rear panel: First rotate the handle 90, push the battery cover in the direction of the battery cover...
Page 9 Right Left 1 2 3 1 2 3 4 5 6 4 5 6 7 8 9 7 8 9 * 0 # * 0 # Figure 3 7) Installation of the rear panel: First rotate the handle 90 , push the battery cover in the direction of the battery cover arrow and remove, connect the cable and install the real panel.
Page 10 (8) Change the battery: press the press mark on the battery cover to open the battery cover, and then install the battery (pay attention to the positive and negative direction of the battery) see the ﬁgure below. INTRODUCTION OPERATION APPENDIX...
Page 11: Product Specifications
Product Speciﬁcations Lock Material Aluminum Alloy Color Black Door Thickness 35-80mm Communication OzoLife Support OS iOS 7.0 or above, Android 4.4 or above Battery Life (6-8 months) by 15 times normal unlock Power Supply DC6V: 4pcs AA alkaline batteries < _ 50 uA Static Current <...
Page 12: Packing Details
10. Packing Details Name Name Front Panel Rear Panel 1 set Gasket Rubber Plate 2pcs Emergency Key 2 pc M4X35 screws Reset Pin M4X45 screws 2pcs User manual Cut out template Mortise USB cable Plate case 4X20 screws 6pcs Screw Φ6x35 3 pcs RFID Card 2pcs...
Page 13: Operation Steps
OPERATION STEPS OZOLIFE APP OPERATIONS Please download the OzoLife on the Apple Store or Google Play Store. Also, you can scan the QR code below to download the APP directly. OzoLife iOS OzoLife Android 8.1 Please register one account with your E-mail. 8.1.1 Sign-up 8.1.2 Enter mail I’d Get 8.1.3 Enter the code...
Page 14: Interface Introduction
INTERFACE INTRODUCTION SmartLockBle Power display: When the phone is connected to the lock, you can see the lock's real time battery life. Opening record: You can check which user had Temporary code: Use this opened the door in which way. to create temporary passcode to unlock the lock.
Page 15: Member Management
MEMBER MANAGEMENT ADD MEMBER Click on “+” to add Fill member name, After member accepts member app account detail & new member. the invitation, his details will select family role then click on reﬂect on the screen. save. FINGERPRINT MANAGEMENT Click on member Click on “Add”...
Page 16: Password Management
PASSWORD MANAGEMENT Enter 8 digit user deﬁned Click on “Add” to enroll Click on member code or click on “Random” to password. details to add password. auto-generate. Add code name (Optional) then click on “Save” button to save changes. DOOR CARD MANAGEMENT Click on member Click on “Add”...
Page 17 TEMPORARY CODE MANAGEMENT Time Limited Select “ Time Limited” Select “Effective time” and “Expiration 12-08-2022 12:00 12-08-2022 12:00 12-08-2022 13:00 time” for the passcode. 12-08-2022 13:00 type the code name (optional) Click on “Get Code”. A 10-digits system-generated code will be created. Use the code to unlock the door.
Page 18 TEMPORARY CODE MANAGEMENT Dynamic Passcode: Select “Dynamic” and click on “Get Code” to get system generated 8 digit passcode which is valid for 5 minutes and it can be used multiple times before it expires. Clear Code: Select clear code. Select clear type. Choose from “all clear or “individual clear.
Page 19: Lock Setting
LOCK SETTING Special Function: Dual Combination Privacy Locking Lock Volume Passage Mode: click on “Set” After click on For enable/disable dual combination For enable/disable Privacy Locking Select “Lock Volume” to set lock voice mode click on “two-factor authentication” mode click on “spacial control” prompts volume or to mute.
Page 20 ADD GATEWAY (OPTION) 3.1.1. ADD BLUETOOTH GATEWAY 2.4Ghz Red: The Wi- Fi Light Switch/Reset button Blue: The Bluetooth Light Charging Power on the gateway. Turn on the phone bluetooth and connect to 2.4g Wi-Fi (note that if the router supports both 2.4g and 5G modes, the phone must be connected to a 2.4g network;...
Page 21 ADD DOOR LOCK TO THE BLUETOOTH GATEWAY THERE ARE TWO WAYS TO ADD BLUETOOTH DOOR LOCK DEVICE UNDER BLUETOOTH GATEWAY Method 1: Method 2: Enter the bluetooth Gateway Device App Select the new device to search, select the panel (as shown in picture 1), select add in "door lock"...
Page 22 FAQs How to read operation records? Select “Opening record” option on lock main interface After installation, touch sensing keyboard or screen not responding. a) First check that the positive and negative electrodes of the battery have been installed upside down. b) Check whether the battery has enough power.
Page 23: Warranty Card
WARRANTY CARD E-Mail ID Invoice No. Total Quantity...
Page 25 Special Instructions: • Please replace the battery as soon as the low voltage alarm signals it. • Read this manual carefully before installation and keep it safe, for future reference. OzoLife Ozone Secutech Pvt. Ltd. Registered Oﬃce: H 40, Bali Nagar, New Delhi - 110015, India Operations Oﬃce: Plot No.
